EFFIO-E ON SCREEN DISPLAY
INFRARED DOME CAMERA
U S E R M A N U A L
IMPORTANTE:
La limpieza de la cubierta del domo debe realizarse con una franela sueva
humedecida con agua, el uso de solventes o limpiadores agresivos pueden
raspar/dañar la cubierta pudiendo afectar la calidad de la imagen.
IMPORTANT:
The cleaning of the dome cover should be done with a damp cloth, use of
solvents or abrasive cleaners can scratch / damage the housing and can
affect image quality.
R040687B-SYS
1
Advertisement
Table of Contents
Related Manuals for Epcom EYD105VDR
Summary of Contents for Epcom EYD105VDR
- Page 1 EFFIO-E ON SCREEN DISPLAY INFRARED DOME CAMERA U S E R M A N U A L IMPORTANTE: La limpieza de la cubierta del domo debe realizarse con una franela sueva humedecida con agua, el uso de solventes o limpiadores agresivos pueden raspar/dañar la cubierta pudiendo afectar la calidad de la imagen.
-
Page 2: Table Of Contents
Contents 1. SAFETY PRECAUTIONS.................. 3 2. INTRODUCTION ....................4 3. FEATURES ......................5 4. PACKING LIST ....................7 5. NAME and FUNCTION of EACH PART ............8 6. INSTALLATION ....................9 6.1 Camera Installation & Operation ..............9 7. OPERATION ..................... 13 7.1 OSD Framework ................... -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! C AUTIO N : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. It is advised to read the Safety Precaution Guide through carefully before operating the product, to prevent any possible danger. -
Page 4: Introduction
2. INTRODUCTION Clear image quality has been achieved by employing a 1/3” Hi-Res. CCD, which provides a horizontal resolution of 700 TV lines. The camera can be by External Light Sensor; it provides Color image in full light condition (Day) and provides B/W image in low light condition (Night) to reach the best effect. -
Page 5: Features
3. FEATURES High Resolution Excellent Sensitivity CCD Sensor provides high resolution High sensitivity, low smear, high reaching 650~700 TVL with advanced anti-blooming and high S/N ratio. and clear picture quality. Adaptive Tone Reproduction (ATR) Digital Noise Reduction (DNR) ATR is the Single Scan WDR function; With 2DNR enable, it can reduce the it has the other name with Digital WDR, noise to produce extremely clear picture... - Page 6 Lens (External manual focus) Built-in DC-type Vari-Focal lens with OSD (On Screen Display) Setup Menu. ICR / Without ICR. Camera tile setup of up to 16 alphanumeric letters. Mechanism Weatherproofing Housing Design. Application All function can be operated from OSD: AES (Automatic Electronic Shutter), AI (Auto Iris), GC (Gain Control), WB (White Balance), BLC (Back Light compensation), positive/ negative and Horizontal Mirror.
-
Page 7: Packing List
4. PACKING LIST Check to make sure all of the items shown below are included in your product package. If something is missing, contact your dealer as soon as possible. Item Description Item Picture Camera & Bracket Appurtenances Fix retaining screw Countersunk Head Screws for Camera Protection... -
Page 8: Name And Function Of Each Part
5. NAME and FUNCTION of EACH PART To adjust the OSD, remove the dome cover from the main body by gently turning the cover counter-clockwise to unlock and pull free from the main body. The OSD buttons are can be found on the main body of the dome camera. 1~3.OSD Button (Menu): Name Function... -
Page 9: Installation
6. INSTALLATION 6.1 Camera Installation & Operation 1. Removing the Dome Cover Remove the dome cover from the main body by gently turning the cover counter-clockwise to unlock and pull free from the main body. 2. Camera Image Adjustment You can adjust camera to any direction by using Pan, Tilt, and Rotate ... - Page 10 3. Adjusting the Vari-Focal Lens Loosen the Zoom lever counter-clockwise a little, and then rotate the Zoom lever to obtain the best image view. Loosen the Focus lever counter-clockwise a little, and then rotate the Focus lever to obtain the optimum picture quality. Re-tighten the Zoom lever and Focus lever after adjustment.
- Page 11 5. Attaching the Dome Cover After all necessary adjustment has been made reinstall the dome cover to the main body. The black plastic inner liner has a cutout slot for viewing. Reinstall the dome cover and the main body by turning the dome clockwise until it locks in place.
- Page 12 The dome comes with a black plastic inner liner placed within the dome cover. Therefore, after replacing the dome cover rotate the liner so that the cutout slot (hole for viewing) is in the correct position and not blocking the camera lens. 6.
-
Page 13: Operation
7. OPERATION 7.1 OSD Framework Main Menu Display OSD Setup Menu page 1 LENS AUTO↲ SHUTTER/ AGC AUTO↲ WHITE BAL BACKLIGHT ↲ ↲ PICT ADJUST NEXT↲ EXIT↲ SAVE ALL OSD Setup Menu page 2 DAY/ NIGHT AUTO* PRIVACY MOTION DET CAMERA ID LANGUAGE ENGLISH... -
Page 14: Osd Main Menu Description
7.2 OSD Main Menu Description 7.2.1 LENS: MANUAL /AUTO selectable. LENS: MAUNAL Not adjustment LENS: AUTO TYPE：DC MODE：AUTO/ OPEN /CLOSE AUTO SPEED：000~255 AUTO: Camera automatically controls the lens. OPEN: Lens fully open. CLOSE: Lens fully closed. SPEED: Speed of the lens. 7.2.2 SHUTTER/AGC: AUTO / MANUAL selectable. -
Page 15: White Bal
SHUTTER/AGC: MANUAL MODE：SHUT+AGC SHUTTER： MANUAL NTSC：1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 PAL：1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 AGC：6.00、12.00、18.00、24.00、30.00、36.00、42.00、44.80 SHUTTER: Fixed electronic shutter speed. AGC: Fixed AGC gain control. 7.2.3 WHITE BAL ATW / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH LOCK selectable. -
Page 16: Backlight: Blc / Hlc / Off Selectable
7.2.4 BACKLIGHT: BLC / HLC / OFF selectable. BACKLIGHT.: BLC Enable the function of Back Light Compensation, and the detection method is the BLC Smart. BACKLIGHT.: HLC Enable the function of High Light Compensation. 7.2.5 ATR: ON / OFF selectable. ... -
Page 17: Next
7.2.8 NEXT: ↲ Move to MAIN MENU, page 2 7.2.9 EXIT: ↲ Exit OSD to choose the list. 7.2.10 SAVE ALL: When you change the OSD menu settings, before leaving the OSD item option SAVE ALL. Press ENTER key to change the memory settings for the OSD. 7.2.11 DAY/NIGHT：AUTO / DAY / B/W selectable. -
Page 18: Privacy: On / Off Selectable
7.2.12 PRIVACY: ON / OFF selectable. PRIVACY: ON AREA SEL Max. 8 000~244 (NTSC) / 000~288(PAL) BOTTOM 000~244 (NTSC) / 000~288(PAL) 550TVL：000~378 (NTSC)、000~370 (PAL) LEFT 650TVL：000~474 (NTSC)、000~468 (PAL) 550TVL：000~378 (NTSC)、000~370 (PAL) RIGHT 650TVL：000~474 (NTSC)、000~468 (PAL) COLOR TRANSP 0.00 / 0.50 / 0.75 / 1.00 MOSAIC ON / OFF AREA SEL：... -
Page 19: Motion: On / Off Selectable
7.2.13 MOTION: ON / OFF selectable. MOTION DET: ON DETECT SENSE 000~127 BLOCK DISP ON / OFF / ENABLE MONITOR AREA ON / OFF AREA SEL 000~244 (NTSC) / 000~288(PAL) BOTTOM 000~244 (NTSC) / 000~288(PAL) 550TVL：000~378 (NTSC)、000~370 (PAL) LEFT 650TVL：000~474 (NTSC)、000~468 (PAL) 550TVL：000~378 (NTSC)、000~370 (PAL) RIGHT... -
Page 20: Camera Id: On / Off Selectable
7.2.14 CAMERA ID: ON / OFF selectable. A B C D E F G H I J K L M N O P Q R S T U V W X Y Z 0 1 2 3 4 5 6 7 8 9 - ! ” # $ % & ’ Each User Font ( ) _ ‵... -
Page 21: Specification
8. SPECIFICATION Model no. EYD105VDR 1/3” Color CCD Ex-View HAD II Image Device (Sony Chipset) NTSC: 976x494 Effective Picture Elements PAL: 976x582 700TVL Horizontal Resolution Minimum Illumination 0.01ux/ F1.2 Day to Night Illumination Under 5 Lux More than 48dB (AGC OFF) - Page 22 MEMO...
