CONTENTS
Please check that you have all the parts in the Alarm Kit as follows:
BATTERY CONNECTOR
(9V DC 6F22 or 6LR61)
STRAIGHT
CROSS
IN
DELAY
BLEEP
JACK PLUG
PRESSURE MAT CARDS (x2) & STICKERS
THE LOGIBLOC GUARANTEE
If by any chance anything is missing or not working properly, please write to us
at the address on the back of this booklet and we will sort things out as soon as
possible. This does not affect your right to return this product to where you bought
it from under the retailer's usual terms and conditions.
4
WHAT THE LOGIBLOCS DO
BATTERY CONNECTOR
(9V DC 6F22 or 6LR61)
This brings the power from the battery to make the Logiblocs
work. Plug it in to the CROSS or wherever there is a space
STRAIGHT
This is the basic LOGIBLOC piece that just gets you from
place to place. The light lights up whenever it receives a
signal and it passes it on immediately
CROSS
This acts as a cross-roads for all
Logiblocs and lets you turn corners.
DELAY
Logiblocs have several different types of delay.
A delay waits for a bit before sending the signal on.
This one stays on for about 10 seconds once it has
been triggered. Useful for keeping an alarm on, or
for just slowing things down!
IN
When the two wires of the Jack Plug are
joined together the IN block triggers any other
block that is connected to it
BLEEP
When a signal gets to the
BLEEP it makes a noise.
