Specifications - Compal notebook User Manual

CPU
•
Intel Mobile Merom & Merom ICPM, Socket P, FSB800/667 MHz
•
MAX 4M L2 Cache
•
Dual Core
•
Micro FC-PGA package CPU
Chipset
•
Intel PM965 / Intel GM965
•
667/800 MHz FSB supported
•
ICH8-M
Memory
•
Supports DDR-II 533/667MHz
•
No on-board memory
•
Two SO-DIMM with 256MB/512MB/1GB/2GB modules
•
Upgradable to 4GB memory by two SO-DIMM
•
Easy install from bottom side
Display
•
Supports 15.4" WXGA (1280 x 800) TFT color LCD
•
Supports 15.4" WXGA+ (1440 x 900) TFT color LCD
•
Supports 15.4" WSXGA+ (1680 x 1050) TFT color LCD
Keyboard
• ENE 925Q K/B controller
• 86-US/87-UK/88-JA Key; 12 function keys; 4 cursor keys
• Windows key; Application keys, 19.05mm pitch, 2.5mm stroke, H=5.1mm
Hard Disk Drive (HDD)
•
9.5mm height, 2.5" HDD
•
Up to 160GB capacity
•
Supports SATA 1.5Gb/s
•
5400 RPM
•
Easily removable
