Part No. MFL39433003
INSTALLATION INSTRUCTIONS
INSTRUCCIONES DE INSTALACIÓN
Microwave Hood Combination
Combinación Microondas Campana
Sears, Roebuck and Co., Hoffman Estates, IL 60179
www.sears.com
Advertisement
Table of Contents
Related Manuals for Kenmore 721.85062
Summary of Contents for Kenmore 721.85062
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS Models/Modelos INSTRUCCIONES DE INSTALACIÓN 721.85062 721.85063 721.85064 721.85069 Microwave Hood Combination Read and save these installation instructions. Combinación Microondas Campana Lea y guarde estas instrucciones de instalación Part No. MFL39433003 Sears, Roebuck and Co., Hoffman Estates, IL 60179... -
Page 2: Your Safety First
YOUR SAFETY FIRST BEFORE YOU START • Proper installation is the installer's responsibility! - Read the entire manual before you begin. - The model number label is located on the oven front of oven behind doon See Figure 1. - Mounting plate is located on back side of microwave oven. See Figure 2. BE SURE TO READ THE FOLLOWING SAFETY INSTRUCTIONS: Model Number Label Mounting Plate... -
Page 3: Excessive Microwave Energy
YOUR SAFETY FIRST • THIS APPLIANCE MUST BE GROUNDED! - If there is an electrical short circuit, grounding reduces the risk of electrical shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. - Page 4 YOUR SAFETY FIRST • MAKE SURE YOU HAVE ENOUGH SPACE AND SUPPORT. - Mount the oven against a flat, vertical wall, so that it is supported by the wall. The wall should be constructed of minimum 2" x 4" wood studding and 3/8" thick drywall or plaster/lath. - ATTACH AT LEAST ONE of the two lag screws supporting the oven to a vertical, 2"...
-
Page 5: Parts, Tools, Materials
PARTS, TOOLS, MATERIALS THE FOLLOWING PARTS ARE SUPPLIED WITH THE OVEN: NOTE: Depending on your ventilation requirements, you may not use all of these parts. Damper/duct connector One power cord clamp and (for roof vented or wall vented installation). One dark-colored mounting screw (to hold the power cord). - Page 6 PARTS, TOOLS, MATERIALS YOU WILL NEED THE FOLLOWING TOOLS AND MATERIALS FOR THE INSTALLATION: Carton or other heavy material for covering the counter top. Clear tape Stud finder (for taping the templates to the wall). Saber saw Keyhole saw (for the power cord hole). (for cutting vent holes for roof or wall venting).
-
Page 7: Step 1 : Prepare The Electrical Connections
STEP 1 : PREPARE THE ELECTRICAL CONNECTIONS WARNING AVOID ELECTRICAL SHOCK! THIS APPLIANCE MUST BE GROUNDED! 1. Locate the grounded electric outlet for this oven in the cabinet above the oven, as shown in Figure 5. Upper Cabinet NOTE: The outlet should be on a circuit dedicated to the microwave oven (120V, 60Hz., AC only) with a 20A fused electrical supply. -
Page 8: Step 2 : Prepare The Venting System
STEP 2 : PREPARE THE VENTING SYSTEM NOTE: The ductwork you need for outside ventilation is not included with your oven. The standard ductwork fittings and length are shown in Figure 10, page 9. WARNING THIS OVEN MUST BE PROPERLY VENTED! You may vent your oven in one of three ways. -
Page 9: Standard Fittings
STEP 2 : PREPARE THE VENTING SYSTEM STANDARD FITTINGS NOTE: If the existing duct is round, you must use a rectangular-to-round adapter, with a rectangular 3" extension duct installed between the damper assembly and the adapter to prevent the exhaust damper sticking. -
Page 10: Remove The Mounting Plate
STEP 3 : PREPARE THE VENTING BLOWER WARNING • To avoid risk of property damage, unplug the microwave oven or disconnect power at source by removing fuse or throwing circuit breaker. • To avoid risk of personal injury, wear protective gloves when handling mounting plate. DO NOT PULL OR STRETCH THE BLOWER WIRING! Pulling and stretching the blower wiring could result inelectrical shock. -
Page 11: Step 3 : Prepare The Venting Blower
STEP 3 : PREPARE THE VENTING BLOWER 4. Reassemble the blower wire. See Figure 15. 5. Rotate the unit so that the exhaust ports face the rear of the cabinet. See Figure 17. When you insert blower unit, blower wire must be like F�gure 16. 6. -
Page 12: Step 4 : Prepare The Wall And Upper Cabinet For Installation
STEP 4 : PREPARE THE WALL AND UPPER CABINET FOR INSTALLATION WARNING To avoid personal injury or property damage, do not attempt to install this microwave oven if you cannot find a wall stud. MEASURE AND TACK / TAPE UP THETEMPLATE 1. -
Page 13: Drill The Holes In The Wall And Upper Cabinet
STEP 4 : PREPARE THE WALL AND UPPER CABINET FOR INSTALLATION WARNING To avoid risk of personal injury, electrical shock or death: • Note where electrical outlets and electrical wires are before you drill into the wall. • Locate and disconnect power to any electrical circuits that could be affected by installing this oven. - Page 14 STEP 5 : INSTALL THE MOUNTING PLATE TO THE WALL THE OVEN MUST BE CONNECTED TO 3/16" Hole on Studs AT LEAST ONE WALL STUD 3/4" Hole on Dry wall Only 1. Draw a vertical line on the wall at the center of the Minimum 66"...
- Page 15 STEP 5 : INSTALL THE MOUNTING PLATE TO THE WALL FOR WALL-VENTING • Make the box cutout for the rear wall duct. - 1 piece mounting plate: Using a pencil, put dots through slots F and G, and through holes H and I. Remove the mounting plate and draw lines extending through the points.
-
Page 16: Step 6 : Attach The Oven To The Wall
STEP 6 : ATTACH THE OVEN TO THE WALL WARNING To avoid risk of personal injury or property damage, use will need two people to install this microwave oven. 1. Carefully lift microwave oven and hang it on support tabs (See Figure 28) at the bottom of the Power cord mounting plate. - Page 17 STEP 6 : ATTACH THE OVEN TO THE WALL 5. Roof vented installation: See Figure 34. Install ductwork through the vent opening in the Damper upper cabinet. Complete the venting system through the roof according to the method needed. See “PREPARE THE VENTING SYSTEM” STEP 2. Use caulking to seal exterior roof opening around the exhaust cap.
- Page 18 MEMO...
- Page 19 MEMO...
- Page 20 Impreso en China...
