digi-MOD INFORMATION SHEET
Changing the Channel name/s and LCN
CHANNEL NAME. Channels can be named by using the Scroll UP key until you reach "CHANNEL NAME"
Use the UP/DOWN scroll keys to change each letter. Click OK to confirm channel name change.
LCN (Logic Channel Number) can be moved from its default position (101, 102, 103 and 104) to a different channel number (e.g. 4, 5,
6, 8) by scrolling up/down in the LCN option for each channel. Once selected, press the "OK" button to lock your channel change.
Setting options – (default first)
Channel Output – 21 UHF (6-69)
FEC (forward error correction) - ¾ (1/2, 2/3, ¾, 5/6, 7/8)
Guard Int - 1/16 (1/2, ¼, 1/8, 1/16, 1/32)
Attenuator - 0 (0 – 20dB adjustable)
Constellation - 64QAM (16QAM)
OFDM Mode - 8K (2K)
Video Input - CVBS (ASI)
Brightness – 128 (adjustable)
Contrast – 128 (adjustable)
Saturation – 128 (adjustable)
Sharpness – 64 (adjustable)
HUE – 128 (adjustable)
CELL ID – 0
STREAM ID – 1000
NETWORK ID – 100
ORG NET ID – 10
NETWORK NAME – RL-NETWORK (changeable via menu)
PROGRAM NUMBER – 1000/2000/3000/4000 (changeable via menu)
CHANNEL NAME – CHANNEL-1 (changeable via menu)
LCN – 101 (changeable via menu)

Safety Precautions

• Do not apply power to the DVB-T Single Input Digital IR Modulator until all components have been installed and all wiring has been properly
terminated. Failure to do so may result in damage to the product and void manufacturer's warranty
• Do not attempt to terminate, change or un-install any wiring without first unplugging Power Adapter from the DVB-T Single Input Digital IR
Modulator
• Do not expose any component to moisture. Doing so can create electrical hazards or render the component unusable. Exposure to moisture will
also void the warranty on the system.
• This modulator is powered with a voltage of 12 VDC. The power supply voltage must not exceed this, otherwise this modulator could suffer
irreparable damage and subsequent invalidation of the warranty.
Note:
- Do not replace the power supply with a voltage greater than 12 VDC.
- Do not connect the modulator to the power if the power cord is damaged.
- Do not plug the modulator into the mains supply until all cables have been connected correctly.
- Do not cut the cord.
• Avoid placing the modulator next to central heating components and in areas of high humidity.
• Do not cover any modulator elements that could obstruct the ventilation slots and cause overheating.
• If the modulator has been kept in cold conditions for a long time, keep it in a warm room no less than 2 hours before plugging it into the mains.
WARRANTY
Vcomm Pty Ltd states that the warrant that the customer can rely on is that
provided by the manufacturer. In the event of any warranty claim please
contact us and we will forward it to the manufacturer. The manufacturer will
then determine the extent of their liability. This expressly negates, to the
extent possible by Australian law, any warranty reliance on Vcomm Pty Ltd.
®
Radio Frequency Range
DVB-T Single Input Digital IR Modulator
complete with 12V DC 3A Power Supply
RL-DM1000
Vcomm Pty Ltd
ABN: 99 091 281 524
N15275
