To assist you in your service activities, this manual explains the main characteristics of the 2006 PRIUS, in
particular providing a technical explanation of the construction and operation of new mechanisms and new
technology used.
This manual is divided into 3 sections.
1. Introduction - Changed features and model line-up are explained.
2. New Features - Technical explanation of the construction and operation of each new system and
component.
3. Appendix - Major technical specifications of the vehicle.
CAUTION, NOTICE, REFERENCE and NOTE are used in the following ways:
CAUTION
NOTICE
REFERENCE
NOTE
For detailed service specifications and repair procedures, refer to the following Repair Manuals:
" 2006 PRIUS Repair Manual
" 2006 PRIUS Electrical Wiring Diagram
All information contained herein is the most up-to-date at the time of publication. We reserve the right to make
changes without prior notice.
2005
TOYOTA MOTOR CORPORATION
All rights reserved. This book may not be repro-
duced or copied., in whole or in part, without the
written permission of Toyota Motor Corporation.
First Printing: Nov. 7, 2005 01-051107-00
FOREWORD
Applicable models: NHW20 series
A potentially hazardous situation which could result in injury if instructions are
ignored.
Damage to the vehicle or components may occur if instructions are ignored.
Explains the theory behind mechanisms and techniques.
Notes or comments not included under the above 3 titles.
Manual Name
Pub. No.
RM01R0U
EM01R0U
