Epcom EFFIO-P User Manual

Wide dynamic range infrared dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

EFFIO-P

Wide Dynamic Range

Infrared Dome Camera
U S E R M A N U A L
IMPORTANTE:
La limpieza de la cubierta del domo debe realizarse con una franela sueva
humedecida con agua, el uso de solventes o limpiadores agresivos pueden
raspar/dañar la cubierta pudiendo afectar la calidad de la imagen.
IMPORTANT:
The cleaning of the dome cover should be done with a damp cloth, use of
solvents or abrasive cleaners can scratch / damage the housing and can
affect image quality.
VER 1.0, P/N: R040195A-SYS1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EFFIO-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Epcom EFFIO-P

Summary of Contents for Epcom EFFIO-P

  • Page 1: Wide Dynamic Range

    EFFIO-P Wide Dynamic Range Infrared Dome Camera U S E R M A N U A L IMPORTANTE: La limpieza de la cubierta del domo debe realizarse con una franela sueva humedecida con agua, el uso de solventes o limpiadores agresivos pueden raspar/dañar la cubierta pudiendo afectar la calidad de la imagen.

  • Page 2: Table Of Contents

    Contents 1. SAFETY PRECAUTIONS.................. 2 2. INTRODUCTION ....................3 3. FEATURES ......................4 4. PACKING LIST ....................6 5. NAME and FUNCTION of EACH PART ............7 5.1 OSD Button (Menu): ................7 6. INSTALLATION ....................8 6.1 Camera Installation & Operation ............8 6.2 Connect to Monitor ................

  • Page 3: Safety Precautions

    1. SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! C AUTIO N : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. It is advised to read the Safety Precaution Guide through carefully before operating the product, to prevent any possible danger.

  • Page 4: Introduction

    2. INTRODUCTION This WDR digital image camera uses a high sensitive color Sony 1/3” interline transfer Charge Coupled Device (CCD) image sensor, producing pictures reaching 650 lines of horizontal resolution. Super Wide Dynamic Range technology, capturing both high-luminance and low luminance subjects under these type of shooting conditions.

  • Page 5: Features

    3. FEATURES High Resolution Excellent Sensitivity CCD Sensor provides high resolution High sensitivity, smear, high reaching 650 TVL with advanced and anti-blooming and high S/N ratio. clear picture quality. Wide Dynamic Range (WDR) and Digital Noise Reduction (DNR) Adaptive Tone Reproduction High-quality WDR and ATR functions, 2D/ 3D DNR, realize the clear image at perfectly shows the image details...
  • Page 6 Lens (C/CS Mount) Extra Connection Built-in DC-type Vari-Focal lens with Control the camera easy by keyboard/PT ICR. Driver via RS485 interface; Connect the extra Alarm out to combine with the Motion Detection function. Image Control OSD (On Screen Display) Setup Menu. Performance: 16x digital zoom, freeze Camera tile setup of up to 16 alphanumeric image, positive/ negative image, mirror...

  • Page 7: Packing List

    4. PACKING LIST Check and make sure all the items shown below are included in your product package. If something is missing, contact your dealer as soon as possible. User’s Manual Dome (IR Type) Indoor IR Outdoor IR Dome Dome Power Adaptor (option) Accessories Indoor IR...

  • Page 8: Name And Function Of Each Part

    5. NAME and FUNCTION of EACH PART 5.1 OSD Button (Menu): Name Function Digital Zoom-Out or Up direction button DOWN Digital Zoom-In or Down direction button Increase Value (＋) RIGHT Decrease Value (－) LEFT ENTER Enter or Exit setup MENU To adjust the OSD, remove the dome cover from the main body by gently turning the cover counter-clockwise to unlock and pull free from the main body.

  • Page 9: Installation

    6. INSTALLATION 6.1 Camera Installation & Operation 1. Removing the Dome Cover Remove the indoor dome cover from the main body by gently turning the  cover counter-clockwise to unlock and pull free from the main body.  Remove the outdoor dome cover using the provided L-Wrench, loosen the screws securing the temper-resistant housing cover (with the screws still attached on the cover) to unlock the cover from the main body.
  • Page 10 <Note> This product is not suitable for horizontal 360° continuous rotation. 3. Adjusting the Vari-Focal Lens Loosen the Zoom lever counter-clockwise a little, and then rotate the Zoom  lever to obtain the best image view. Loosen the Focus lever counter-clockwise a little, and then rotate the Focus ...
  • Page 11 4. Attaching the Dome Cover  After all necessary adjustment has been made reinstall the dome cover to the main body.  Reinstall the indoor dome cover and the main body by turning the dome clockwise until it locks in place. To prevent unpredictable damage and burglary, lock-up the dome by using the countersunk head screw.

  • Page 12: Connect To Monitor

    6.2 Connect to Monitor Connect the Video-out port of the camera to a monitor. As the connecting method varies depending on the instrument, therefore refer to the manual supplied with the instrument for more information.

  • Page 13: Connect The Power

    6.3 Connect the Power  Connect the indoor dome video output to a 75 Ohms type coaxial cable and the DC-Jack or AC/ DC-Terminator to the power source. <Note> Power adapter is sold separately.  Connect the outdoor dome video output to a 75 Ohms type coaxial cable and the DC-Jack or AC/ DC-Terminator to the power source.

  • Page 14: Connection Layout

    <Note> Power adapter is sold separately. 6.4 Connection Layout To connect the keyboard and alarm, please follow the setup guide shown below:...

  • Page 15: Communication Setting

    6.4.1 Connecting the Keyboard PELCO Keyboard (or compatible) Installation RS-422 interface is used for communicating PELCO keyboard. Refer to Fig. 1; connect R+ of the camera to T+ of the PELCO keyboard. Connect R- of the camera to T- of the PELCO keyboard. User could adjust Camera ID via rear panel keys or via remote commands.
  • Page 16 Fig.1 6.4.2 Connecting the Alarm Alarm Installation Connect GND and AL of the camera to the GND and AL of the alarm. <Note> The alarm is triggered by motion detection.

  • Page 17: Operation

    7. OPERATION 1. Mount the camera on the mounting bracket by using the hole on the top or bottom of the camera, and by using the enclosed mounting block, secured by 2 screws. 2. Connect the video output to the monitor or other video device via a 75 Ohms type coaxial cable.

  • Page 18: System Setup

    8. SYSTEM SETUP 8.1 Digital Zoom Operation: Under normal display (before entering the OSD menu), use (T)/ (W) button to control the digital zoom (zoom range: 1 x ~ 16 xs). 8.2 OSD (On Screen Display) Main Menu Display MAIN MENU VERSION ...

  • Page 19: Sub Menu Description

    8.3 Sub Menu Description 8.3.1 EXPOSURE Setup EXPOSURE  SHUTTER MANUAL BACKLIGHT SHUTTER AGC  NOISE REDUCTION IRIS SPEED DEFAULT RETURN (1) WDR: This function is used for changing the AE mode.  Set the mode to Normal, ATR-EX, WDR ...
  • Page 20  Back Light Compensation (BLC) is ON: BLC could emphasize the luminance of the BLC Area according to the BLC Level.  Manual/ SMART BLC: MANUAL The Manual BLC function enables manually setup of BLC on parts of image or the whole image. SMART The Smart BLC function through DSP, according to the backlight environment auto calculates the backlight compensation to assure...
  • Page 21 EXPOSURE BLC LEVEL AREA SELECT CENTER BOTTOM LEFT RIGHT DEFAULT RETURN> BLC LEVEL SET  This function is valid to BLC MANUAL mode.  Adjust the level from 0 MIN to 15 MAX. BLC AREA SET  This function is valid to BLC MANUAL mode. ...
  • Page 22 (4) SHUTTER AGC: Adjust the level from LOW*/ MIDDLE/ HIGH. (5) NOISE REDUCTION: Set the 2D-NR to OFF/ LOW/ MID-LOW/ MIDDLE*/ MID.HIGH/  HIGH. Set the 3D-NR to OFF/ LOW/ MID-LOW/ MIDDLE*/ MID.HIGH/  HIGH. (7) IRIS SPEED: Set the IRIS SPEED from 0 ~ 31* ~ 255. ...
  • Page 23 AUTO  DAY TO NIGHT Adjust the threshold level from 156 to 895 to switch mode from day  to night (Default Setup: 500*). When SHUTTER AGC is set to LOW, the threshold level will be  from 349~895 When SHUTTER AGC is set to MID, the threshold level will be ...

  • Page 24: Auto White Balance

    8.3.4 AUTO WHITE BALANCE Setup: AUTO WHITE BALANCE MODE DEFAULT RETURN (1) AWB MODE: This function is used for changing the WB mode.  Set the mode to ATW*, Indoor, Outdoor, Manual, Push Lock,  Anti-CR. ATW: WB color temperature range = 2500°K ~ 8000°K. ...
  • Page 25 8.3.5 PRIVACY Setup: PRIVACY AREA SELECT 1/15 MODE POSITION COLOR TRANSP. MOSAIC DEFAULT RETURN (1) AREA SELECT:  Select the mask from 1 to 15.  The number is which current setting of mask. (2) MODE: Adjust the mode to OFF* or ON. (3) POSITION: ...
  • Page 26 8.3.6 EFFECT Setup: EFFECT  DISPLAY  COLOR VIEW MODE CRT> POSI/ NEGA POSI MIRROR FREEZE SYNC  IRIS ADJ LANGUAGE ENGLISH DEFAULT RETURN EFFECT→ [DISPLAY] DISPLAY TITLE ID ON CAMERA ID DISP ZOOM RATIO DISP MOT/ ALM DISP AE/ AWB DISP DEFAULT RETURN...
  • Page 27  ZOOM RATIO DISP SET Select the mode ON*/ OFF.  MOT/ ALM DISP SET Select the mode ON*/ OFF.  AE/ AWB DISP SET Select the mode ON*/ OFF.  DEFAULT Return to default setup.  RETURN Return to previous status. Normal CAMID:1 ZOOM CAMERA...
  • Page 28 (4) POSI/ NEGA  This mode is used for changing the color and luminance to negative.  Select the mode NEGA or POSI*. (5) MIRROR  This function allows mirroring the image vertically, horizontally, or both.  Select the mode OFF*, V-FLIP, H-FLIP, or HV-FLIP. (6) FREEZE ...
  • Page 29 (11) DEFAULT: If default is entered, all EFFECT functions will be changed to the factory default setting. (12) RETURN: Exit the EFFECT setup menu and return to the main menu. <Note> Do not precede IRIS ADJ function when replacing Manual Lens. 8.3.7 MOTION DETECT setup: MOTION DETECT BLOCK DISP...
  • Page 30 8.3.8 COMMUNICATION setup: COMMUNICATION CAMERA ID BAUD RATE 9600 PARITY NONE DEFAULT RETURN (1) CAMERA ID:  To connect large amount of cameras, identification number is assigned to each camera for camera control (000 ~ 255: total numbers of ID are 256). ...
  • Page 31 8.3.9 EXIT Setup: Exit the OSD menu and enter the normal display. 8.3.10 SAVE ALL Setup:  Saving the current configuration to flash.  Set this function to OFF and nothing will be written. 8.3.11 DEFAULT Setup: If default is entered, all functions will be changed to factory default settings.

  • Page 32: Camera Control Command Protocol

    9. Camera Control Command Protocol (For RS-232, RS-422, and RS-485) 9.1 Communication Format Communication specification (Default) Communication speed: 9600 BPS Start bit: 1 Data bits: 8 Parity: None Stop bit: 1 The communication data format from PC to Camera Data of total 6 bytes is transmitted from PC to camera. Format: Byte1 Byte2...
  • Page 33 The communication data format from Camera to PC Data of total 9 bytes is transmitted from Camera to PC. Format: Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 Byte9 0xC5 Code1 Code2 Code3 Data1 Data2 Data3 Data4 C.S. Description: (Refer to 7.2 PC Command) (a) Byte 1: Camera is realized the protocol comes from PC.

  • Page 34: Pc Command

    9.2 PC Command Exposure Mode Setting Set the mode of Exposure according to AEmodeCNT. PC → Camera 0xC5 0xAA 0x60 AEmodeCNT CAM_ID C.S. Camera → PC 0xC5 0xAA 0x60 AEmodeCNT 0x60 0xXX 0xXX 0xXX C.S. AEmodeCNT: The counter for setting Exposure mode 1.
  • Page 35 White Balance Mode Setting Set the mode of White Balance according to WB_CNT. PC → Camera 0xC5 0xAA 0x65 WB_CNT CAM_ID C.S. Camera → PC 0xC5 0xAA 0x65 WB_CNT 0x65 0xXX 0xXX 0xXX C.S. WB_CNT: This is an index counter to change the mode of White Balance 1.

  • Page 36: Camera Power Off

    Ex. In case of Zoom lens Position = 0x12A & Digital zoom data = 0x10, a. ZP_CNT+1 = 0x01 b. ZP_CNT = 0x2A c. V_MAG = 0x10 Caution: This command is used to set the PRESET mode control. Focus Lens Position Read Read the current value of Focus lens.
  • Page 37 Memorize Zoom Lens Position for External PRESET control Memorize the Zoom lens position into the volatile “Buffer RAM” designated “Buffer RAM Index” for the external PRESET Move control. PC → Camera 0xC5 0x49 PRE_I_ZH ZPL CAM_ID C.S. Camera → PC 0xC5 0x49 PRE_I_ZH ZPL PRE_I_ZH 0xXX 0xXX 0xXX C.S.
  • Page 38 2. FPL: Lower data of position value for the Focus lens. Ex. Memorize 0x21F to the Focus Lens Position in PRESET 3. 0xC5 0x4A PRE_I_FH FPL CAM_ID C.S. 0xC5 0x4A 0x32 0x1F CAM_ID C.S. Memorize Digital Zoom Position for External PRESET control Memorize the Digital Zoom position into the volatile “Buffer RAM”...
  • Page 39 Camera RESTART Restart the Camera’s micro controller (u-COM). PC → Camera 0xC5 0x4F 0x00 0x00 CAM_ID C.S. Camera → PC 0xC5 0x4F 0x00 0x00 0x00 0xXX 0xXX 0xXX C.S. Digital Zoom Power Adjust Adjust Digital Zoom Max Power. PC → Camera 0xC5 0x52 INDEX 0x00 CAM_ID C.S.
  • Page 40 Key Action Perform the Key action according to the data of "KEY_NUM". Caution: After using the Key action, the camera has to be notified by the key action code KEY_NUM = “KN_STOP“. PC → Camera 0xC5 0x5F KEY_NUM 0x00 CAM_ID C.S. Camera →...
  • Page 41 Auto Back Light Mode ON/ OFF control Change the Auto Back Light Mode of the camera. PC → Camera 0xC5 0xAA 0x6D MODE CAM_ID C.S. Camera → PC 0xC5 0xAA 0x6D MODE 0x6D 0xXX 0xXX 0xXX C.S. 1. In case of MODE = 0x00, the Auto Back Light Mode of camera becomes OFF mode.
  • Page 42 FOCUS Mode Setting Switch the FOCUS mode to AUTO, MANUAL or PUSH_AUTO according to the data of “MODE”. PC → Camera 0xC5 0xAA 0x73 MODE CAM_ID C.S. Camera → PC 0xC5 0xAA 0x73 MODE 0x73 0xXX 0xXX 0xXX C.S. 1. In case of MODE = 0x00, the FOCUS mode becomes “AUTO” mode. 2.
  • Page 43 1. If MODE = 0x01, the PUSH AUTO White Balance state becomes to ON. In this case, White Balance Tracking is activated. 2. If MODE = 0x00, the PUSH AUTO White Balance state becomes to OFF. In this case, White Balance Tracking is stopped. 3.

  • Page 44: Shutter Speed Setting

    1. In case of MODE = 0x01, “Main Menu” OSD is displayed on the screen. 2. In case of MODE = 0x00, MENU OSD is erased on the screen. 3. Otherwise, no action is performed. SHUTTER Speed Setting Set the shutter speed of the camera according to the data of “SSC_CNT”. PC →...
  • Page 45 AGC_CTL: The data for adjusting the AGC level of the camera. Data value range from 0x1C (Minimum AGC Level) to 0xDC (Maximum AGC Level). Caution: This command is valid when the Exposure Mode is “AGC MAN” or “MANUAL”. Function OSD Display Mode Change Change the Function OSD Display Mode of the camera according to the data of “OSD_DISP”.
  • Page 46 SCREEN INVERSION (FULL MIRROR) ON/OFF Setting Switch the SCREEN INVERSION mode to ON or OFF according to the data of “MODE”. The function is for high resolution only. PC → Camera 0xC5 0xAA 0x7F MODE CAM_ID C.S. Camera → PC 0xC5 0xAA 0x7F MODE 0x7F 0xXX 0xXX 0xXX C.S.
  • Page 47 Zoom Tracking PRESET status Read Read the status of the Zoom Tracking PRESET action to judge whether the PRESET action has been completed or performed. PC → Camera 0xC5 0x7F 0x00 0x00 CAM_ID C.S. Camera → PC 0xC5 0x7F 0x00 0x00 Status 0xXX 0xXX 0xXX C.S. 1.
  • Page 48 Reserved. Reserved. Reserved. 0: Auto BACKLIGHT Mode OFF state. 1: Auto BACKLIGHT Mode ON state. Digital Effect status of the Camera Read Command Read the current Digital Effect status of the camera. The data is “DEFT_CON”. PC → Camera 0xC5 0xAA 0x82 0x00 CAM_ID C.S. Camera →...
  • Page 49 Camera → PC 0xC5 0xAA 0x84 0x00 AE_MODE 0xXX 0xXX 0xXX C.S. Explanation of “AE_MODE” data AE_MODE Explanation AUTO Exposure mode. IRIS MAN Exposure mode. AGC MAN Exposure mode. MANUAL Exposure mode. Read the current MWB_CTL data at the Hue White Balance Mode Read the current HUE point adjust data of the Camera at the Hue White Balance Mode.
  • Page 50 Read the IRIS control data Read the current IRIS control value to control IRIS OPEN level. The data is “IRIS_CTL”. PC → Camera 0xC5 0xAA 0x8B 0x00 CAM_ID C.S. Camera → PC 0xC5 0xAA 0x8B 0x00 IRIS_CTL 0xXX 0xXX 0xXX C.S. Read the AGC control data Read the current AGC control value to control AGC level.
  • Page 51 Camera → PC 0xC5 0xAA 0x8F 0x00 DZ_MAX 0xXX 0xXX 0xXX C.S. Caution: The data of this command is valid only when the Digital Zoom mode is Explanation of “DZ_MAX” data DZ_MAX Explanation The current Max Power Digital Zoom of the Camera is “x2”. The current Max Power Digital Zoom of the Camera is “x3”.
  • Page 52 0xC5 0x7A INDEX 0x00 CAM_ID C.S. Camera → PC 0xC5 0x7A INDEX 0x00 INDEX 0xXX 0xXX 0xXX C.S. INDEX: The value for indicating the memory position to store the zoom, focus, and digital zoom position value. The range of this value is from 0x00 to 0x7F. Slow Speed Internal Zoom Tracking PRESET Moving control Perform the Zoom Tracking PRESET action to the target zoom position slowly.
  • Page 53 Distance: The value for indicating the object distance range limit that the camera can be focused. 1. In case of “0x00”: Focusing range = From 1 cm To infinite 2. In case of “0x01”: Focusing range = From 10 cm To infinite 3.
  • Page 54 Camera → PC 0xC5 0xAA 0x6F INDEX 0x6F 0xXX 0xXX 0xXX C.S. INDEX: The value, which selects the MENU OSD page or erases the MENU OSD on the screen. 1. In case of INDEX = 0x00, the “Main Menu” OSD is displayed. 2.
  • Page 55 INDEX: This is a value, which selects the sub MENU. 1. In case of INDEX = 0x00, the data of all Sub Menu are initialized. 2. In case of INDEX = 0x01, the data of “Focus Sub Menu” are initialized. 3.
  • Page 56 Back Light Control Mode Setting Command This command sets the back light mode of the camera according to MODE. PC → Camera 0xC5 0xAA 0x9C MODE CAM_ID C.S. Camera → PC 0xC5 0xAA 0x9C MODE 0x9C 0xXX 0xXX 0xXX C.S. 1.
  • Page 57 Red Control Gain Adjust Command This command adjusts the red control gain of the camera. PC → Camera 0xC5 0xAA 0xA4 R_Cont CAM_ID C.S. Camera → PC 0xC5 0xAA 0xA4 R_Cont 0xA4 0xXX 0xXX 0xXX C.S. R_Cont: The value, which adjusts the red control gain of the camera. Red Control Gain Read Command This command reads the current red gain of the camera.
  • Page 58 Camera → PC 0xC5 0x59 0x00 0x00 Distance 0xXX 0xXX 0xXX C.S. Distance: The index value, which indicates the current object distance range that the camera can be focused. 1. In case of Distance = “0x00”, the Focusing range = From 1 cm To infinite 2.
  • Page 59 CHAR Character ‘A’ 0x00 ‘B’ 0x01 ‘C’ 0x02 ‘D’ 0x03 ‘E’ 0x04 ‘F’ 0x05 ‘G’ 0x06 ‘H’ 0x07 ‘I’ 0x08 ‘J’ 0x09 ‘K’ 0x0A ‘L’ 0x0B ‘M’ 0x0C ‘N’ 0x0D ‘O’ 0x0E ‘P’ 0x0F ‘Q’ 0x10 ‘R’ 0x11 ‘S’ 0x12 ‘T’...
  • Page 60 0x03 Select the function OSD that is related to the ZOOM DISP 0x04 Select the function OSD that is related to the User Title. Dark Fade ON (Video Mute) Command This command mutes the video signal out. PC → Camera 0xC5 0xAA 0x54 0x00 CAM_ID C.S.

  • Page 61: Key Code Table

    The status of Camera operation: Bit5 & Bit4 are the flags of Day & Night Control Mode Status Explanation Bit5 Bit4 Camera’s Day & Night Control Mode is “Day & Night DAY Mode”. Camera’s Day & Night Control Mode is “Day & Night NIGHT Mode” Camera’s Day &...
  • Page 62 displaying the MENU, it operates as the “MENU selection scroll up“. Perform Zoom Tracking to WIDE side by slow speed. In case of displaying the MENU, it operates as the “MENU selection scroll KN_WIDE 0x03 down“. Perform Zoom Tracking to WIDE side by high speed. In case of displaying the MENU, it operates as the “MENU selection scroll KN_HWIDE 0x04...
  • Page 63 Use for RS-232C Serial Communication: Scroll down the AGC KN_RS_AGCdn 0x45 level. The AE mode must be “AGC MAN“, or “MANUAL“. Use for RS-232C Serial Communication: Scroll up the Brightness level. The AE mode must be “AUTO”, “IRIS MAN“, or “AGC KN_RS_BRTup 0x46 MAN“.

  • Page 64: Specification

    10. SPECIFICATION Image Device 1/3" Color Sony Vertical double-Density WD CCD Image Device NTSC: 976 x 494 (H x V) / PAL: 976 x 582 (H x V) Picture Elements Day: 650 TVL, Night: 700 TVL Resolution (0.01)Lux(Day mode), (0.00011) Lux (Night mode) / F1.2 Min.
