MyPBX U100/U200

Installation Guide

Version 1.1
Date: 9th Aug, 2013
Yeastar Information Technology Co. Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MyPBX U100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yeastar Technology MyPBX U100

  • Page 1: Installation Guide

    MyPBX U100/U200 Installation Guide Version 1.1 Date: 9th Aug, 2013 Yeastar Information Technology Co. Ltd...
  • Page 2: Table Of Contents

    3.2.2 Connection of FXO/GSM/UMTS/BRI ports ............9 3.2.3 Connection of FXS ports ..................11 3.2.4 Power Connection ....................11 3.2.5 Overall Flow Chart ....................12 4. MYPBX U100 & U200 BASIC CONFIGURATIONS ................12 4.1 F ................12 ACTORY EFAULTS 4.2 L...
  • Page 3 MyPBX U100/U200 Installation Guide ABOUT MYPBX U100 & U200 MyPBX U100 is a 1U rack mount model IP PBX for up to 25 concurrent calls and 100 users. Internally, it supports network access to ISDN BRI, PSTN, GSM/UMTS and VoIP. High performance, stability and compatibility, combined with rich functionality make MyPBX U100 perfectly suited for your business communication.
  • Page 4: Preparation Before Installation

    Contents of the box Upon receiving MyPBX U100 & U200 gift box, please open the package and check if all the items are supplied as MyPBX U100 & U200 Packing List (See Sheet 1). If there is any problem, please contact your provider.
  • Page 5: Hardware Specifications

    MyPBX U100/U200 Installation Guide 2. Hardware Specifications 2.1 Overview Figure 2-1 MyPBX U100 Figure 2-2 MyPBX U200 5/16...
  • Page 6: Led Indicators And Ports

    MyPBX U100/U200 Installation Guide 2.2 LED Indicators and Ports Figure 2-3 MyPBX U100 & U200 Front Panel Figure 2-4 MyPBX U100 & U200 Rear Panel Indication Status Description Power Power status The power is switched on. The power is switched off.
  • Page 7 USB port For the storage of call recording files. Ethernet ports MyPBX U100 & U200 provides two 10/100 adaptive RJ45 Ethernet ports, marked as LAN and WAN. -LAN port: LAN port is for the connection to Local Area Network (LAN).
  • Page 8: Specifications And Operating Environment

    If placed on the desktop, please ensure it is horizontally placed. 3.2 Installation Instructions After placing MyPBX U100 & U200 in a suitable place, please connect the power adapter and all other cables to complete the installation.
  • Page 9: Connection Of Fxo/Gsm/Umts/Bri Ports

    Ethernet port of a hub, switch or ADSL modem.  LAN Port Connection Connect one end of a network cable to the LAN port of MyPBX U100 & U200, and the other end to any port of company’s LAN switch/router.
  • Page 10 MyPBX U100/U200 Installation Guide Figure 3-2 Inserting the SIM Card Step 3: Connect the antenna Once completed, the No.3 and No.7 LED lights would turn red as below figure: Figure 3-3 Connection of GSM/UMTS ports 3. Connection of BRI ports The BRI port could be connected to the BRI line and the BRI port of a traditional PBX with a BRI RJ45-RJ11 cable.
  • Page 11: Connection Of Fxs Ports

    MyPBX U100/U200 Installation Guide Figure 3-4 Connection of BRI ports 3.2.3 Connection of FXS ports The FXS port could be connected to an analog phone with a phone line. For instance, if No.6 and No.8 connectors are FXS ports, the connection could be depicted as...
  • Page 12: Overall Flow Chart

    MyPBX U100/U200 Installation Guide 3.2.5 Overall Flow Chart Figure 3-6 Overall Flow Chart 4. MyPBX U100 & U200 Basic Configurations 4.1 Factory Defaults MyPBX U200 provides web-based configuration interface for administrator and account user. The user can manage the device by log in the web interface.
  • Page 13 MyPBX U100/U200 Installation Guide same segment with the PC and which can be connected when commit “Ping +MyPBX IP address” command. Start the browser on PC. In the address bar, enter the IP address, click “Enter” button and then you can see MyPBX Web Configuration Panel login page (See Figure 4-1).
  • Page 14: Network Settings

    MyPBX U100/U200 Installation Guide 4.3 Network Settings After logging in the admin configuration interface, generally the first step is to configure the IP address. If both the WAN and LAN ports are connected to the network, their IP addresses need to be configured.
  • Page 15: Making/Receiving Calls

    MyPBX U100/U200 Installation Guide default or newly setup extensions of MyPBX. For more information on terminal configuration, please refer to http://www.yeastar.com/Solutions/SIP_Phones.asp Step 4: Reboot the IP terminal after configuration, and click “Status Monitor”->”Line Status” on the menu bar of MyPBX web configuration interface to check if it has registered successfully to MyPBX.
  • Page 16: Conclusion

    MyPBX U100/U200 Installation Guide 5. Conclusion This Installation Guide only explains the installation and basic settings of MyPBX U100 and U200 for making and receiving calls. For more functionality and advanced settings of MyPBX U100 and U200, please refer to the relative documents as below: “MyPBX U100 Datasheet”...
