K4C COMPACT-MULTI – INSTALLATION/OPERATION MANUAL
3.3
INSTALLATION CODES
INSTALLATION MUST COMPLY WITH THE REQUIREMENTS OF AUTHORITIES
HAVING JURISDICTION. All local and national codes governing the installation of oil
burning equipment, wiring, and venting must be followed. Some of the applicable codes
are:
CAN/CSA B139
NFPA 31
ANSI/NFPA 90B
ANSI/NFPA 70
CSA C22.1
ANSI/NFPA 211
The latest versions of the above codes, which have been approved for use in the
location of the installation, must be used.
3.4
MULTI - POSITION
The Compact-multi is designed to operate in the conventional upflow mode, in
horizontal mode or as a downflow furnace. The breech is convertible from front to rear
by switching the breech pipe and cover plates. The burner is always installed in an
upright position by four nuts.
3.5
PLACEMENT, VENTING & VENTILATION
Furnace installation should conform to the required installation code for oil-fired
equipment (USA: NFPA 31, Canada: CSA B139).
UPFLOW
DOWNFLOW
HORIZONTAL
K4C Compact-multi
Installation Code for Oil Burning Equipment.
Installation Code for Oil Burning Equipment.
Warm Air Heating and Air Conditioning Systems.
National Electrical Code.
Canadian Electrical Code.
Chimneys, Fireplaces, Vents and Solid Fuel Burning Appliances.
The furnace may be placed on a combustible floor or, if required,
on four rigid blocks. The floor must be strong enough to carry the
weight of the furnace.
Install the plenum and sub base as shown in the illustration
(included with sub base). For furnaces installed on a combustible
floor, ensure that the requirements of the authorities having
jurisdiction are satisfied. The floor must be strong enough to carry
the weight of the furnace.
In suspended horizontal positions use the eyebolts provided in kit
(K4C-KA-0200-00).
supported from below, use 4" long 3/8" UNC bolts as adjustable
legs.
For installations where the furnace will be
4
Feb
-06
