Assembly Instructions
M108HV
Your Maco 108HV maxibeam is an innovation in base station beam design, which enables the
vertical and horizontal to be assembled for either 10 or 11 meters.
For example, using the charts supplied, you can assemble the horizontal for 11 meters and the
vertical for 10 meters, or reverse this, or assemble both the same. The horizontal and vertical
do not affect each other, so feel free to set your antenna up whichever way you wish.
THE ONLY DIFFERENCE BETWEEN THE HV BEAMS AND THE INSTRUCTIONS INCLUDED IS THAT THE
HV BEAM HAS BOTH SETS OF ELEMENTS ON THE SAME BOOM.
P LEASE ADD THE FOLLOWING INSTRUCTIONS TO THOSE SUPPLIED:
U U
Mount the first reflector with the u-bolt facing the rear. Mount its mate with the u-bolt
facing the front of the beam. This is so the vertical and horizontal elements will be close
together, but they should not touch. Maintain a 1/4" spacing between the hardware.
Do the same with all the elements and measure the spacing only once per set of elements.
Maco Antennas - a Division of Charles Electronics, LLC
302 S. East St.
Mt. Carroll, IL 61053
815-244-3500
www.macoantennas.net
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Maco Antennas M108HV
Summary of Contents for Maco Antennas M108HV
-
Page 1: Assembly Instructions
Assembly Instructions M108HV Your Maco 108HV maxibeam is an innovation in base station beam design, which enables the vertical and horizontal to be assembled for either 10 or 11 meters. For example, using the charts supplied, you can assemble the horizontal for 11 meters and the vertical for 10 meters, or reverse this, or assemble both the same. -
Page 2: Packing List
WHEN ORDERING PARTS, ALWAYS GIVE PART NUMBER AND DESCRIPTION. Please note: In an effort to keep the price on Maco Antennas down, we have decided not to clean up all the burrs and rough edges on the parts. We recommend that you deburr and clean up each part with files, sandpaper, etc. -
Page 3: General Instructions
R E F L E C T O R BLACK PLASTIC E L E M E N T D I R E C T O R S E C O N D D I R E C T O R T H IRD HORIZONTAL POLARIATION D I R E C T O R... -
Page 4: Boom Assembly
3” BOOM T W I S T E N D O F G U Y HEX NUT T H R E A D G U Y W I R E T H R O U G H E G G I N S U L A T O R A N D T W I S T E N D 1 ”... - Page 5 Please read the Assembly and Troubleshooting Tips end of this instruction booklet before assembling elements. I E L E M E N T BE3 CLAMP NUTS AND FIGURE 3A ELEMENT CENTER SECTION MOUNTING Refer to the main sketch (Figures 1A & B) for spacing of the elements. Slide the 5/8” x 6’ center sections inside the boom to element mounts.
- Page 6 MOUNTING The M108C is designed to accept a 2” O.D. mast. A l/4” heavy duty mast designed for this purpose is recommended. If mounted on a guyed tower, break up the guys every 3’ by using egg insulators in the guy lines for the top 20’...
- Page 7 REFLECTOR DRIVEN ELEMENT DIRECTOR 1 DIRECTOR 2 DIRECTOR 3 DIRECTOR 4.5.6 2 6 . 5 0 0 I T I I ” I 7’ 2” IT I ” 2 6 , 5 5 0 I T l o ” I T 2” IT I ”...
- Page 8 * m: THESE DIMENSONS ARE APPROXIMATE. REFER TO THE INSTRUCTIONS ON ADJUSTINNG THE S.W.R. TO DETERMINE EXACT SETTINGS. THERE ARE2 SEPARATEGAMMA ADJUSTMENTS, 1. CAPACI- TOR ADJUSTMENT, 2. SLIDER POSITION. DO NOT MOVE BOTH AT THE SAME TIME. MOVE THE CAPACITOR FIRST, THEN, IF NECESSARY MOVE THE SLIDER.
- Page 9 I n s t a l l i n g a n d r i g g i n g t o w e r s , m a s t s a n d a n t e n n a s r e q u i r e s p e c i a l i z e d s k i l l s a n d e x p e r i e n c e . I n f o r m a t i o n s u p p l i e d b y M a s s u m e s t h a t a l l p r o d u c t s w i l l b e i n s t a l l e d b y p e r s o n n e l h a v i n g t h e s e s k i l l s a n d h a v e i n s t a l l e d s i m i l a r p r o d u c t s b e f o r e .
