Always On UPS Systems IMPORTANT SAFETY INSTRUCTIONS • THIS MANUAL CONTAINS IMPORTANT INSTRUCTIONS THAT SHOULD BE FOLLOWED DURING INSTALLATION AND MAINTENANCE OF THE UPS AND BATTERIES. • THE UPS SYSTEM IS NOT INTENDED FOR EXTERNAL USE UNLESS SPECIFICALLY DESIGNED FOR IT. •...
Page 6
Always On UPS Systems MORE SAFETY INSTRUCTIONS • DO NOT USE THIS EQUIPMENT FOR ANY PURPOSE OTHER THAN THE INTENDED USE. • EXAMINE THE PACKAGING CONTAINER FOR DAMAGE. NOTIFY THE CARRIER IMMEDIATELY IF DAMAGE IS PRESENT. • DO NOT DISASSEMBLE THE UPS. •...
Always On UPS Systems Introduction Congratulations on your choice of the Always “On N Series On-Line Uninterruptible Power System (UPS). The N Series features the very latest, top of the line, microprocessor technology and IGBT transistors for clean, highly regulated, PWM (Pulse Width Modulated) True Sine Wave power.
Page 10
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
Always On UPS Systems Product Description 2.1. Theory of Operation The UPS (Uninterruptible Power Supply) is designed to be installed between utility (commercial supplied power) and your loads. It is used to protect your loads from noticing any power fluctuations (eg. Blackouts, brownouts, over-voltage conditions). The UPS will supply a sufficient amount of steady, constant AC power during these power fluctuations, allowing the loads to be shutdown properly preventing possible damage to both hardware and software.
Always On UPS Systems 2.3. Description of Each Block Input Breaker: Prevents the breaker of the distribution panel from tripping when a UPS fault or over-current condition occurs. EMI/RFI Filter: This filter attenuates the electrical noise associated with the polluted utility power to the UPS or noise (THD) generated by the UPS. Rectifier / Power Factor Correction (PFC): During normal operation, the rectifier/power factor correction (PFC) circuit converts the utility power (AC power) to DC power, which in turn is used by the inverter, while ensuring that the waveform...
Always On UPS Systems 2.4. Special Features Efficiency Optimizer function The Efficiency Optimizer function adds cost effectiveness, minimizes power loss and reduces power consumption. Alternating between bypass and on-line modes is achieved automatically and in accordance with the conditions of the utility AC power. On-line mode may be used during times of intermittent power, and bypass mode when the utility is within selectable parameters in order to obtain greatest efficiency.
Page 14
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
Always On UPS Systems Handling 3.1. Delivery Upon receiving the UPS system, inspect the packaging integrity and the physical condition of the cabinet carefully. In the event that physical damage is visible, the carrier must be informed immediately and a claim filed with them. Inform Always “On as soon as the claim has been filed and a copy of claim should be faxed to Always “On at (250) 491-9775.
Page 16
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
Always On UPS Systems Installation The UPS is intended for installation in a temperature-controlled indoor area, free of conductive contaminants. Installation should be conducted by qualified individuals. 4.1. Location The N Series UPS is intended for installation in a temperature and humidity controlled indoor environment, free of conductive contaminants with unrestricted airflow.
Always On UPS Systems 4.2. Electrical Considerations The UPS shall be installed by a qualified technician and wired in accordance with local and national electrical codes. The following information is for recommendation only. Standard Load VA Rating F (Hz) Panel Input Output Breaker Size...
Always On UPS Systems 4.4. Input, Output and External Battery Connection The 700VA, 1,000VA and 1,500VA (701N, 102N and 152N) come with a 6’ cord, complete with a 5-15P connection that will plug into a regular wall receptacle (Figure 4.4.1). The 2,000VA and 3,000VA have a terminal strip connection to which will require a connection to a cord to (Figure 4.4.2).
Page 20
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
Always On UPS Systems Start-up/Shutdown Once the UPS is installed, make sure it is located on a sturdy, well-ventilated surface, and that the exhaust fans and ventilation grills are not obstructed. Below is the necessary information for operation of the unit. Normally the UPS runs automatically, but on those few occasions such as just after installation start-up or shutdown procedures maybe required.
Page 22
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
Always On UPS Systems Front Control Panel ON-LINE ON-BAT BYPASS FAULT FUNC STATUS ON/OFF Figure 6.1 LCD Display (* Not Used) 6.1. Normal Display The UPS status is shown in normal display mode. From here you have a choice to go to UPS meters display and the Settings display by pushing the button.
Always On UPS Systems 6.3. Button Operation Please note the three operating buttons on the front panel: “ON/ OFF” button: (a) Push the “ON/OFF” button for at least 3 seconds to turn on the UPS. (b) When UPS is working, push the “ON/OFF” button for at least 3 seconds to turn off the UPS.
Page 25
Always On UPS Systems Press the “FUNC” button to scroll through the options for the selected parameter; Press the “STATUS” button to select the option. You may be prompted to save the selection, if so press the “STATUS” button to either confirm or save your selection.
Page 26
Always On UPS Systems Settings LCD Display Explanation Selection Factory Default 100/110/115/120/127VAC 120VAC Output Voltage Select nominal output O/P V Setting Setting voltage 208/220/230/240VAC 220VAC ±2% Select input frequency ±5% ±7% Input Frequency I/P F Setting range when UPS goes ±7% into free run mode ±10%...
Always On UPS Systems Audible Alarm 7.1. Backup mode The UPS will beep once every five (5) seconds and the BACKUP LED will light, when the unit is in back-up mode. (beep - - - - beep - - - - beep) [Slow beep] 7.2.
Page 28
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
Always On UPS Systems 10. Battery Replacement The batteries may be replaced without having to turn the UPS off or disconnecting the load due to the hot-swappable battery feature. When replacing batteries, use the same number and the following types of batteries: UPS Rating Number of Batteries Type of Batteries...
Page 30
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
Always On UPS Systems 11. Software Setup For Standard Software Applications At the back of the UPS is an interface allowing direct communication with your computer system, the location of which can be found in figure 4.3.1-4. There is a RS232 serial data interface, one USB data interface and an emergency power off switch supplied.
Always On UPS Systems 11.4. EPO port (Emergency Power Off) A customer-supplied switch located remotely can be used to open the EPO connection and allows UPS output receptacles to be switched off. Since the EPO shuts down the equipment immediately, orderly shutdown procedures are not followed by the power management software.
Always On UPS Systems 12. Optional Extras 12.1. Procedure for (Optional) Extended Battery Cabinets Attention: Choose the correct battery pack voltage, according to the UPS rated capacity. Do not connect too few or too many batteries, as this could cause electrical shock, damage or death. Caution: It is important to follow the correct procedures for connecting the battery packs.
Always On UPS Systems Battery cable (supplied) is attached to the Battery Cabinet and the UPS. If multiple battery banks have been purchased connect all batteries banks together in a parallel fashion (Batt. Pos. to Batt. Pos. and Batt. Neg. to Batt. Neg.) before connecting the final battery bank to the UPS.
Always On UPS Systems 12.3. AS-400 and Relay Contact (Optional) Located on the rear panel of the UPS is a connector, which provides status information through relay and photo-coupler of the UPS operation. Pin Assignment (DB 25pin male connector) Input signal pin assignment: Remote Emergency Power Off: Pin 24, 25 When pin 24 and pin 25 are shorted, the UPS will power off immediately.
Page 36
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
Always On UPS Systems 13. TROUBLESHOOTING The following chart of unusual situations includes some possible problems and solutions occurring under daily operation. If the UPS loses its basic functions, please check the following items before contacting your local dealer or service center: Is the UPS connected to the power source? Does the input voltage match the specification? When you contact anyone for service, please provide the following information:...
Page 38
Always On UPS Systems THIS PAGE IS INTENTIONALLY BLANK M0309_N_Series_ABS_700-3kVA_User_Manual V2.8 2012-06-12...
