- Page 1 Always “On” UPS Systems Inc. GES V-Series – Single Phase Input, Single Phase Output Uninterruptible Power Supply GES-325V, GES -425V, GES -525V, GES -625V Line Interactive (PWM): 325VA, 425VA, 525VA, 625VA User Manual Version 2.2...
- Page 2 Always “On” UPS Systems Inc. SAVE THESE INSTRUCTIONS This manual contains im portant instructions for the GES-325V, GES-425V, GES-525V, GES-625V and should be followed during installation and maintenance of the UPS and batteries. The UPS contains voltages that are potentially hazardous. Please contact our dealers or qualified personnel for service.
- Page 3 Always “On” UPS Systems Inc. SAFETY INSTRUCTIONS The UPS has its own internal energy source (battery), therefore the output receptacles may have electricity present even though the UPS is disconnected from the utility power. The DC voltage provided from the internal battery is 12VDC. Isolated Ground Wire refers to the bare wire connecting electrical equipment to ground.
-
Page 4: Table Of Contents
Always “On” UPS Systems Inc. Table of Contents INTRODUCTION..................... 1 PRESENTATION..................... 2 2.1. Front Panel....................2 2.2. Rear Panel....................2 INSTALLATION....................3 3.1. Unpacking and Inspection................3 3.2. Placement..................... 3 3.3. Connect Computer Interface (Optional)............3 3.4. Connect to Utility..................3 3.5. -
Page 5: Introduction
Always “On” UPS Systems Inc. 1. INTRODUCTION The V-Series is a Line Interactive UPS system that includes the newest and latest technology enhancements. The Line Interactive technology with AVR function (on- line voltage boost -up & buck-down) allows for a wide input voltage range of 90 to 150VAC. -
Page 6: Presentation
Always “On” UPS Systems Inc. 2. PRESENTATION 2.1. Front Panel Multi Purpose LED This LED will be solid green when the UPS is under normal conditions. It will flash every 2 seconds when the UPS is supplying battery power to the loads, and will flash rapidly when the battery needs replacement. -
Page 7: Installation
Always “On” UPS Systems Inc. 3. INSTALLATION 3.1. Unpacking and Inspection Examine the packaging for damage. Inform the carrier immediately if and/or when damage is noticed. Retain the packaging for future use. 3.2. Placement Install the UPS in a protected area with adequate airflow and free of excessive dust. -
Page 8: Connecting The Telephone/Modem/Ethernet Lines (Optional)
Always “On” UPS Systems Inc. 3.7. Connecting the Telephone/Modem/Ethernet Lines (Optional) Connect a telephone line, modem line, or 10BaseT line into the telephone/modem/ethernet surge protection sockets on the back of the UPS. The RJ-45/RJ-11 modular sockets accept standard single line telephone connections and 10BaseT connectors. -
Page 9: Operation
Always “On” UPS Systems Inc. 4. OPERATION 4.1. Switching “On” the UPS With the UPS plugged in, and utility power present, press and hold the On/Off/Test/Silence Button more than 3 seconds or until the LED is lit, this will switch the UPS “On”. The UPS will perform self-testing each time it is switched “On”. -
Page 10: Green Function
Always “On” UPS Systems Inc. 4.7. Green Function In order to conserve battery power the UPS will automatically shutdown when in back-up mode, after 5 minutes, if the connected loads are operating at less than 20 watts. To disable “GREEN FUNCTION” press and hold the “On” button during initial start -up for at least 3 seconds, until a beep-beep sound is heard. -
Page 11: Audible Alarm
Always “On” UPS Systems Inc. 5. AUDIBLE ALARM 5.1. Back-Up (Slow Alarm) When in back-up mode, the LED flashes every 2 seconds and the UPS sounds an audible alarm. The alarm stops when the UP S returns to line normal operation. Press the On/Off/Test/Silence Button during back-up mode to silence the beeping. -
Page 12: Computer Interface Port
Pin 4 is the RS-232 data transmit bit (DTR) Pin 7 is the RS-232 data receive bit (RTS) Pin 5 is the common or computer ground DB-9 Pin Configuration for the GES-325V, 425V, 525V and 625V UPS Shut Down or RS-232 RD (PIN 3) -
Page 13: Battery Replacement
Always “On” UPS Systems Inc. 7. BATTERY REPLACEMENT Your battery should run anywhere from 3-5 years before it needs to be replaced. Please follow the instructions below for easy, trouble free, battery replacement. Turn the UPS off (follow procedure previously mentioned) Unplug the UPS from utility power source and disconnect all connected loads. -
Page 14: Troubleshooting
Always “On” UPS Systems Inc. 8. TROUBLESHOOTING Please follow the guidelines below for common problems: ü Check UPS input plug and wiring. ü Check UPS input voltage. Please prepare the information as follows for service personnel: ü UPS model number and serial number ü... -
Page 15: Specifications
Always “On” UPS Systems Inc. 9. SPECIFICATIONS MODEL GES-325V GES-425V GES-525V GES-625V Capacity 350VA 425VA 525VA 625VA INPUT Voltage 120V, 220V +/-25% Frequency 50 or 60Hz +/-5% (auto sensing) Voltage (on battery) Simulated sine wave at Line Input +/-5% Frequency (on battery) 50 or 60Hz +/-0.5%... -
Page 16: Contact Information
Always “On” UPS Systems Inc. 10. CONTACT INFORMATION 10.1. Additional Purchases or Upgrades Always “On” UPS Systems Inc. Bldg 1 – 150 Campion Road, Kelowna, BC, Canada, V1X 7S8 Phone: (250) 491-9777 Ext 451 Fax: (250) 491-9775 Email: sales@alwaysonups.com Website: www.alwaysonups.com 10.2.
