User Manual for your
BWMC253SS
25 Litre combination microwave oven
with grill
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 30/09/13
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Baumatic BWMC253SS
Summary of Contents for Baumatic BWMC253SS
- Page 1 User Manual for your BWMC253SS 25 Litre combination microwave oven with grill NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 2: Table Of Contents
Contents Environmental note Important safety information 4 – 8 Specifications 9 – 12 Product and aperture dimensions Product specifications 9 - 10 Electrical details Description of the appliance Control panel The turntable LED display Using your microwave 13 – 27 The adjustment dial Setting the clock Before first use... -
Page 3: Environmental Note
Environmental note o The packaging materials that we use are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this ooklet, please contact the Advice Line. - Page 5 o IMPORTANT: The adjacent furniture or housing and all materials used in the installation must b e able to withstand a minimum temperature of 85°C above the ambient temperature of the room it is located in, whilst in use. o Certain types of vinyl or laminate kitchen furniture are particularly prone...
- Page 6 Warning and safety instructions o This appliance complies with all current European safety legislation. We do wish to emphasise that this comp liance does not remove the fact that the appliance surfaces will become hot during use and retain heat after operation. o DO NOT place anything between the door and the door frame.
- Page 7 Do not heat cooking oil or liquid containing alcohol, as there is the chance of spontaneous combustion. o Do not boil eggs or similar foods in their shells, otherwise they may burst. It is possible to poach eggs in your microwave, providing you prick the yolks first.
- Page 8 Declaration of conformity o CE: Appliance conforming European directives 89/336/EEC, 93/68/EEC, 73/23/EEC and subsequent revisions and “RoHS” directive 2002/95/CE.* o The manufacturer declares that the oven is built using certified materials requires appliance installed accordance with the standards currently in force. This appliance must be used by a trained person for domestic purposes only.
-
Page 9: Specifications
pecifica tions Product dimensions Aperture dimensions (including frame kit) eight: 460 mm Height: 450 mm idth: 594 mm Width: 560 - 570 mm epth: 465 mm Depth: 550 mm Product specifications 10 functions: Auto-rehea Vegetables Fish Meat Pasta Potato Pizza Soup Chicken Cake... -
Page 10: Electrical Details
o Microwave output: 900 W o Grill output: 1100 W o Hot air output: 2500 W o Turntable size: Ø 315 mm Electrical details Rated Voltage: 230 Vac 50 Hz Supply Connection: 13 A (dou ble pole switched fused outlet with 3m m contact gap) ax Rated Inputs: 2.50 kW... -
Page 11: Control Panel
Control panel A) LED display B) Convection button C) Stop/Clear button D) Start/+30 Second/Confirm button E) Adjustment dial F) Door button G) Clock/Kitchen timer button H) Defrost by Weigh t/Time button ) Microwave/Grill/ ombination button The turntable o Never place the glass tray upside down. -
Page 12: Led Display
ED d isplay The LED display will show the time of day, or if the microwave is in use, it will show the cooking time. Indicates that microwave cooking is taking place. Indicates that convection cooking is taking place Indicates that grilling is taking place. Indicates that defrosting is taking place. -
Page 13: Using Your Microwave
Using your microw The adjustment dial o The adjustment dial (E) should only be turned clockwise (towards the book symbol) if you want to use the auto menu function. o For all other purposes and se ttings, the adjustment dial (E) should be turn ed anti-clockwise (towards the clock symbol). -
Page 14: Microwave Cooking
Microwave cooking o Once the clock has been set, your microwave is then ready to use. o Use the door button (F) to open the door of the microwave. o Check that the turntable shaft, turntable ring assembly and glass tray are correctly assembled in the cavity. -
Page 15: Second Button (Quick Start)
+ 30 second button (Quick start) o If you want to cook on the highest power level setting for a period of time, then you can use the +30 second button (D). o Press the +30 second button (D) once and your microwave will operate on full power for 30 seconds. -
Page 16: Grill Cooking
Grill cooking o Press the grill button (I) once and the LED display (A) will show “P100”. Turn the adjustment dial (E) or keep pressing the grill button (I) until “G-1” appears on the LED display. o Once “G-1” appears on the LED display (A), press the confirm button (D). -
Page 17: Combination Cooking
Combination cooking Press the combination button (I) once and the LED display (A) will show “P100”. o Turn the adjustment dial (E) or keep pressing the combination button (I) until “C-1”, “C-2”, “C-3” or “C-4” appears on the LED display (see the table below to see the various combination cooking modes that can be selected). -
Page 18: Convection Cooking
Convection cooking o Convection cooking allows you to operate your microwave like a traditional oven. Th e appliance does not use microwaves to cook the food and the cavity should be preheated before food is placed inside of it. o Use the door button (F) to open the door of the microwave. o Place whatever you are cooking in the centre of the microwave cavity and then close the microwave door. -
Page 19: Interrupting A Cooking Cycle
o Press the start button (D) and the microwave will start to pre- heat the oven cavity to the temperature that you have selected. o Once the r equired temperature inside the oven cavity has been reached, an audible signal will sound twice and the LED display will flash. -
Page 20: Cancelling A Cooking Cycle
Cancelling a cooking cycle o If you wish to cancel a cooking cycle when it is in progress, you should press the stop/clear button (C). o The m icrowave will stop heating immediately, give an audible signal and the LED display (A) will return to showing the time of day. -
Page 21: Defrost By Time
Defrost by time o Press the defrost by weight/time button (H) twice and the LED display (A) will show “dEF2”. o Turn the adjustment dial (E) to set the defrost time that you require. o Press the start button (D) and your microwave will start to defrost the food. -
Page 22: The Kitchen Timer
The kitchen timer The kitchen timer will countdown a set time and a buzzer will sound when the req uired time is reached. The kitchen timer is to be used eparately from the microwave functions and cannot be used at the same time. -
Page 23: Auto Menu Chart
o The oven will stop heating, so you can open the microwave door to place the c ake inside of the cavity. Shut the oven door and then press the start button (D) to begin cooking. Auto menu chart Menu Weig Disp Power... -
Page 24: Safety Lock
Safety lock o When the microwave is not heating, it is possible to switch on the safety lock. o Press and hold down the stop/clear button (C) for 3 seconds. o The microwave will emit a long audible signal and the LED display (A) will display a padlock symbol. -
Page 25: Materials You Can Use In A Microwave Oven
o You should not use ceramic or porcelain crockery, or porous earthenware inside of your microwave. Thes e dishes could absorb moisture from the food whilst it is cooking, which could cause pressure to build up and shatter the dish. o If you are heating certain foods and any liquid, moisture will evaporate and condensation may occur. -
Page 26: Materials Not To Be Placed In A Microwave Oven
Plastic Microwave-safe only. Follow the manufacturer’s instructions. It should be labelled as “microwave s afe”. Some plastic containers soften as the food inside gets hot. “Boilin g bags” and tightly closed plastic bags should be slit, pierced or vented, as described by the package. -
Page 27: Cleaning And Maintenance
Cleani g and maintenance Cleaning operations must only be carried out when the oven is cool. The appliance s hould be disconnected from your mains supply before c ommencing any cleaning process. The appliance exterior o You should wipe over the front of the appliance with a soft cloth and warm water mixed with a little washing up liquid. -
Page 28: Installation
o Never clean the oven surfaces by steam cleaning. o If you use any form of oven cleaner on your appliance, then you must check with the manufacturer of the cleaner that it is suitable for use on your appliance. o DO NOT us e abrasive cleaners or sharp objects to clean the glass of the microwave as this can damage the glass and lead to... - Page 29 o This appliance is supplied with a moulded plug, which must be connected to an earthed socket. o If in future you need to change the fuse in this plug, then a 13 amp ASTA approved (BS 1362) fuse must be used. o If the earthed socket is not accessible after the appliance is installed.
-
Page 30: Aperture And Ventilation Requirements
perture and ventilation requirements o The diagram above shows aperture ventilation requirements that you require to build the appliance into a housing unit. o Ensure that the rear panel of the furniture housing unit has been removed. o This oven may be installed without any additional ventilation cut outs being made in the housing unit. -
Page 31: Built Under Installation Requirements
Built under installation requirements MPORTANT: NO OTHER METHODS OF BUILDING UNDER THE MICROWAVE ARE SANCTIONED BY THE MANUFACTURER. The rear wall of the housing unit MUST be removed to allow there to be the correct amount of ventilation. o The minimum installation height is 850 mm to allow sufficient ventilation. -
Page 32: Preparing The Housing Unit
Preparing the housing unit o Your appliance will be supplied with an installation template, which you should follow when preparing the housing unit. o Place the template on the base of the housing unit and tape it into position. o IMPORTANT: The edge of template must be completely level with the front edge of the housing unit. -
Page 33: Installing The Oven Into A Housing Unit
o Remove the template from the base of the housing unit. o Fix the bottom brackets to the base of the housing unit, using screw A. o IMPORTANT: These screws must be fully tightened. Installing the oven into a housing unit o Fit adjustment screw B into the adjustment screw-hole on the top of the microwave. - Page 34 o Place the microwave into the housing unit. o IMPORTANT: Do not push the microwave fully into the housing unit, as you still need to be able to access adjustment screw B at this stage of the installation. o IMPORTANT: Make sure that the oven feet are sitting correctly in the grooves on the bottom brackets.
-
Page 35: Troubleshooting
Troubleshooting o The microwave will not switch on. * Check that the appliance has been connected to the mains supply correctly. * Check that the fuse in the moulded plug has not blown. * Check that the fuses in your fuse box have not blown. * If fuses blow on a regular basis, then we would recommend that you consult with a qualified electrician. - Page 36 o I am getting condensation in my oven * Steam and condensation are a natural by product of cooking in a microwave. * Do not leave food in the oven to cool after it has been cooked and the oven has been switched off. * Use a covered container, where practical, when cooking to reduce the amount of condensation that forms.
-
Page 40: Contact Details
United Kingdom 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Customer Care (0118) 933 6918...
