resi-linx RL-DM1000 DigiMOD Installation Manual

www.resi-linx.com
DigiMOD INSTALLATION MANUAL
Face Plate
A
®
Connections
A
IN
Video Audio L Audio R
E
Hardware Connection
1. Connect the RCA cable from the video source (eg.
CABLE / PAY TV, DVD, VCR, CAMERA) to the yellow
RCA video 'INPUT' jack
RL-DM1000 Modulator.
2. Connect the RCA cable from the audio source to the red/
white 'INPUT' audio jacks (AudioR, AudioL)
rear of the RL-DM1000 Modulator. Use red and white
jacks for dual input, or either one for single input.
3. Connect the RF output
to the modulator input on the RF Distribution Module
Alternatively, connect the RF output
distribution system or directly to a television set.
4. Slide the Remote Power switch D to 'ON' if connecting
the Modulator to a RL-RF380 Video Hub.
5. Connect IR emitters RL-IR700/800 to the outputs C
on the rear of the RL-DM1000 Modulator. Place the
other end within 25mm of the IR receiver on the AV
source (depending on environmental conditions).
6. Connect the supplied 12V DC Switch Mode power pack
to the power input F .
WARRANTY
Vcomm Pty Ltd states that the warrant that the customer can rely on is that
provided by the manufacturer. In the event of any warranty claim please
contact us and we will forward it to the manufacturer. The manufacturer will
then determine the extent of their liability. This expressly negates, to the
extent possible by Australian law, any warranty reliance on Vcomm Pty Ltd.
B
C
D
IR
OK
RL-DM1000
(Video) on the rear of the
A
A on the
H from the RL-DM1000
H to an existing
Radio Frequency Range
DVB-T Single Input Digital IR Modulator
complete with 12V DC 3A Power Supply
Face Plate
LCD Display
A
IR LED
B
Scroll up / down
C
Enter Button (OK)
D
LED Indicator Input
B C
IR REPEATER
ANT IN
RF OUT
ASI IN
I H

Technical Specifications

INPUT
Video Input
Video Input Level
Video Mode
Audio Input
Audio Input Level
Input Connectors
Input Impedance
OUTPUT
Frenquency Range
Output Level
Output Impedance
Channel Bandwidth
Output Level Adjustment
MER
Connector Type
MODULATION
Video Resolution
Video Compression
Audio Compression
LCN
Carrier
Guard Intervals
Code Rate
Constellations
GENERAL
Power Supply
Consumption
Languages
Dimensions
Weight
RL-DM1000
Connections
Video and Audio Input
A
Not Active
B
IR Repeater
C
Remote Power Switch
D
Screw Holes for Mounting brackets
E
12V DC Power Input
F
Not Active
G
RF Output
H
Antenna Input
I
LED Indicator Input
D
OFF ON (REMOTE) PWR
DC 12V
REMOTE SET UP
G
F E
CVBS
0.7-1.4 V (pp)
PAL / NTSC
Stereo
0.4 - 4.8 V (pp)
Video (RCA) - Audio (RCA)
75
177.5 - 816.5 MHz
μ
85 dB V
75
6,7,8 MHz
15 dB typ.
30 dB typ.
"F" female
PAL 720x576 @ 25fps
MPEG2 MP@ML
MPEG1 Layer ll
Yes
2K/8K
1/4, 1/8, 1/16, 1/32
1/2, 2/3, 3/4, 5/6, 7/8
16 QAM / 64 QAM
12 VDC 3-AMP
1100 MA
English
300mm x 200mm x 47mm
1.660kg
Vcomm Pty Ltd
ABN: 99 091 281 524
N15275
