M2 HFTB436CP42-2X2 Assembly Manual

SPECIFICATIONS:
Model ........................................ HFTB436CP42 2X2
Band .......................................... 70M
Antenna ..................................... 436CP42 2X2
T-Brace...................................... Y
Cross Boom Dia ...................... 2.0"
Wind Load w/o Ant.. .................. 3.05 SQ FT.
FEATURES
:
M2 has been a leader in high performance antennas since it started back in 1984. In addition
to specialized antenna designs, we also developed a diverse line of multiple antenna support struc-
tures (loosely referred to as H frames) to maintain that high level of performance. Just like the an-
tenna, the support structure becomes nearly as complex and varied. All antennas have a defined
near field size and shape and in order to achieve maximum "array performance", the support struc-
ture must accommodate the careful coupling of these near fields.
In many cases the support structure, has to meet special customer requirements like size, weight,
wind speed or area, and weather issues. Our standard H frames then are a composite of these fea-
tures that should satisfy most customer needs. We enjoy discussing your needs and offering our
opinion regarding what best can meet your situation.
M2 Antenna Systems, Inc. 4402 N. Selland Ave. Fresno, CA 93722
M2 Antenna Systems, Inc.
Model No: HFTB436CP42-2X2
Tel: (559) 432-8873 Fax: (559) 432-3059 Web: www.m2inc.com
©2011 M2 Antenna Systems Incoporated
FRONT OF SYSTEM
Weight........................................ 23 LBS
A Dim ......................................... 68"
B Dim ......................................... 72"
C Dim......................................... 93"
D Dim......................................... 36"
.
REAR OF SYSTEM
