Memory card slot - SD, SDHC, MMC, MS, xD NOTE: When you turn on the frame or tap the Quick Touch Borders, the screen icons appear and lights indicate where to touch the Borders. To use the Quick Touch Borders, see www.kodak.com/go/support page Product features...
Inserting a memory card... 26 Connecting a digital camera or other USB device ... 26 Viewing the Home screen... 27 Viewing your pictures and videos... 28 Viewing thumbnails ... 29 Viewing a single picture ... 30 Playing a slide show... 31 www.kodak.com/go/support...
Page 6
Changing your frame orientation ... 61 Maintaining your frame... 62 Learning more about your frame... 62 8 Troubleshooting and support ...63 Frequently asked questions ... 63 Picture frame problems ... 64 Picture frame/computer communications ... 66 Screen messages... 67 www.kodak.com/go/support...
Page 7
9 Appendix ...70 Digital frame specifications... 70 Important safety instructions ... 72 Upgrading your software and firmware... 73 Additional care and maintenance ... 73 Limited warranty ... 73 FCC compliance and advisory ... 75 www.kodak.com/go/support...
Getting started Welcome to your KODAK OLED Wireless Frame. Viewing your pictures with spectacular clarity and brightness couldn’t be simpler! Setting up your frame Attaching the power cable CAUTION: Do not use this power cable with other devices, including digital cameras.
Turning your frame on and off Power button - press and hold (for about 2 seconds), then release www.kodak.com/go/support Getting started With the power cable still plugged in, your frame retains information (like the time) if you turn it off.
Tap below arrows at the ends of the scroll bar to move the highlight one picture, menu, or item at a time. Tap lights next to icons* (No sliding here) Home Play slide show Done Close Quick Touch Borders ** Tap below arrows www.kodak.com/go/support...
26). To bypass the initial network setup and connect later, see Connecting to your wireless network later, page www.kodak.com/go/support Slide (or tap below slider arrows) on the lights at the bottom border to highlight your language, then tap Save.
If your wireless network is not listed, follow the directions on page and resume this connection procedure. 1 Slide or tap below the arrows to highlight your home network, then tap OK. page 63. Or open KODAK EASYSHARE Digital Display page 8) and click Tools page www.kodak.com/go/support...
Page 13
On-screen keyboard: Text box Slider Slider arrows Congratulations! You have successfully connected your frame to your network! www.kodak.com/go/support Setting up for wireless operation (Select) to enter it in the text box. Touch tips Backspace key Right border - tap only...
IMPORTANT: Do not select Scan now (to verify connections, installed the software. 3 If you haven’t done so already, install the KODAK EASYSHARE Digital Display Software on your WINDOWS OS computer (see customize your frame right from your computer wirelessly. For MAC OS users, see...
KODAK EASYSHARE Digital Display Software from your computer, copy between your frame and computer your frame for access to KODAK Gallery and Web content KODAK EASYSHARE Software IMPORTANT: We recommend that you install both. If you already have EASYSHARE Software on your computer, upgrade to this special version for additional features.
Page 16
When prompted, take a few minutes to electronically register your frame and software for exclusive tips and offers. To register later, visit www.kodak.com/go/register. 1 Insert the CD into your computer. 2 Follow the on-screen instructions to install the software.
NOTE: If you have more than one frame on your wireless network, give them unique names using the on-screen keyboard so you can tell them apart. Go to Home menu. See page www.kodak.com/go/support Setting up for wireless operation (page 8), return to your frame, then: page 28).
Opening the Device Settings Web page On your computer, open your frame’s Device Settings Web page in your browser. You’ll use it to set up access to the KODAK Gallery and RSS (Really Simple Syndication) feeds from services like FLICKR® and FRAMECHANNEL.
3 Open a browser (for example, INTERNET EXPLORER, MOZILLA FIREFOX, SAFARI, etc.) on your computer. 4 Enter the IP address in the browser’s address window, then press Enter. The KODAK Displays and Devices Configuration page (Display Settings Web page) opens in your browser (see www.kodak.com/go/support →...
Page 20
1 From the drop-down menu, select your frame. 2 Click the following Web Media tabs for on-screen setup instructions. KODAK Gallery—connect to your existing Gallery account or set up a new one to receive pictures from Gallery friends and family. See FLICKR service—sign in to your existing FLICKR account or set up a new one...
Connecting to your Gallery account Perform this one-time setup on your frame to connect it to your existing KODAK Gallery account. 1 Follow the steps on page 11 2 Click the KODAK Gallery tab. The Gallery page appears. 3 If you don’t have a Gallery account, click Set one up now. Follow the on-screen instructions, or visit www.kodakgallery.com.
FLICKR photo feeds wirelessly. You return to the FLICKR page with your sign in confirmation. To add new FLICKR feeds, click the Photo RSS tab (see to access the Device Settings Web page. page www.kodak.com/go/support Sign in confirmation 17).
FRAMECHANNEL page view and manage your favorite photos and photo-sharing sites add new FRAMECHANNEL feeds; click the Add button (see www.kodak.com/go/support to access the Device Settings Web page. Setting up Web content...
The Photo RSS/FLICKR page appears with a list of preloaded FLICKR feeds that are on your frame. 4 Click Add. page page to access the Device Settings Web page. www.kodak.com/go/support 24. They appear also in the Web page page 15), then continue...
Page 25
FLICKR page and to the Web media list on your frame’s Home screen. (See To create a shortcut of your feed on the Home screen, see NOTE: Preview your feed to make sure it will play on your frame. (See www.kodak.com/go/support page 27.) Setting up Web content...
You can click the FRAMECHANNEL logo to access these and other free photo-sharing sites for viewing right on your frame. 4 Click Add. to access the Device Settings Web page. www.kodak.com/go/support FRAMECHANNEL logo...
Page 27
Home screen. See To create a shortcut of your feed on the Home screen, see NOTE: Preview your feed to make sure it will play on your frame. See www.kodak.com/go/support Setting up Web content page...
The URL of the photo RSS feed is automatically entered in the Photo feed name box. 7 Click in the Photo feed name box to edit the name. to access the Device Settings Web page. Photo RSS/FLICKR Add/Edit page www.kodak.com/go/support...
Page 29
Photo/RSS page and to the Web media list on your frame’s Home screen. (See page 27.) To create a shortcut of your feed on the Home screen, see page NOTE: Preview your feed to make sure it will play on your frame. (See page 24.) www.kodak.com/go/support...
Setting up Web content Creating shortcuts on your frame Create up to five shortcuts to easily access your favorite Web media (such as KODAK Gallery, FLICKR, and FRAMECHANNEL) right from your frame’s Home screen. 1 Follow the steps on page 11 2 Click the Create Shortcuts tab.
To delete a feed, click appears. Click Delete. FRAMECHANNEL page www.kodak.com/go/support next to the feed name on the FRAMECHANNEL or next to the feed name. next to the feed name. A confirmation message...
If your frame has pre-loaded sample pictures, they start playing automatically. To maximize your frame’s internal memory, delete the pre-loaded samples. Access them in Pictures & → Videos Internal memory page 53 to delete them. www.kodak.com/go/support 26). Your pictures play (page 28), then see...
MULTIMEDIA Card SECURE DIGITAL/SDHC MEMORY STICK Connecting a digital camera or other USB device USB cable included with your USB device www.kodak.com/go/support Viewing locally on your frame Important: Do not insert a micro or mini memory card without an adapter (sold separately).
Home screen icons: Pictures and videos (see Music (see Playing music, page For viewing Web content such as Web Media, KODAK Gallery, FLICKR and content FRAMECHANNEL feeds, News, Weather, Sports, and any shortcuts you create (see Viewing Gallery/Web media content on your frame, page Settings—customize frame settings such as slide show durations and transitions,...
Home PC—appears if you are connected to a wireless network computer. View pictures that are stored on the computer (see My Slide show—appears when you save a picture source as a default slide show for quick access anytime (see www.kodak.com/go/support Viewing locally on your frame 1 Tap (Home), then Videos).
Tap OK. From a slide show, tap the touch border to display the icons, then tap From single view, tap Pictures are displayed as thumbnails www.kodak.com/go/support Pictures and Videos), (see page 28). (Thumbnails). (Thumbnails). (Play slide show).
To rotate a single view picture, tap (Rotate) until you get the desired orientation. www.kodak.com/go/support Viewing locally on your frame (Close) to hide the icons and lights, and (Actions), then keep tapping...
Pictures and Videos screen as a picture source page page page (Slide show options). For more page → Save as My Slide show. Tap Yes to confirm. (see page www.kodak.com/go/support 29), or highlight a picture (Play slide show). (see page 55). 28).
Settings menus. For details, see page 55 page www.kodak.com/go/support Viewing locally on your frame Saving your favorite slide show for easy access, page Arranging pictures to play by date or filename, page Notes on playing, copying, deleting music:, page...
Viewing locally on your frame Creating a multimedia slide show Use KODAK EASYSHARE Digital Display Software to create a multimedia slide show with pictures and music. Then copy the slide show to your frame. Before you proceed, make sure you install the software packaged with your frame (see...
Page 41
2 Drag the slide show to your frame in the Drag & Drop Zone. For more details on copying from Digital Display Software to your frame, click THE Help or see page 44 www.kodak.com/go/support in this guide. Viewing locally on your frame...
2 Tap (Slide show options). 3 Highlight Sort, then tap Select. 4 Highlight a sort order: -Filename, A to Z -Filename, Z to A -Date, oldest to newest -Date, newest to oldest 5 Tap Save. www.kodak.com/go/support...
Display pictures on your frame directly from your computer hard drive Display Web content you set up Display pictures from your KODAK Gallery account Automatically receive pictures from your friends and family at the Gallery Email pictures/videos directly from your frame to friends and family...
Pictures and Videos screen. If your computer is not listed, go to troubleshooting help on page 44). Viewing thumbnails, page 29 (page (page , then tap OK. → → Settings Device configuration for all the www.kodak.com/go/support 8) and...
Viewing Gallery/Web media content on your frame Follow the instructions in to display your favorite KODAK Gallery albums and RSS feeds from the Web. Then do the following: Web sources Web sources on the Home screen, including your shortcuts: Web media—list of all the RSS photo feeds that are on your frame.
(upper right or bottom) to display the icons, then tap Viewing KODAK Gallery pictures View Gallery pictures and albums wirelessly right on your frame. NOTE: Connection to KODAK Gallery is currently limited to customers in the United States, Canada, and Europe. To see all pictures from the Gallery:...
Your wireless frame uses Kodak’s Picture Mail feature to notify you automatically when a friend shares pictures with you at the KODAK Gallery. Play a slide show of the new pictures, right on your frame, even before you see the email on your computer! www.kodak.com/go/support...
Page 48
14). 1 Tap (Home), 2 Tap KODAK Gallery, then tap Select. 3 Highlight Picture Mail, then tap Select. 4 Choose from these options: Auto-receive with notification ON—(default) you automatically receive your friends’ albums and the notice appears on the frame.
Repeat for each character of your email address, then tap Save. Text box 4 Assign a nickname to the new email address (optional). www.kodak.com/go/support Viewing in wireless mode (page (Actions).
Page 50
To send the pictures to multiple addresses, highlight an address and tap (Select) for each address, then tap (Select all) to send to everyone on your list. (page 29) or single view page (Share). (Share). (Share) to send all at once. www.kodak.com/go/support (page 30). page 42).
Copying wirelessly to/from your computer The KODAK EASYSHARE Digital Display Software (included on the CD that was packaged with your frame) lets you drag and drop (copy) pictures, videos, and music wirelessly between your frame and computer or other connected devices...
Page 52
My Devices: - your wireless frame - connected USB devices KODAK EASYSHARE Digital Display Software Proceed with copying: 1 Click My Devices to see the folders on your frame and connected devices (page 26). The frame appears as removable drives—one drive for each connected picture source in the frame: internal memory, memory cards, USB devices.
It’s easy to copy pictures/videos from My Collection to your frame. 1 Install the software that came with your frame (see 2 Set the USB connection mode to Computer (see 3 Double-click (KODAK EASYSHARE Software) on your desktop to open the software. File → Copy to Collection KODAK EASYSHARE Software www.kodak.com/go/support...
Page 54
8 Click Copy. Pictures are copied to your frame. 9 Go to the copy location to view your copied pictures on your frame and to play a slide show. → Copy to. www.kodak.com/go/support...
Adjust the frame volume with the Volume button volume indicator appears in the upper right. While music is playing, tap to set Audio presets and Audio priority. For more details, www.kodak.com/go/support 1 Tap (Home), then All connected sources that contain music files are listed (memory card, USB device, network computer, etc.)
NOTE: HD (high definition) video files are not supported. Video formats created with digital cameras are certified for KODAK Digital Frames. Videos created with or copied from other sources may not play on your frame.
(Print), then Yes to start printing all selected pictures. NOTE: Remember to change your connection mode back to Computer when you are done (see www.kodak.com/go/support Doing more with your frame 1 Turn off the frame and printer.
4 Highlight USB connection mode, then tap Select. 5 Slide to highlight the mode you want to connect to, printer or computer, then tap Save. 6 Reconnect the device (printer or computer) that matches the connection mode in step 5. (Home), then tap (Settings). www.kodak.com/go/support...
The picture is copied. 4 Tap OK to dismiss the screen. NOTE: To copy wirelessly between your frame and computer, see www.kodak.com/go/support Doing more with your frame 1 Highlight a picture to copy: In thumbnails view, slide or tap below the slider arrows to find a picture;...
4 Tap OK to dismiss the screen. 1 Highlight a picture to delete: In thumbnails view, slide or tap below the slider arrows to find a picture; or, display a picture in single view. To select multiple pictures, see 2 Tap (Actions). www.kodak.com/go/support page...
2 Continue selecting pictures. To remove a check mark, tap To quickly unselect many pictures, tap Select All, then Unselect All. Select/Unselect all www.kodak.com/go/support page 29), slide or tap below the slider arrows to find a (Select). (Unselect) while the picture is highlighted.
3 seconds to 5 minutes. (The default is 5 seconds.) Transitions—specify the transition style between pictures in a slide show. See screen for options. The default is Random. Shuffle—plays the images in random order. www.kodak.com/go/support...
Page 63
KODAK PERFECT TOUCH—automatically enhances your pictures to look their best on your frame. The default is On. KODAK logo—set the lighted Kodak logo on the front of the frame. Keep on (default). The logo stays on whenever the frame is on. Fade away. The logo turns off after start up (takes effect the next time you turn off/turn on your frame).
Page 64
Changing settings and more Setting Clock and timer KODAK Gallery Network Device configuration Language Options On/Off schedule—set your frame to turn on and off at a specified time every day (page Set time—manually set the clock to the current time (page 58).
Set your frame to turn on and off at a specified time every day. NOTE: Set the clock before enabling auto on/off. 1 Tap (Home), then tap www.kodak.com/go/support Changing settings and more Options Choose to turn on or off automatic resizing of your pictures when copying.
Upgrading your firmware (recommended) Firmware is the software that runs on your frame. To check for the latest version, visit www.kodak.com/go/digitalframedownloads. Automatically upgrade firmware from the Internet When the frame is connected to your wireless network, you receive an automatic notice from the Internet whenever a new firmware version is available for your frame.
IMPORTANT: Do not turn off the frame or remove the memory card or USB flash drive during the upgrade! When the upgrade is complete, your frame automatically restarts. If it doesn’t, press the power button on the frame to Off, then back to On. www.kodak.com/go/support www.kodak.com/go/digitalframedownloads. (Settings). Changing settings and more page 52 for copying files.
3 Slide to highlight Frame orientation, then tap OK. 4 Slide to highlight Portrait, then tap OK. 5 Tap to exit. Your frame is set up now to display pictures in portrait orientation. www.kodak.com/go/support . You . But, you must (Settings). (Viewing options), then tap...
Gently wipe the frame and OLED screen with a clean, dry, lint-free cloth (included). For fingerprints on the frame, apply light pressure. Learning more about your frame www.kodak.com/go/OLEDframe www.kodak.com/go/digitalframesupport www.kodak.com/go/support Changing settings and more...
For step-by-step product support, visit select Step-by-Step Solutions & Repair. Frequently asked questions I already have KODAK EASYSHARE Software on my computer. Do I have to install it again? The CD that was packaged with your frame contains a special version of EASYSHARE Software that lets your computer share pictures with your frame.
1 Open KODAK EASYSHARE Digital Display Software on your computer. → 2 Select Tools Preferences 3 Select Enable wireless media sharing on my home network. If you are still getting a message on your frame that says, “Please select Allow on computer and try again”, see...
Page 72
OK (not Back). See If your frame loses power, the clock returns to the factory setting and auto on/off times are disabled. See losing power, page page 26). page 26). page ii). page Resetting the clock after www.kodak.com/go/support page...
Cannot copy pictures to my computer. Cannot see my frame as a removable drive. Cannot copy pictures from KODAK EASYSHARE Software. www.kodak.com/go/support page 58). It is not necessary to reset the on/off times. Try one or more of the following Make sure your frame and computer are on.
See your device documentation to remove write protection. Insert or connect a different device. Make sure your printer is on and the USB cable is securely connected Make sure you changed your USB connection mode from computer to printer (page 50). (page 51). www.kodak.com/go/support...
Page 75
Media Sharing. Follow the on-screen directions to allow your frame. → Tap Home Pictures and Videos. Select a computer name that starts with the frame name, not Kodak (indicates a connection through WINDOWS MEDIA Player.). To access your computer using EASYSHARE Digital Display Software (recommended): →...
Page 76
Unknown error. Try one or more of the following Turn off the frame, then turn it back on. Press and hold the power button (for about 2 seconds), then release. If the problem persists, contact customer support help, at www.kodak.com/go/digitalframesupport. www.kodak.com/go/support...
Appendix Digital frame specifications For more specifications, visit www.kodak.com/go/digitalframesupport. KODAK OLED Wireless Frame, model OL7620 Color display Type AMOLED active matrix organic light emitting diode Brightness 200 nits (minimum) Contrast ratio >30,000:1 Size 19.3 cm (87.6 in.) diagonal digital LCD, 800 x 480 pixels, 16:9 aspect ratio, 17.6 x 10 cm (6.9 x 3.9 in.) viewable area...
MOV, AVI, MPG, MPEG 1, 2, 4, MJPEG NOTE: HD (High Definition) is not supported on your frame. Video formats created with digital cameras are certified for KODAK Digital Frames. Videos created with or copied from other sources may not play on your frame.
The use of an accessory that is not recommended by Kodak may cause fire, electric shock, or injury. For approved accessories, visit www.kodak/go/accessories. Use only a USB-certified computer equipped with a current-limiting motherboard.
Warranty service will include all labor as well as any necessary adjustments and/or replacement parts. If Kodak is unable to repair or replace a Product, Kodak will, at its option, refund the firmware—www.kodak.com/go/digitalframedownloads.
Page 81
Appendix purchase price paid for the Product provided the Product has been returned to Kodak along with proof of the purchase price paid. Repair, replacement, or refund of the purchase price are the sole remedies under the warranty. If replacement parts are used in making repairs, those parts may be remanufactured, or may contain remanufactured materials.
Unless a specific Kodak warranty is communicated to the purchaser in writing by a Kodak company, no warranty or liability exists beyond any minimum requirements imposed by law, even though defect, damage, or loss may be by negligence or other act.
(2) this device must accept any interference received, including interference that may cause undesired operation. Hereby, Eastman Kodak Company declares that this KODAK Product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
For more information, see your retailer, local authority, or www.kodak.com/go/recycle. MPEG-4 Use of this product in any manner that complies with the MPEG-4 visual standard is prohibited, except for use by a consumer engaging in personal and non-commercial activities.
Page 85
44 help with communicating, 66 viewing pictures from, 37 connecting wireless network, 5, 7 connection mode, 51 www.kodak.com/go/support connectors, ii copying from EASYSHARE Software, 46 to frame’s internal memory, 52 to/from computer, wirelessly, 44 date sort pictures by, 35...
Page 86
IP address, finding, 12 KODAK Gallery receiving from friends and family, 40 set up account, 14 viewing from, 38, 39 KODAK logo, turn off, 56 KODAK PERFECT TOUCH, 56 landscape, set orientation, 55, 56, 61 language, setting, 4 logo, turn off, 56...
Page 87
25 viewing single, 30 viewing wirelessly, 36 zoom, 30 playing music, 48 slide show, 31 videos, 49 www.kodak.com/go/support portrait, set orientation, 55, 56, 61 power button, ii, 2 connecting, 1 specifications, 70 printer connection mode, 51 printing, PictBridge printer, 50...
