Kodak EasyShare 5100 User Manual

Start Here
Unpack Printer
EasyShare 5100
a) See box flaps for unpacking
All-in-One Printer
b) Remove all orange shipping
Print
Copy
Scan
1
a) If not preinstalled, insert
Box Contents
Check Check Check
Black Ink Color Ink Paper
D P O F Photos
Tagged Proofsheet
PictBridge
Transfer
Scan
b) Press down on all edges of
Copy
Quantity
100% Black
Fit to Page Color
Cancel
Start
EasyShare 5100
All-in-One Printer
Control Panel Overlay Sample Paper Printhead
(may be pre-installed) Packs
2
10
a) Load photo paper into the photo tray.
Black and Color Power Supply Software CD
Ink Cartridges and Adapter and Brochure
Identify Main Components
Scanner glass
Printer access
door
USB drive/
PictBridge port
Paper-width
guide
Output tray b) Load plain white paper into the main tray.
Photo tray light
Photo tray
Main tray
Paper-length guide
Scanner lid
Control panel
Rear access
door
USB port
Power connector
*3J9337* *D*
*3J9337* *D*
3J9337 D
7
Install Windows Software Install Macintosh Software
IMPORTANT: Do not connect the USB cable to the printer until
a) Connect the USB cable to
instructed during software installation.
a) Load the Kodak EasyShare
CD into the CD-ROM drive.
If instructions do not appear,
click Start, then Run. Select
CD-ROM drive and type
setup.exe, then press ENTER.
b) Download the EasyShare
b) If connected to the internet,
select Web Install to get the
latest upgrades for your
printer.
c) Double-click the .dmg file to
c) Follow the on screen prompts
to install the AiO Software.
d) Wait for the Kodak EasyShare
d) Connect the printer to
the USB port. Click Next
and follow the on screen
prompts.
If prompted, re-boot your
computer.
e) When the EasyShare AiO dialog box appears, close the window.
Vista XP
e) Click on the Install Software.app
Eastman Kodak Company
The Bluetooth® trademarks are
Rochester, NY 14650 U.S.A.
owned by the Bluetooth SIG, Inc.
© Eastman Kodak Company, 2007
MC/MR/TM: Kodak, EasyShare. Printed in the U.S.A.
3
IMPORTANT: Do not connect the USB cable to the printer until
instructed during software installation.
IMPORTANT: The printhead
is fragile. Handle carefully.
instructions.
a) Lift the printer access door.
Make sure the orange tape
is removed from the carriage.
tape from the printer.
b) Remove the printhead from
Install Control Panel
it's bag.
D P O F
All-in-One Printer IMPORTANT: Insert the
the control panel overlay,
printhead immediately
bottom end first.
upon opening sealed bag.
EasyShare 5100
All-in-One Printer
c) Pull on the orange tab to
remove the protective
D P O F
retainer.
the overlay until it snaps
into position.
All-in-One Printer
Load Paper
d) Carefully remove and discard
1) Lift the photo tray lid. Insert
the clear plastic shield and the
the photo paper glossy side
orange protective cap.
down.
IMPORTANT: Do not touch
IMPORTANT: Do not overload
the copper-colored contacts.
the photo tray. Max 20 sheets.
2) Push the photo tray in
until it clicks into place.
e) Place the printhead into
the carriage. Insert at the
NOTE: You can only print to
angle shown.
the photo tray when the photo
tray is pushed in.
3) Lower the photo tray lid.
f) Push firmly against the top
of the white label on the
1) 2)
printhead until it clicks into
place.
Tip: The printhead requires a
firm push and makes an audible
click when locked into place.
3) 4)
Helpful Tips
Pull out the output tray extender
to help collect your 8.5"x11"
prints.
the printer and your
computer.
The photo tray light illuminates
when the photo tray is pushed in.
To use the main paper tray,
disengage the photo tray by
pulling it towards you.
Control Panel Features
AiO software from
www.kodak.com/go/5100aiosupport.
open it.
Scan
Copy
Installer icon to appear on your
desktop and double-click on it.
Getting Started
You can access and use the AiO Home Center by double-clicking on the
icon on your desktop.
The AiO Home Center will enable
you to copy, scan, and configure
your AiO Printer from the
computer. You can also launch
icon and follow the on screen
Kodak EasyShare software for
prompts.
transferring, viewing, and working
with your digital pictures and
videos.
Windows® is a registered trademark
of Microsoft Corporation
Macintosh® is a registered
trademark of Apple Computer, Inc.
4
Install Printhead
Install Ink Cartridges
a) Remove the black ink
cartridge from it's bag.
IMPORTANT: Insert ink
cartridges immediately
upon opening sealed bag.
b) Carefully remove and
discard the orange cap.
Handle ink cartridges
carefully to avoid ink
transfer.
c) Insert the black ink
cartridge into the
printhead.
d) Press down on the ink
cartridge until you hear
it click into position.
e) Open and uncap the color
ink cartridge. Insert it into
the printhead.
f) Press down firmly on the
ink cartridge until you
hear it click into position.
It is normal for the printhead
to flex when inserting the
cartridge. You will not
damage the printer.
g) Close the printer access door.
Troubleshooting
If you have additional questions about troubleshooting this device, please
visit www.kodak.com/go/5100aiosupport
PROBLEM:
I cannot print anything, the printer is locked-out after printing the calibration
sheet.
SOLUTION:
1. Are both the Black and Color lights solid red? YES
2. Did you already scan the Calibration Sheet?
NO - proceed to step 3.
YES - proceed to step 5.
3. Place calibration sheet on the scanner glass.
4. Press START.
Did this correct your problem?
YES - no further troubleshooting is necessary
NO - proceed to steps 5 through 8.
5. Reset power to printer by turning it OFF. Wait ten seconds and turn it
back ON.
6. After the printer finishes re-booting, check the position of the calibration
sheet on the scanner glass.
7. Press START.
Did this correct your problem?
Indicates that a source with a DPOF
YES - no further troubleshooting is necessary.
print file is detected
NO - contact Kodak service support.
Check Check Check
Black Ink Color Ink Paper Indicates PictBridge connectivity
PROBLEM:
I've put the calibration sheet on the scanner glass and nothing happened.
D P O F
Photos
Tagged
If photo tray is engaged, toggles
SOLUTION:
Proofsheet
PictBridge
between Transfer and Proofsheet.
One of two scenarios may have occurred. Either the calibration sheet is not
Transfer
If photo tray is not engaged, toggles
positioned correctly (arrow not positioned in right corner) on the scanner
between Transfer and Photos
glass or the calibration sheet is skewed (not aligned squarely) on the scanner.
1. Verify that the calibration sheet is positioned correctly on the scanner glass.
2. Press START.
Quantity display
Did this correct your problem?
Quantity
YES - no further troubleshooting is necessary.
Black
+
100%
NO - please contact Kodak service support.
Color Increases the number of copies from 1-9
Fit to Page
-
PROBLEM:
I cannot get a calibration sheet to print.
Decreases the number of copies from 9-1
Cancel
SOLUTION:
When necessary, you can force a calibration sheet to print by following these
Start
steps:
Toggles between Black and Color copies
1. Make sure the photo paper tray is loaded and pushed in.
EasyShare 5100
All-in-One Printer 2. Press CANCEL and PHOTO simultaneously. Then press START.
3. When the print comes out, place it at the front-right corner of the scanner
Toggles between 100% and Fit-to-Page
glass, and press START.
PROBLEM:
I cannot print to my desired paper type.
SOLUTION:
Check to see if the photo tray is pushed in. You can do this by checking if the
green photo tray light is illuminated. If it is, all prints will be produced from
this tray. If you want to print from the main tray, pull out the photo tray by
lifting the lid and sliding the paper tray toward you (See step 6d).
PROBLEM:
I have a paper jam.
SOLUTION:
Windows Macintosh 1. Press in the tabs on the rear access door to remove the door.
2. Gently pull the paper out of the rollers.
The AiO Home Center will enable
IMPORTANT: If the paper tears while removing it, check inside the
you to configure your AiO Printer
printer for torn pieces of paper and remove them. Additional jams are
from the computer. You can also
likely to occur if all of the torn pieces are not removed.
order supplies and launch Kodak
3. Replace the rear access door. Gently push the door forward until it snaps
EasyShare software for
transferring, viewing, and working into place.
with your digital pictures and
videos. Use the Kodak EasyShare
AiO drivers to print and scan to
your AiO Printer.
5
Connect Power
a) Connect the power supply
and adapter.
b) Press ON.
-ON
6
Calibrate Printer
IMPORTANT: Make sure that the photo tray is pushed in. The photo
tray light will be lit.
a) Press Start. Wait two minutes
for the calibration sheet to print.
Tip: If the calibration sheet
does not print properly, see
the Troubleshooting section
in this setup poster.
b) Remove the calibration sheet
from the output tray. Place it
face down and align to the front,
right corner of the scanner glass,
as shown.
IMPORTANT: The blue arrow in the corner of the calibration sheet
must point to the registration marks as shown.
4x6
c) Lower the scanner lid and
press Start. The ON/OFF
4x6
light will turn solid green
when the calibration is complete.
Remove the sheet from the
scanner glass.
d) Lift the photo tray lid, then slide the
photo tray toward you to return to
main tray operation. The photo tray
light will turn off.
Is Further Troubleshooting Required?
If you need further information to
help answer your questions,
please contact Technical Support
KODAK SERVICE NUMBER
and have your KSN number ready. F330065
*F330065*
*F330065*
Your KSN number can be found
on the unit after lifting the printer
access door as shown.
More accessories
More options
More convenience
The KODAK EasyShare All-in-One Printer gives you more. Be sure to visit
our online store to select from our full line of supplies and accessories at
www.kodak.com/go/AiO.
Kodak's Inkjet Photo Paper
Get prints that look great the first
time with Kodak's unique backprint
technology that automatically
enables optimized prints.
Value Packs
Save up to 50% on everything you
print and pay as low as 10 cents a
print with our ink and paper Value
Packs .
Two-sided Printing Accessory
It's easy to print both sides of your
document with the Kodak EasyShare
5000 Series Two-Sided Printing
Accessory.
ess Adapter
reless with the Kodak Wireless
SB Bluetooth Adapter.
Wireless Bluetooth 2.0 USB
Adapter
Note: A USB 2.0 cable is required to connect your Kodak All-in-One printer
to your Windows or Macintosh OS computer. Available in the Kodak online
store or see your local retailer.
Need More Help?
Look here for answers:
www.kodak.com/go/5100aiosupport
User Guide
The User Guide is installed with your Kodak AiO Software and is located:
Windows
Start All Programs Kodak
Macintosh
Library Documentation Kodak AiO Printers
