- Page 1 RemoteMix 3x4 Multi-Line Telephone Hybrid / Mixer Users Guide JK Audio...
- Page 2 RemoteMix 3x4 RemoteMix 3x4 is a professional audio mixer designed to handle Television IFB feeds and Radio remote broadcasts. The combination of inputs, outputs, and controls make even the most complicated remote a simple success. It works with any standard analog telephone line. It can also connect to many cellular telephones using a fax/modem adapter available from your cellular telephone manufacturer.
- Page 3 IFB From 4 Locations Talent New York D.C. Chicago L.A. Radio Remote Broadcast Station Talent IFB Feeds Remote Call-in Talk Show Talent Producer Callers Phone line to Studio...
- Page 4 Five Sections (continued) Headphone Section Three separate headphone amplifiers are strong enough to power a pair of headphones or a small desktop speaker. Each has independent source and volume controls. You can choose between Mix, Main phone line, and Monitor phone line.
- Page 5 Hz - 3600 Hz). These are, however, simple hybrid circuits which provide only a minimum return cancellation. Any audio that you send down the phone line, from RemoteMix 3x4, will come back mixed with the signals from the other end of the call.
- Page 6 We also provide a high quality, regulated AC to DC adapter to power RemoteMix 3x4 when AC power is available. Simply plug it into the back of RemoteMix 3x4 and plug the transformer into a 110 VAC wall outlet. When the power connector is inserted into the jack, the batteries are bypassed.
- Page 7 On the bottom of RemoteMix 3x4, there are four holes for a small flat blade screwdriver Try to remember the position of the blade first adjust clockwise, and then b a c k t o t h e o r i g i n a l p o s i t i o n , a n d t h e n counterclockwise.
-
Page 8: Specifications
Specifications Inputs: Microphone: Connector (3) Female XLR Input Impedance 1k ohms Mic / Line: Line = -30dB from microphone gain. Headphone Connector (3) 1/4” mono jack Cue Input: Input Impedance 10 K ohms Level 250 mV RMS Handset: Modular 4pin/4wire handset jack Electret / dynamic microphone bias. -
Page 9: Fcc Registration
FCC Registration Your new JK Audio product has been registered with the Federal Communications Commission (FCC). This product complies with the standards in Part 68 of the FCC rules. Connection and use with the nationwide telephone network The FCC requires that you connect this telephone equipment to the national telephone network through a USOC RJ-11C modular telephone jack. - Page 10 FCC. Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper functioning of your JK Audio product. If such changes are planned, you'll be notified by your telephone company.
- Page 11 Changes or modifications not expressly approved by JK Audio can void the user's authority to operate the equipment.
-
Page 12: Warranty
RemoteMix 3x4 is covered by a 2-year warranty to be free from defective workmanship and materials. In the event that the RemoteMix 3x4 needs repair, you must call us to get an authorization, and then carefully pack and ship it to us. You will pay for shipping to us and we will pay for return back to you, UPS ground.
