digi-MOD INFORMATION SHEET
The resi-linx "digi-MOD" range of Digital Modulators comes available in the following three options
RL-DM1000 – Single Channel
RL-DM2000 – Dual Channel
RL-DM4000 – Quad Channel
The "digi-MOD" DVB-T Digital RF Modulation system will allow you to distribute any AV devices (Foxtel, Austar, DVD, CCTV Camera
etc) around the home or business with ease.
The resi-linx "digi-MOD" comes with the following factory pre-sets
Output Channel
Attenuation
Constellation
FEC
Guard Interval
Channel Region
Network Name
Channel Name
Video Input
Video Standard
Before you start installing the digi-MOD, you should perform a "Factory Default"
In order to do this, please follow the below steps -:
• Power Up the digi-MOD, wait until the booting process is complete
• Once complete, use the Scroll up/down Key to reach "Default Config" in the menu. Once "Default Config" is located – press
the "OK" button
• Then power down the digi-MOD by removing the power lead
• Wait 5 seconds and the re-connect the power supply
Once the unit has completed its booting process, enter the menu by selecting the "OK" button
• The LCD screen will now display "Advanced Menu Output Channel" - select the "OK" button
• The LCD screen will now display "Output Channel 21" with the frequency in MHz. In some TV sets Channel 21 in not available, so
it is recommended to change this to appropriate available output channel to suit your installation (40, 50, 60 etc.)
• Once you have scrolled and selected a channel number, Select "OK" to lock in the change
• Then use the UP scroll button until the LCD display reads "Advanced Menu EXIT"
• Select "OK", the LCD will now read "EXIT, EXIT Menu". Select "OK"
• The LCD display will now show "Running"
• The digi-MOD unit is now ready to have sources connected.
• Auto Scan for Channels on the TV set with the digi-MOD connected and powered
• Sources for selected digi-MOD Channel selection, (e.g. channel 40), are found on TV channels 101 (changeable via menu – see
below).
• If the digi-MOD is powered down, there is no need to reconfigure. All settings will remain unless a factory default is done.
• If you are connecting via ASI, simply go to the 'Video Input' option in the desired input and change from CVBS to ASI. Allow up to
70 seconds for the Modulator to detect the ASI Input and lock it in.
WARRANTY
Vcomm Pty Ltd states that the warrant that the customer can rely on is that
provided by the manufacturer. In the event of any warranty claim please
contact us and we will forward it to the manufacturer. The manufacturer will
then determine the extent of their liability. This expressly negates, to the
extent possible by Australian law, any warranty reliance on Vcomm Pty Ltd.
®
21
0
QAM64
3/4
1/16
Australia
RL-NETWORK
CHANNEL - 1
CVBS
PAL
Radio Frequency Range
DVB-T Single Input Digital IR Modulator
complete with 12V DC 3A Power Supply
RL-DM1000
