SOUNDMASTER FUR850 Instruction Manual

RADIO CONTROL CLOCK
INSTRUCTION MANUAL
1 1
Display
2 MODE 2 MODE
3 3
UP/12/24
4 WAVE 4 WAVE

FUNCTIONS AND CONTROLS

. DISPLAY
. MODE KEY
. UP/12/24 KEY
. WAVE KEY
. SNOOZE KEY

OPERATION

1. Open the battery door[9] and insert two AAA batteries, then the Hour, Minute,
Second, Month, Date, Weekday and temperature will be shown on LCD screen.
2. When you just inserted the batteries into the battery compartment, it will
automatically detect the temperature once and the RCC will automatically
receive the signal once.
3. At this mode, press UP/12/24 key[3] to switch between the 12-hour system and
24-hour system.
4. Press DOWN key[6] to switch between the
5. Press MODE key [2] to view the preset alarm time.
6. At any mode (except ALARM mode), press SNOOZE key[5] once, the LED will
be light up for five seconds. Press the button when unit is sounding at alarm
time to stop the alarm immediately, but after five minutes, the unit will sound
again.
7. You can press any key to stop the alarm except the SNOOZE button[5]. If the
unit is receiving the wave at preset alarm time, then it will stop receipt of wave
automatically.
8. The unit will detect the temperature once a minute.
Battery door
9
TEMP
5 SNOOZE
6 DOWN C/ F
7
LOCK
8 Bracket
. DOWN ⁄
. LOCK SWITCH
. BRACKET
. BATTERY DOOR
KEY
and .
