coNTeNTS
Product Dimensions ................................................................3
Accessories ..................................................................................3
Advance Planning ............................................................... 4, 5
Installation preparation
Clearances .............................................................................. 6, 7
Parts Supplied ............................................................................7
Tools and Materials Required .............................................7
Remove Packaging ..................................................................7
Power Supply ..............................................................................8
Venting Options .........................................................................9
pRoDucT DIMeNSIoNS
A
30" Models
30"
36" Models
36" 33-15/16"
AcceSSoRIeS
jXRb67 - Optional accessory for indoor remote
location of the blower/motor assembly. Use this kit
when the blower and motor assembly will be located
outside of the cabinet, such as below the cabinet floor.
Design Information
b
28-5/16"
Duct Fittings ............................................................................. 10
Step 1, Install Downdraft Vent ......................................... 11
Step 2, Install the Ductwork .............................................. 11
Step 3, Install Remote Switch ........................................... 12
Step 4, Connect Power ........................................................ 13
Step 5, Install Filters, Check Operation ........................ 13
Cleaning ..................................................................................... 13
jXbc67 - Optional outdoor cover accessory for remote
installation of blower and motor assembly on an
outside wall.
3
