- Page 1 BMIC4644X 46 cm (high) Combination BMC460BGL Microwave Oven...
- Page 2 User Manual for your Baumatic BMIC4644X BMC460BGL 44 Litre, 46cm high compact combination microwave oven NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 3: Table Of Contents
Contents Environmental note Important safety information 5 – 9 Specifications 10 – 12 Product and aperture dimensions Product specifications Electrical details Oven parts and accessories Turntable installation Control panel Using your microwave oven 13 – 19 Functions Setting the clock Before first use Microwave cooking 14 - 15... -
Page 4: Environmental Note
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 5: Important Safety Information
Installation o IMPORTANT: Only the built in/built under installation sanctioned by Baumatic and outlined in this manual should be followed. o Do not attempt to use your appliance outdoors or any place where it is likely to come into contact with the elements. - Page 6 Baumatic will invalidate any warranty or liability claim. o Your new appliance is guaranteed against electrical or mechanical defects, subject to certain exclusions that are noted in Baumatic’s Conditions of Guarantee. The foregoing does not affect your statutory rights.
- Page 7 Only genuine Baumatic spare parts should be fitted to your appliance. These can be obtained from the Baumatic Spares Department. Warning and safety instructions o This appliance complies with all current European safety legislation. Baumatic do wish to emphasise that this compliance does not remove the fact that the appliance surfaces will become hot during use and retain heat after operation.
- Page 8 This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o Baumatic declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.
- Page 9 o Please consult with your qualified installer if you are in any doubt about the amount of ventilation that you will require. Declaration of conformity This appliance complies with the following European Directives: - 2006/95/EC regarding “low voltage” - 2004/108/EC regarding “electromagnetic disturbances” - Regulation (EC) N°...
-
Page 10: Specifications
Specifications Aperture dimensions Product dimensions Height: 450 mm (built in) Height: 454.5 mm 458+2 mm MIN Width: 594 mm (built under) Depth: 568 mm Width: 560 mm Depth: 550 mm MIN Product specifications o 9 cooking functions o 15 auto functions o 5 power levels o LED temperature and function display o Knob and touch control operation... -
Page 11: Electrical Details
Optional extra o GTR46 Glass tray Electrical details Rated Voltage: 230 Vac 50 Hz Fuse Rating: 16 AMP Electrical Connection Rating: 3.35 kW For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. -
Page 12: Turntable Installation
Turntable installation o NEVER place the enamel tray upside down. The enamel tray movement should never be restricted. o The tray must ALWAYS be used during microwave or combination cooking. o All food and containers of food should ALWAYS be placed on the enamel tray when microwave or combination cooking. -
Page 13: Using Your Microwave Oven
Using your microwave oven WARNING: The accessible surface may be hot during operation and for a period of time afterwards. Functions: Function Mode Microwave Microwave Use the microwave function to cook and reheat vegetables, potatoes, rice, fish and meat. Fan oven With fan oven cooking you can prepare meals in the same way as you do with a normal oven. -
Page 14: Setting The Clock
Setting the clock o When your appliance is connected to the power supply for the first time, the LED display will show 00:00 and an audible signal will sound once. o Use the adjustment dial (8) to adjust the current time. You can adjust the hour time between 00:00 –... -
Page 15: Microwave Power Level Chart
o Place whatever you are cooking in the centre of the microwave cavity and then close the microwave door. IMPORTANT: You should make sure that the door of the microwave is shut securely. o Press the ON / OFF button (4) once and the LED display will show the default mode of 900W and a time of 01:00. -
Page 16: Power Level Cooking Chart
15 – 60 minutes 1 minute 60 – 90 minutes 5 minutes Power level cooking chart Power level Food 900 W o Boiling water o Reheating o Cooking chicken, fish and vegetables 700 W o Reheating o Cooking mushrooms and shellfish o Cooking dishes containing eggs and cheese 450 W o Cooking rice and soup... -
Page 17: Grill Cooking
o Press the temperature setting button (5) to alter the temperature. Use the adjustment dial (8) to select a temperature from 50 – 230°C. The maximum temperature is 230°C and the minimum temperature is 50°C. o Press the timer button (6) to change the cooking time. The default time set is 10 minutes. -
Page 18: Grill + Fan Cooking
taken when removing items from the microwave. We would recommend that you use an oven glove. o After the food has been removed from the microwave oven, you should make sure that the door is closed. Grill + fan cooking o Place whatever you are cooking in the centre of the microwave cavity and then close the microwave door. -
Page 19: Preheating Function
o Turn the cooking function selection dial (1) once clockwise to select oven/heating cooking mode o Use the adjustment dial (8) to select the bottom–heat & fan function. The default temperature set is 180°C. IMPORTANT: You must select the cooking function within 10 seconds or the displayed default setting will be programmed. -
Page 20: Combination Cooking
o When the required temperature is reached, an alarm will sound 3 times. To silence the alarm, press the start / stop button (7). The oven heating and alarm will turn off automatically after 2 hours. o Place your food to the oven and Press the start / stop button (7) to begin the cooking part of the selected function. -
Page 21: Microwave And Fan Oven Cooking
o After the food has been removed from the cavity, you should make sure that the door is closed. NOTE: It is safe to use the supplied grill stands with this function. Microwave and fan oven cooking o Place whatever you are cooking in the centre of the microwave cavity and then close the microwave door. -
Page 22: Microwave And Grill Fan Cooking
Microwave and grill fan cooking o Place whatever you are cooking in the centre of the microwave cavity and then close the microwave door. IMPORTANT: You should make sure that the door of the microwave is shut securely. Turn the cooking function selection dial (1) twice clockwise to select combination cooking mode. -
Page 23: Microwave And Bottom-Heat Cooking
Microwave and bottom-heat cooking Place whatever you are cooking in the centre of the microwave cavity and then close the microwave door. IMPORTANT: You should make sure that the door of the microwave is shut securely. Turn the cooking function selection dial (1) twice clockwise to select combination cooking mode. -
Page 24: Other Functions
Auto-cooking menu There are 15 automatic cooking programs on your appliance. You only have to choose the program and set the weight to begin cooking. The power, time and temperature are already programmed to achieve optimum cooking results. To select a cooking program follow the steps below: o Press the ON / OFF button (4) to activate the microwave function. -
Page 25: Defrost Function
* These programs are preheated. During preheating, the cooking time pauses and the preheating symbol turns on. After preheating, you will hear an alarm and the preheating symbol will flash. ** These programs use only the microwave function. Defrost function o Turn the cooking function selection dial (1) four times clockwise to select defrost mode. -
Page 26: Microwave Cooking Guidelines
Microwave cooking guidelines If you are heating liquid in the microwave, then you must also place a teaspoon in the container. This will ensure that the liquid does not boil suddenly after being removed from the microwave cavity. o This phenomenon is called “delayed boiling”, this means that a liquid can be close to boiling point, even if there is no steam coming off the liquid or the liquid is not bubbling. -
Page 27: Materials You Can Use In A Microwave Oven
o After the cooking time has completed, you should let the food stand for a few minutes. This is called “standing time” and will allow the heat generated by the microwave to spread evenly throughout the food. Materials you can use for microwave cooking Material Remarks Aluminium foil To be used for shielding only. -
Page 28: Materials Not To Be Placed In A Microwave Oven
Materials you cannot use for microwave cooking Material Remarks Aluminium tray cause arcing. Transfer food into microwave-safe dish. Food carton with cause arcing. Transfer food into metal handle microwave-safe dish. Metal or metal- Metal shields the food from microwave energy. trimmed utensils The metal trim may cause arcing. -
Page 29: Cleaning And Maintenance
Cleaning and maintenance Cleaning operations must only be carried out when the oven is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. The appliance exterior o You should wipe over the front of the appliance with a soft cloth and warm water mixed with a little washing up liquid. -
Page 30: Installation
Any damage that is caused to the appliance by a cleaning product will not be fixed by Baumatic free of charge, even if the appliance is within the guarantee period. - Page 31 o WARNING: THIS APPLIANCE MUST BE EARTHED. o This appliance is supplied with a mains supply cable. It must be wired into a 16A double pole switched fused spur outlet, having 3 mm contact separation and placed in an easily accessible position adjacent to the appliance.
-
Page 32: Aperture And Ventilation Requirements
Aperture and ventilation requirements o The diagram above shows aperture ventilation requirements that you require to build the appliance into a housing unit. o Ensure that the rear panel of the furniture housing unit has been removed. o This oven may be installed without any additional ventilation cut outs being made in the housing unit. -
Page 33: Fixing The Appliance Into The Housing Unit
IMPORTANT: OTHER METHODS INSTALLING MICROWAVE ARE SANCTIONED BY BAUMATIC. o Fully insert the appliance into the aperture hole and centre it. o Ensure that none of the cables are kinked or compressed when the appliance is in position. o Screw the appliance to the aperture using the fixing screws. -
Page 34: Troubleshooting
Baumatic Customer Care Department. o The interior light bulb is not working. * Call the Baumatic Customer Care Department. The interior light bulb can only be replaced by a trained service technician. o My food is not cooking properly. - Page 35 * You should wipe over any condensation that has formed, as soon as the food has stopped cooking. IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact Baumatic Customer Care telephone...
-
Page 39: Contact Details
UK Customer Care Telephone 0344 692 3605 UK Spare Parts Telephone 0344 692 3606... - Page 40 CANDY HOOVER GROUP S.R.L. Via Privata Eden Fumagalli -20047 Brugherio Milano Italy www.baumatic.co.uk...
