5.1ch Home Theater Speaker Package
Supplied Accessories
Make sure you have the following accessories.
Front Speakers (SKF-591)
(White)
Front speakers
Speaker cables 10 ft. (3.0 m)
Center Speaker (SKC-591N/SKC-591)
Center speaker
Speaker cable 10 ft. (3.0 m)
SKC-591N (North American)
SKC-591
(Asian)
4 rubber stoppers*1
*1
Configuration of the rubber stoppers may be different from the
figure, such as being 2 sheets instead of 1 sheet, but the total
number will be same.
HTP-593
E
n
Surround Speakers (SKR-590)
Surround speakers
Powered Subwoofer (SKW-593/SKW-591)
(Red)
(Green)
Subwoofer
4 floor pads
Part Names
Front Speakers (SKF-591)
(Blue)
(Gray)
Speaker cables 26 ft. (8.0 m)
Center Speaker (SKC-591N/SKC-591)
RCA cable 10 ft. (3.0 m)
Surround Speakers (SKR-590)
Caution
• The front grilles are not designed to be removed so do not
attempt to remove them forcibly, as this will damage
them.
1
D1406-0
* 2 9 4 0 1 8 7 4 *
Keyhole slot
Speaker terminals
Speaker terminals
Keyhole slots
Keyhole slot
Speaker terminals
