- Page 1 WiMAX Outdoor Router User Manual Version 1.04 Applies to: RUT723, RUT725, RUT735 and RUT738 Suitable for RUT7xx...
-
Page 2: Legal Notice
TELTONIKA Ltd is prohibited. The manufacturer reserves the right to modify the product and manual for the purpose of technical improvement without prior notice. -
Page 3: Table Of Contents
Table of contents LEGAL NOTICE ................................2 ATTENTION ................................. 2 TABLE OF CONTENTS ..............................3 SAFETY INFORMATION ..............................4 DEVICE SERVICE ................................5 PRODUCT OVERVIEW ..............................6 ................................... 6 NTRODUCTION ................................6 ACKAGE CONTENTS ............................... 6 YSTEM REQUIREMENTS HARDWARE INSTALLATION ............................7 ................................ -
Page 4: Safety Information
SAFETY INFORMATION In this section you will be introduced on how to use a WiMAX Outdoor Router safely. You have to be familiar with the safety requirements before using the device! We suggest you to adhere to the following recommendations in order to avoid personal injuries and or property damage. The device is intended for supply from a Limited Power Source (LPS) that power consumption should not exceed 15VA and current rating of overcurrent protective device should not... -
Page 5: Device Service
This automatic two pole protective device disconnects all the associated equipment (fig 1). To disconnect the device plug off the AC-DC power adapter from the wall outlet or power strip. The gap between contacts should be no less than 3mm. 1 Figure: Building installation scheme Device service Signal level of the device depends on the working environment. -
Page 6: Product Overview
PRODUCT OVERVIEW Introduction Teltonika RUT723, RUT725, RUT735 and RUT738 are outdoor routers offering high speed data rate connectivity to the WiMAX networks. Router is compliant with IEEE802.16e-2005 WiMAX Wave 2. 10/100 Base-T interface and integrated DHCP server allow easy connection to any device with Ethernet cable. -
Page 7: Hardware Installation
Hardware installation Connecting device Device has included waterproof RJ45 connector. Use it together with LAN cable and assemble as is shown in the picture below. To connect LAN cable to the router: 1. Plug cable into RJ45 socket 2. Tighten the screw around RJ45 socket 3. -
Page 8: Mounting Device
Mounting device Device pole mounting kit contains these elements: STEP 1 STEP 2 STEP 3 Fix “L” bracket to the router Assemble pole bracket clamp and Adjust right direction and “U” bolt on a pole tighted the nuts. Device position and angle of antenna has big impact on performance. By monitoring Status window in WebUI try to find a location with best signal quality. -
Page 9: Web Gui Overview
Web GUI OVERVIEW In this section you will be briefly introduced to our user interface. Note: we use an intuitive tool tip system in our web user interface which displays additional data for the user. To see this data hover your mouse cursor above the field. Also, if the frame of the field becomes red, it usually means that the data in the field is incorrect, in this case look into red tool tip for more information. -
Page 10: Webui Structure
WebUI structure Our modern web user interface provides you with all the tools needed within the five main pages: Status, Ethernet, Firewall, Administration, About. Status Status page The status page consists of 6 properties that define the current state of the WiMAX Outdoor Router: Uptime –... -
Page 11: Ethernet
Ethernet Ethernet settings page allows the user to change the IP address, net mask and DHCP server settings. IP address IP address settings page IP address – IP address of the router. Netmask–mask used to divide IP address into subnets. DHCP server Dynamic Host Configuration Protocol (DHCP) is a network protocol that enables a server to automatically assign an IP address to a computer from a defined range of numbers configured for a... -
Page 12: Firewall
Firewall Firewall page lets you configure firewall settings to meet your requirements. It includes port- forwarding, MAC filtering and IP filtering Port forwarding Port forwarding is the process of translating the address and port number of a packet to a new destination. -
Page 13: Mac Filtering
Mac filtering MAC filtering is a security access control method used to determine access to the network by physical address. Follow these steps to add a MAC filtering rule: Enable – check to enable the MAC filtering. 2. Press the button. -
Page 14: Ip Filtering
IP filtering IP filtering is a security access control method used to determine access to the network by IP address. Follow these steps to add an IP filtering rule: Enable – check to enable the IP filtering. 2. Press the button. -
Page 15: Demilitarization Zone
Demilitarization zone In computer networks, a DMZ (demilitarized zone) is a computer host or small network inserted as a "neutral zone" between a private network and the outside public network. DMZ page To set up DMZ, click the Enablecheckbox and put in IP address of your destination in the Destination IP text field. -
Page 16: Firmware
Firmware Firmware page To save firmware: click Save firmware to file and at the following dialog browse to the directory you want to place binary file. To update firmware:click Select firmware file and at the following dialog window select firmware file (note: file must be named firmware.bin). -
Page 17: Troubleshooter
Troubleshooter: Q: I think my router is not working: can not acquire connection and WebUI is not reachable. A: Check if IP address is set to obtain automatically via DHCP. Follow these steps: Windows 7: Go to Control panel ->Network and internet -> Network sharing center -> change adapter settings. - Page 18 Make sure that Obtain IP address automatically is checked in the General settings. Click OK.
-
Page 19: Technical Specifications
Technical Specifications: Standard Compliant IEEE 802.16e-2005 Air Interface S-OFDMA Frequency Band 3.3 – 3.6 GHz (RUT735) or 2.5 – 2.7 GHz (RUT725) Channel Bandwidth 3 MHz, 3.5 MHz, 5 MHz, 6 MHz, 7 MHz, 8.75 MHz and 10 MHz Modulation Adaptive QPSK, 16QAM, 64QAM MIMO MRC, Matrix A + MRC, Matrix B...
