Summary of Contents for JK Audio RemoteMix 3.m
- Page 1 RemoteMix 3.m Phone LIne Hybrid and Telephone Handset Interface for Remote Broadcasts Users Guide JK Audio , Inc.
- Page 2 Connections RemoteMix 3.m is a professional audio mixer designed to work on any standard analog telephone line or simply unplug the handset on most PBX or digital telephones and connect to the built-in universal handset interface. It can also connect to many cellular telephones using a fax/modem adapter available from your cellular telephone manufacturer.
- Page 3 PBX, ISDN, or a key telephone system, You can use the built-in handset interface. Simply disconnect the handset from the coily cord and plug the cord into the RemoteMix 3.m PBX Handset Interface Jack. Now select the handset type on the 3.m position switch.
- Page 4 The speaker switches off when the microphone button is pushed on to prevent feedback. Ringer RemoteMix 3.m has an internal ringer for incoming calls. This can be turned off using the switch on the side of the unit.
- Page 5 Operating (Continued) Handset Jack The handset jack on the right side of RemoteMix 3.m allows you to plug in a telephone handset and quickly set up a call before you set up your microphones and headphones. The handset microphone volume is adjusted using the Line In knob. The earpiece volume is adjusted using the Headphone level knob.
- Page 6 We also provide a high quality, regulated AC to DC adapter to power RemoteMix 3.m when AC power is available. Simply plug it into the back of RemoteMix 3.m and plug the transformer into a 110 VAC wall outlet. When the power connector is inserted into the jack, the batteries are bypassed.
- Page 7 From Phone or Headphones volume control depending on which method you are using to monitor the receive signal. On the back of RemoteMix 3.m, below the words Null Adj., there is a hole for a small flat blade screwdriver. This is a 10-turn potentiometer to allow for very sensitive adjustments.
-
Page 8: Specifications
Specifications Inputs: Line: Connector RCA phono Jack Input Impedance 20 k ohms Level 250 mV RMS (-10 dBm nom.) Microphone: Connector Female XLR Input Impedance 1000 ohms Mic / Line: Line = -30dB from microphone gain. Handset: Modular 4pin/4wire handset jack Electret / dynamic microphone bias. -
Page 9: Fcc Registration
FCC Registration Your new JK Audio product has been registered with the Federal Communications Commission (FCC). This product complies with the standards in Part 68 of the FCC rules. Connection and use with the nationwide telephone network The FCC requires that you connect this telephone equipment to the national telephone network through a USOC RJ-11C modular telephone jack. - Page 10 FCC. Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper functioning of your JK Audio product. If such changes are planned, you'll be notified by your telephone company.
-
Page 11: Fcc Part 15 Compliance
Changes or modifications not expressly approved by JK Audio can void the user's authority to operate the equipment. -
Page 12: Warranty
Warranty RemoteMix 3.m is covered by a 2 year warranty to be free from defective workmanship and materials. In the event that the RemoteMix 3.m needs repair, you must call us to get an authorization, and then carefully pack and ship it to us. You will pay for shipping to us and we will pay for return back to you, UPS ground.
