Always “On” UPS DC UPS Systems User Manual

DC UPS SYSTEMS
DC UPS
UPC Order Code
SYSTEM
Phase
Input
Voltage
Frequency
Voltage (nominal)
Voltage Range
Output
Output Current
Transfer Time
Current
Charging
System
Voltage
Type
Capacity
Runtime
Batteries
Number of Batteries
Battery Low Trip Point
Charging Time
Protection
LED
Indicators
Audible Alarm
Operating Temperature
Environmental
Humidity
Container Rating
Mounting
Physical Data
Dimensions (WxDxH)
Weight
Always "On" UPS Systems Inc.
Bldg 1 – 150 Campion Road, Kelowna, BC, V1X 7S8
FOR MORE INFORMATION CALL TOLL FREE AT 1-877-259-2976 Ext 451.
825433 00420 825433 00425
Single
120 or 220VAC Nominal (+10% -13%)
47 – 63 Hz
12VDC 12VDC
10.2 - 13.8VDC 10.2 - 13.8VDC
3A Max (other configurations available)
0 ms
0.5A
13.8VDC
Sealed, maintenance-free, lead acid
12V 5Ah 12V 26Ah
Dependant on load(s)
1
10.8-10.9VDC
4 hours to 90% 16-20 hours to 90%
Output short, Overload, I/O noise, spike and
transient, RFI/EMI filter full time suppression
and FCC Class, Surge/Transient (6500A, 320J)
IEEE C62.41 Cat. A
AC Present / Charging / Output / Low Battery
YES
0°C to 40°C
5-95% non condensing
NEMA 1
Tower
10.5"x6.1"x2.5" 10.5"x11.5"x8"
3.0kg (6.6lbs) 12kg (30lbs)
Always "On" UPS Systems Inc.
®

User Manual

Version 1.0
