  • Page 1: Instruction Manual

    Hidden CCD Camera Instruction Manual R040525A/4-SYS...
  • Page 2 Thank you very much for purchasing our product. Before operating this product, please read this instruction manual carefully to ensure proper use. 1. Safety Precautious CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE.
  • Page 3 3. Feature  Employs Digital Signal Processor (DSP) chip-set for image control.  Pixel number: NTSC=480K/ PAL=570K for ultra high resolution and NTSC=380K/ PAL=440K for high resolution.  High sensitivity, low smear, high anti-blooming and high S/N ratio.  Powerful functions: Auto Electronic Shutter (AES), Auto Iris (AI), Auto Gain Control (AGC), Auto White Balance (AWB), Back Light Compensation (BLC), and Noise Reduction (NR function depends on model type).

  • Page 4: Installation

    5. Installation (1) Use the 3 screws provided to attach the mounting bracket to the surface or wall, assemble all spare parts to the base plate and tighten the camera wingnut . Figure 1 (2) Screw the mounting bracket into the camera mounting post; then adjust the camera to approximate location and tighten the camera wingnut.

  • Page 5: Detector Board

    75-ohm coaxial cable. Insert the AC plug into the AC power socket and the DC plug to the DC Jack. Note: AC adapter is sold separately. 7. DETECTOR BOARD (NOT AVALIABLE FOR EYH003FAP)
  • Page 6 Options Description 1.LED Selector: A. Top + Center w/black cap: Upon Walk-testing: Light blinking (Disadvantages: Easy to identify as a security system.) B. Center + Low w/black cap: No light blinking while detecting. (Advantages: less obvious) (3PINS: Top, Center, Bottom) 2.Sensitivity Adjustment: A.

  • Page 7: Top View

    100¢X TOP VIEW SIDE VIEW feet feet Wide angle lens up to 100°, coverage areas to 30 x30 feet.  Provide 64 beans in 3 layers. ...

  • Page 8: Specification

    8. Specification According to the camera purchased, select and refer to the appropriate specification below: EYH003FAP Model no. 1/3” Color CCD Super HAD II (Sony Chipset) Image Device NTSC: 976 x 494 Picture PAL: 976 x 582 Elements Resolution 650TVL Min Illumination 0.02Lux/ F1.2...
