Team C T8E User Manual page 11

13
Steering Turnbuckle
Bag
T08606
6.8 Ball stud
T08606
6.8 Ball End-Steering
T08643 4x53 Turnbuckle
14
Front Upper/Steering Turnbuckle
Front Upper Turnbuckle-Right
T08676 M3x25
T08674 M3x16 Screw
......2
True-to -scale diagram
1:1
D
-
T08606
6.8 Ball stud
5mm
T08606
6.8 Ball End-Steering
T08643
4x53 Turnbuckle
T08606 6.8 Ball stud
.........2
D
-
Bag
T08674 M3x16
T08666 M3
T08676 M3x18
T08666 M3 Nylon Nut T08676 M3x25 Screw
............6
Assemble as many times as specified
x1
Steering-Left
1:1 x1
Steering-Right
1:1 x1
T08606 6.8 Ball stud
...............2 ...............2
Steering Turnbuckle-Right
T08666 M3
T08666 M3
......2
7
Approx.32.5mm
▲Projection.Note direction
Approx.32.5mm
▲Projection.Note direction
T08606 6.8 Ball End-Steering
Steering Turnbuckle-Left
Front Upper Turnbuckle-Left
T08676 M3x25
T08676 M3x18 Screw
......2
...............4
T08674 M3x16
T08666 M3
