CyberPower CP-H430P User Manual

Before using your new product, please read
these instructions to prevent any damage.
USB 3.0 4-Port Hub
CP-H430P Serial User Guide

Package contents

• USB 3.0 4-Port Hub
• 5V/3.6A power adapter
• USB cable
• Quick User Guide

System requirements

• Computer with a USB 2.0 or 3.0 port
Note: USB 3.0 is compatible with USB
2.0, however data transfer speed will
be limited to the 2.0 level.
• Latest version of Windows® 8,
Windows® 7, Windows Vista®, or
Windows® XP; or Mac OS X 10.4 or later
Features
• Backwards compatible with
previous-generation USB revisions
• Adds expansion ports with supplemental
power to your computer
• Blue LED power indicator
• Supports hot-swappable and Plug &
Play capability
• Supports over-current protection at
USB host port
Downstream ports (to devices)
Downstream ports (to devices)
Upstream port
(to computer)
Installation
This USB Hub is a plug and play device.
Your computer will display the Add New
Hardware Wizard after connecting the hub
to your computer. Installation may be done
whether your computer is powered on or
off. It is not necessary to restart your
computer after installation.
1. Connect the USB cable to the upstream
port on the Hub, then connect the
other end of the cable to an unused USB
port on your computer.
2. Connect your USB devices to the UBS
ports on the Hub.
Self-Powering the Hub:
If additional power is required for
connected USB devices, plug the power
adapter into the DC jack, then plug the
power adapter into a wall outlet.
LED
Suction cup
DC jack
(Power connector)
