- Page 1 HARDWARE MANUAL BrightSign XD230, XD1030, XD1230 BrightSign, LLC. 16780 Lark Ave., Suite B Los Gatos, CA 95032 | 408-852-9263 | www.brightsign.biz...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Overview ..........................1 Block Diagram ............................2 XD230 ..............................3 XD1030 ..............................4 XD1230 ..............................5 Power Connector ............................ 6 DE9 RS-232 Connector .......................... 6 DA15 Switch/LED Connector ........................7 Ethernet ..............................9 USB ................................. 9 DE15 VGA Connector ..........................9 Triple RCA Component HD Video Connector .................. - Page 3 Environmental and Power Usage ..................13 Mechanical .......................... 14 Theory of Operation ......................17 Power Supply ............................17 Reset ..............................17 BCM7421 CPU ............................. 17 Built-in Flash ............................17 SDRAM ..............................17 Serial Port ............................. 18 Video Encoder and Filter ........................18 Audio Outputs ............................
-
Page 4: Overview
OVERVIEW The BrightSign XD230, XD1030, and XD1230 players can be used to decode images, audio, and up to two HD video streams for digital sign and kiosk applications. In addition to driving video and audio displays, these players can be controlled with various networked and built-in interfaces. -
Page 5: Block Diagram
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 6: Xd230
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 7: Xd1030
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 8: Xd1230
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 9: Power Connector
DE9 RS-232 Connector The RS-232 connector is a male DE9. Like PCs, BrightSign XD players are DTE devices. The input to the chip accepts a range between +25V and -25V, so it is compatible with standard +12V and -12V signaling. -
Page 10: Da15 Switch/Led Connector
The connector can also supply 3.3V at up to 500mA to an external device. The 3.3V output is polyfuse-protected and can source up to 500mA. If one BrightSign player is driving the inputs on another BrightSign player, then you can drive at most three inputs from one output. The following calculations explain this limitation: Note: The GPIO outputs have 100 Ω... - Page 11 Here is the DA15 female as viewed from the front of the BrightSign XD1030 and XD1230: A button/LED/IR board can be used to demonstrate the GPIO and IR functions on a BrightSign player. This board is built by a third-party manufacturer and can be purchased upon request.
-
Page 12: Ethernet
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 13: Triple Rca Component Hd Video Connector
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 14: Hdmi Out Connector
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 15: S/Pdif Out
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 16: Environmental And Power Usage
BrightSign XD players are designed to be used between 0°C and 40°C, at 90% maximum relative humidity, non- condensing. The power supply on the BrightSign XD series is 36W and 12V at 3A. These players will use approximately 1A of power when playing a 720p or 1080i MPEG2 HD source file. -
Page 17: Mechanical
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... - Page 18 All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012...
- Page 19 All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012...
-
Page 20: Theory Of Operation
There are seven voltage levels present in the player: 12V, 5V, 3.3V, 2.5V, 1.8V, 1.5V, and 1V. Reset BrightSign XD players have a Low Voltage Reset circuit. This circuit will hold the RESET_L signal low until a valid 3.3V power source is present. -
Page 21: Serial Port
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 22: On-Board Switch
All information provided in this reference manual applies to products under development. The characteristics and specifications of these products are subject to change without notice. BrightSign assumes no obligation regarding future manufacturing unless otherwise agreed to in writing. © BrightSign LLC, 2012... -
Page 23: Sdhc/Sdxc And Microsd Slots
NAND Flash BrightSign players have a built-in NAND flash. All the code for the player is stored on the NAND flash, and it may also be possible to store some content on the NAND flash, which is connected directly to the BCM7421.
