ALSO FROM IFB
MICROWAVE OVEN
CAPACITY - 17 to 30 LITERS
Advancing the science of washing
DISHWASHER
CAPACITY - 12 PLACE SETTING
CLOTHES DRYER
CAPACITY - 5.5KG
EXECUTIVE PLUS
Customer Care
OPERATING MANUAL
Dial
1860 425 5678 -
BSNL & MTNL Callers
3900 4321 -
Other Callers
or email
customerservice@ifbglobal.com
USE ONLY GENUINE IFB SPARES & ACCESSORIES
* Company shall not be responsible for defects arising due to usage of spurious parts and accessories
IFB Industries Limited, Plot No. IND - 5, Sector - 1, East Calcutta Township, Calcutta - 700 078
Visit us at www.ifbappliances.com
Advertisement
Table of Contents
Related Manuals for IFB EXECUTIVE PLUS WTEX+B
Summary of Contents for IFB EXECUTIVE PLUS WTEX+B
-
Page 1: Customer Care
ALSO FROM IFB MICROWAVE OVEN CAPACITY - 17 to 30 LITERS Advancing the science of washing DISHWASHER CAPACITY - 12 PLACE SETTING CLOTHES DRYER CAPACITY - 5.5KG EXECUTIVE PLUS Customer Care OPERATING MANUAL Dial 1860 425 5678 - BSNL & MTNL Callers 3900 4321 - Other Callers or email... -
Page 3: Table Of Contents
SERVICE STATION COPY CONTENTS MODEL : EXECUTIVE PIUS SR. NO. WTEX+B KNOW YOUR MACHINE INSTALLATION Pre Installation DEALER’S NAME : Unpacking Setting Up CUSTOMER’S NAME : Water Inlet Water Outlet ADDRESS : Electrical Connection USING YOUR MACHINE PIN CODE : Control Panel Enviromental protection / conservation issues TEL. -
Page 4: Know Your Machine
KNOW YOUR MACHINE INSTALLATION REPORT IFB WASHING MACHINE Model : __________________ Serial No. : ______________Customer’s Name : __________________ _________________________________________________Tel. No. ___________________________ Address :___________________________________________________________________________ Spin Cancel Button __________________________________________________________________________________ Spin Speed Selector Button Water Plus Button Installation Check Points Machine Delivered on : __________________ Machine Installed on :_______________ On/Off Switch with Temperature Detergent Tray... -
Page 5: Installation
CUSTOMER COPY INSTALLATION Pre Installation MODEL : EXECUTIVE PIUS SR. NO. WTEX+B 1. It is mandatory to have a 16 amp. 3-pin 230V AC, 50Hz electrical point with a 16 amp. MCB or Automatic short DEALER’S NAME : circuit protection device within 1 meter of the machine. Make sure it has proper earthing. -
Page 6: Setting Up
6. Remove transit bolts. TECHNICAL DATA 7. Insert plastic caps provided into holes vacated and press till they click into place. Dimensions (DxWxH) 56 cm x 60 cm x 85 cm 8. Keep transit bolts carefully. They will be required in case you need to Weight 57 kgs shift the machine again. -
Page 7: Water Inlet
Avoid the machine coming in contact with floor cleaning Water Inlet chemicals.* WATER INLET 1. Connect inlet hose to water tap/line. Do not wash or spray water over the switch or control panel. 2. Do not connect machine to a hot water Do not allow children/pets to play with the machine. -
Page 8: Safety Precautions
SAFETY PRECAUTIONS Use of extension cord not recommended since it may not be properly earthed. Ensure that the machine is properly balanced on four adjustable Use ISI marked sockets of reputed make for preventing loose feet. contact of power supply cable. Ensure that the machine is connected to 3 pin socket with good Ensure that there is a firm connection between the 3 PIN PLUG and earth and 16 Amp MCB or other automatic short circuit... -
Page 9: Using Your Machine
USING YOUR MACHINE MACHINE DOES NOT START. Check position of programme selector knob Check water supply Porthole door not closed properly Indicator lamp not glowing MACHINE DOES NOT SPIN/ CLOTHES REMAIN WET. Check if the Spin Cancel Button is pressed. Unblanced load ( Divide the load in two halfs and spin each load using exclusive spin program with desired spin speed or add smaller articles of... -
Page 10: Enviromental Protection / Conservation Issues
Environmental Protection/ Conservation Issues FAULT DIAGNOSIS Your washing machine uses water, energy and detergent efficiently, thereby protecting the environment and reducing your household costs. WHY DOES IT HAPPEN? Using your washing machine in an efficient and environmentally PILOT LAMP DOES NOT GLOW. friendly manner: Check if the machine is ON. -
Page 11: Automatic Detergent Dispenser Tray
DRUM AUTOMATIC DETERGENT DISPENSER TRAY Rust Stains Designed automatic dispensing Never leave metal items e.g. paper clips, safety detergent & additives as required, which pins etc. in the drum as it creates superficial rust avoids manual filling at each stage. marks in drum. -
Page 12: Maintenance
To be pressed for drying easy care fabrics. MAINTENANCE Clothes spin dry at 600 rpm only when the FLUFF FILTER button is pressed. Spinning takes place initially at 600 r.p.m. then increases to 800 r.p.m. automatically if the button is not pressed. (A - F ) Spin speed is 600 r.p.m. - Page 13 PROGRAMME SELECTOR KNOB PROGRAMME RUN To select the right programme as per the Note: fabric being washed and extent of During the programme run the knob turns automatically in the soilage. clockwise direction only. A choice of 18 programmes is available Washing, rinsing and spinning can be seen through the porthole to wash different kinds/loads of clothes.
- Page 14 INDICATOR LAMP IRONING Red lamp glows when the machine is The number of dots indicate the maximum recommended temperature switched ON and switches OFF when Max 200 C, machine is switched OFF. Green lamp glows to indicate the start of Max 150 C, t h e w a s h...
- Page 15 TREATMENT OF STAINS 1. Normal Wash Programmes A To F Stains need to be treated immediately when they are fresh. Usually STAGE 1 : Pre-Wash - A stains are categorised as absorbed stains, built-up stains, and Clothes are soaked, tumbled in hot water with detergent to compound stains.
- Page 16 STAGE II : Main Wash - H / K DETERGENT TO BE USED AND QUANTITY The best washing results will be achieved by using the correct Clothes are soaked, tumbled in hot water with detergent for dosage of detergent . lesser duration than main wash of Normal Wash programme.
- Page 17 OPERATION Exclusive spin drying programmes : F and L Can be used for spin drying hand washed / wet clothes. Sorting Of Garments Turn programme selector knob directly to any of the spin drying points (i.e. just beyond F or L) after loading the Machine to be used for machine washable fabrics only (Look clothes.
