Japan CBM CAL TP07 Instruction Manual

CAL TP07
INSTRUCTION MANUAL
5-68-10, Nakano, Nakano-ku,
Tokyo 164-0001, Japan
Phone: (03) 5345-7860, Fax: (03) 5345-7861
TO-Y0062
SPECIFICATIONS
Reception
Reception frequency
1)GERMANY............ 77.5KHz(DCF77)
2)U.K........................ 60KHz(MSF)
3)U.S.A.................... 60KHz(WWVB)
4)JAPAN.................. 60KHz(JJY)
Automatic reception (maximum two times a day)
Manual reception
Basic functions
Analog part................. Hour/Minute
Digital part
Time......................... Hour/Minute/Sec. (24-hour display or a.m./p.m.)
Calendar................... Month/Date/Day (Auto calender up to 2099)
Alarm ....................... Hour/Min. (24-hour display or a.m./p.m.)
Chime....................... Hourly chime
About 1,000 km
Stop watch ............... Up to 24 hours
Dual time.................. Hour (24-hour display or a.m./p.m.)
EL Backlight Los Angeles Los Angeles Los Angeles
Battery life .................. About 2 years
Battery........................ CR2016x1
NAMES OF PARTS
MODE= * The indicated reception area is for your reference only. Sometimes you cannot receive radio waves
even within the zone shown in the figure.
=ADJUST
How to successfully receive radio waves
• It may be difficult to receive radio waves when metal shielding blocks the watch. When
=LIGHT
RECEIVE=
inside a ferroconcrete building etc., try to place the watch near a window that is as close
as possible to facing the radio wave station.
• Try not to move the watch during radio wave reception.
[TIME MODE] [CALENDAR MODE]
• Good reception can be achieved if you aim the reception antenna (on the upper side of
Zone code Month Date
the watch) toward the radio wave station.
Country code
• You can check signal strength by looking at the reception mark that is displayed during
PM mark
Alarm
radio wave reception. If you find a place and a direction to aim the watch in advance that
AM mark
Chime
has stable reception, that will help to get a good connection.
Summer
Sec.
mark
Day
Reception level indicator
Hour
Reception mark Weak radio waves
Minute
CAUTION !
* The watch may fail to receive radio waves or may receive them inaccurately near (within
Before using, be sure to set the "COUNTRY AND TIME ZONE".
10km from) the standard radio wave station. In this case, change the direction of the
For setting of the "COUNTRY AND TIME ZONE", see
antenna by 45 - 90 degrees or receive radio waves again at a place far (10km or farther)
"7.COUNTRY AND TIME ZONE SETTING AND SUMMER TIME
from the standard wave station.
ON/OFF" at right.
* Sometimes when the watch indicates strong radio wave reception, it still may not be able
to receive a signal due to surrounding environmental interference such as electrical
RADIO WAVE CONTROLLED WATCH
noise.
About this radio wave controlled watch
* The maximum time required to receive a complete signal can be up to 13 minutes. It may
This watch receives calibration signal and automatically updates the time
change depending on distance from the standard radio wave station, time, season,
and date.
weather, etc.
Transmitter
GERMANY Places where it may be difficult to receive radio waves
Signal code : DCF77 • Places with extremely high or low temperatures.
Location : Mainflingen Germany (located 25 Km southeast of Frankfurt) • Inside ferroconcrete buildings, underground, inside high-rise buildings, in valleys between
U.K mountains, etc.
Signal code : MSF
• Inside vehicles, trains, and airplanes.
Location : Rugby city (located near from London) • Places that tend to have electrical noise such as near high voltage cables, electric train
U.S.A cables, and near airports.
Signal code : WWVB • Near home appliances such as televisions, refrigerators, computers, fax machines,
Location : FortCollins in Colorado (located 100Km north of Denver) inverter fluorescent lights, OA machines, and operating cellular phones.
JAPAN * The watch operates using its built-in quartz accuracy under conditions of poor reception.
Signal code : JJY When it returns to a reception area and receives radio waves, the watch displays the
Location : Mt.Haganeyama (located 45Km southwest of Fukuoka) correct time. The watch operates using its built-in quartz accuracy between signal
The signal usually operates 24 hours of a day, but it may be temporarily reception cycles.
interrupted for maintenance and lightning cuntermeasure.
AUTOMATIC RECEPTION
Radio wave reception zone
This watch can receive radio waves within a radius of about 1,000km from If you receive radio waves properly, the time and date are adjusted automatically.
the standard radio wave station. However, the coverage can vary depending • The watch automatically receives radio waves a maximum of two times a day.
on time, season, weather conditions, local environmental conditions, etc.
AUTOMATIC RECEPTION
Which way to point the watch during reception
3:05AM, 4:05AM
• If one of the two reception attempts is successful, automatic reception won't be
attempted again until the next day.
During the daylight saving time period, if the watch receives the radio waves normally, it
automatically displays the SUM. If it receives the radio waves normally after the DST
period, it automatically displays the ordinary time.
Radio
• Since the DST is automatically corrected, you do not need to correct it, as long as the
wave
watch receives radio waves. In a district where the DST is not applied, however, you are
station
Antenna
required to correct the DST manually.
Flatten the wristband so it doesn't curl
under the antenna.
● SELECTION OF DISPLAY
TIME
CALENDAR
About About About
1,000 km 1,000 km 1,000 km
London London London
ALARM
Berlin Berlin Berlin
About About About
1,000 km 1,000 km 1,000 km
CHIME
STOP WATCH
DUAL TIME
New York New York New York
Sendai Sendai Sendai
Chicago Chicago Chicago
Tokyo Tokyo Tokyo
Nagoya Nagoya Nagoya
Denver About SUMMER TIME
1,000 km Osaka Osaka Osaka
1. MANUAL RECEPTION
Signal reception takes 2~13 minutes.
TIME
2. CONFIRMING RECEPTION
RESULTS
TIME
Strong radio waves
4. ALARM
• ALARM ON/OFF
• ALARM SETTING
Pull
Push
3. MANUAL ADJUSTMENT TIME
AND CALENDAR
Pull
Sec. setting
Sec. set "00"
Min. adjustment
: Increment
Hour adjustment
: Increment
Year adjustment
: Increment
Month adjustment
: Increment
Date adjustment
: Increment
>2Sec.
12H/24H Setting
: Increment
Calendar format
: "Month-date"
"Date-month"
Push
The latest reception was
successful.
Push to complete adjustment.
The hands are moved forward until
they are set to the time of the
digital section.
CAUTION !
Do not pull while the hands are
being moved forward.
The latest reception was failed.
5. CHIME
• CHIME ON/OFF
Alarm off Chime off
Alarm on Chime on
6. STOP WATCH
Hour setting
: Increment
Timing
Min. setting
: Increment
Split
Alarm on
Timing
Stop
Reset
7. COUNTRY AND TIME ZONE SETTING, AND SUMMER 10. CHECK AND RESET HANDS INITIAL POSITION
TIME ON/OFF
Select Summer time ON/OFF.
Select a country and a time zone where you will use this watch.
If the country is selected, the radio wave is decided. The relationship between
the countries and radio waves is shown in Table below.
Pull
Summer time off/on
Selecut countory
EnG USA JPn GER
U.K USA Japan Germany
Select time zone
+0 +1 +2 +3
PS MS CS ES
(Pacific) (Mountain) (Central) (Eastern)
Push
Push to complete setting.
The hands are moved forward
according to the setting.
CAUTION !
Do not pull while the hands
are being moved forward.
COUNTRY CODE TIME ZONE CITY RECEPTION WAVE
1) In the case of correct position("12H00M00S")
U.K 0 London
MSF(60KHz)
1 Berlin
Germany 0 London
DCF77(77.5KHz)
1 Berlin
2
3
Japan TOKYO JJY(60KHz)
U.S.A 0 PS=PACIFIC STD USA.
1 MS=MOUNTAIN STD USA. WWVB(60KHz)
2 CS=CENTRAL STD USA.
3 ES=EASTERN STD USA.
8. DUAL TIME
• DUAL TIME SETTING
2) In the case of incorrect position( not "12H00M")
Pull
Hour setting
: Increment
Push
9. LIGHT
Push
11. BATTERY REPLACEMENT
When the display dims, replace the battery as soon as possible.After battery
replacement, please make sure to short two pattern on module, and reset hands
initial position refering to "10.CHECK AND RESET HANDS INITIAL POSITION".
It may happen that hands slip and change to incorrect position, because of
hard shock, static electricity and after battery replacement and so on.In this
case, we cannot adjust to correct time, even we receive the wave, because
hands initial position is not correct.
Please check and reset hands initial position as following operation.
Correct hands initial position is "12H00M00S".
* Please don't do following operation, when you don't have any problem.
Pull
Push and at the same time.
Max.12 Min.
Hands stops at their initial position.
No need to reset hands initial position.
Push back
Hands move back to original time.
CAUTION !
Please don't pull while hands forwarding.
Need to reset and adjust hands initial position.
Hands stops incorrect position( not "12H00M").
Push or .
To move hands to correct position, push and .
: Fast move
: Push one time then hand moves one step
Push back
Hands move back to original time.
CAUTION !
Please don't pull while hands forwarding.
