Epcom EYD105FA Instruction Manual

With ir night vision
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual

Dome Camera

with IR Night Vision
Instruction Manual
R040687/2-SYS

Advertisement

loading
Need help?

Need help?

Do you have a question about the EYD105FA and is the answer not in the manual?

Questions and answers

Related Manuals for Epcom EYD105FA

Summary of Contents for Epcom EYD105FA

  • Page 1: Dome Camera

    Dome Camera with IR Night Vision Instruction Manual R040687/2-SYS...
  • Page 2 IMPORTANTE: La limpieza de la cubierta del domo debe realizarse con una franela sueva humedecida con agua, el uso de solventes o limpiadores agresivos pueden raspar/dañar la cubierta pudiendo afectar la calidad de la imagen. IMPORTANT: The cleaning of the dome cover should be done with a damp cloth, use of solvents or abrasive cleaners can scratch / damage the housing and can affect image quality.
  • Page 3 Thank you for purchasing our product. Before installing this camera, please read this instruction manual carefully to ensure proper use. 1. Safety Precautious CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE.
  • Page 4 3. Feature  Color camera PCB module with 1/3” High Resolution Sensor.  Employs Digital Signal Processor (DSP) chip-set for image control.  High sensitivity, low smear, high anti-blooming and high S/N ratio.  Support functions: Auto Electronic Shutter (AES), Auto Iris (AI), Auto Gain Control (AGC), Auto White Balance (ATW), Back Light Compensation (BLC), Flickerless mode (FL).
  • Page 5 5. Installation & Operation Install Preparation Drill hole in wall if wire needs to go through the wall. 2. Removing the Dome Cover Remove the dome cover from the main body by gently turning the cover counter-clockwise to unlock and pull free from the main body. 3.
  • Page 6 4. Install Camera Use the 4 screws provided to attach the camera and bracket to the ceiling surface or wall.
  • Page 7 5. Camera Diagram Image Adjustment  You can adjust camera to any direction by using Pan, Tilt, and Rotate mechanism.  Pan Base moves by 120° on the whole.  Tilt Base covers total 120° angle (60° to each side). ...

  • Page 8: Specification

    6. Specification According to the camera purchased, select and refer to the appropriate specification below: EYD105FA Model No. 1/3” SONY COLOR Ex-view HAD CCDⅡ Image Device (Sony Chipset) NTSC: 976x494 Picture Elements PAL: 976x582 Day: 650 TVL Resolution Night: 700 TVL 0.01 Lux/F1.2 Color mode...
