PureLink HX-6600 User Manual

Hdmi matrix router
Hide thumbs
Table of Contents

Advertisement

Quick Links

HX-6600/8800
HDMI Matrix Router
User Manual
Copyright 2007 Dtrovision LLC.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HX-6600 and is the answer not in the manual?

Questions and answers

Related Manuals for PureLink HX-6600

Summary of Contents for PureLink HX-6600

  • Page 1 HX-6600/8800 HDMI Matrix Router User Manual Copyright 2007 Dtrovision LLC.

  • Page 2: Table Of Contents

    Table of Contents 1. BASIC UNDERSTANDINGS OF THE PRODUCT ....................3 1-1 C ............................3 AUTIONS FOR SAFETY 1-2 P ..............................4 ACKAGE NCLUDES 1-3 F ............................ 4 EATURES OF THE PRODUCT 1-4 N ........................5 AMES AND FUNCTIONS OF EACH PART 1-5 I ......................

  • Page 3: Basic Understandings Of The Product

    1. Basic understandings of the product 1-1 Cautions for safety • All the safety and user manual should be read before the appliance is operated. • The safety and operating instructions should be retained for future reference. • Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

  • Page 4: Package Includes

    IR Remote Controller 1-3 Features of the product HX-6600/8800 receives signals from HDMI output ports or equipments compliant to HDMI Ver. 1.3, and sends them to multiple displays. It can receive up to HDMI signals by three-stack configuration and connect to six ports.

  • Page 5: Names And Functions Of Each Part

    1-4 Names and functions of each part < FRONT & BACK PANEL > 1-5 Installation environments and methods For installation, we recommend the following environments. • Below 85 F (30°C) of ambient temperature (Best condition) • Install and operate in the environment below 60% of ambient humidity (Best condition) Copyright 2007 Dtrovision LLC.

  • Page 6: Functions Of The Product

    • Use it in the environment of free of vibrations and dusts and in good ventilation condition • Recommend stabilized AC input power (Recommend to use AVR) 2. Functions of the product 2-1 Features of the product (Three Stack Configuration) This equipment receives signals (8 input ports) from HDMI output ports or equipments compliant to HDMI specification and sends out to through any of output ports.
  • Page 7 Copyright 2007 Dtrovision LLC.

  • Page 8: System Operation Configuration Diagram

    2-2. System operation configuration diagram Operation configuration diagram of the matrix is shown in following picture. Any of the HDMI or DVI input signals can be selected to each output port by external RS-232C or front panel button. Copyright 2007 Dtrovision LLC.

  • Page 9: Specifications Of The Product

    2-3 Specifications of the product • Type of signals: TMDS signals, digital R.G.B. & Audio • Data transmission band: up to 1.65Gbps (single link). • Resolutions: WUXGA (1920*1200), 480p~1080i/p • Output port control: Front panel button switch, IR remote controller, RS-232C port, LAN (TCP/IP) •...

  • Page 10: Product Number Setting

    The functions of the switches are as follow. • Main power switch: Matrix power on/off • Remote controller receiver: receive infrared ray from remote controller • Reset key: initialize the matrix • Input key: select channel from 1 to 6 •...

  • Page 11: Rs-232C(Com Port) Communication Setting

    **The product ID is set number “1” at the time of its delivery (Factory Default). 3-3 RS-232C (COM PORT) communication setting After booting the matrix, connect RS-232C cable and then make communication settings as follows: • Execute MiniTerm.exe or hyper terminal. •...
  • Page 12 From Matrix Code (4Byte) Head (1byte) | Address (1Byte) | PN (1Byte) | Tail (1Byte) Code Name Byte Data Function Head (Start) Reply Frame Start Start Header 30h (0) Request Frame Start Start Header 31h (1) Request Frame Start Product ID 30h ~ 39h (DIP Switch Set) Product Number Product ID...
  • Page 13 EDID SW ASSIGN SALVO: change all EDID data Input1 of Input2 of Input3 of Input4 of Input5 of Byte Header Command Output Output Output Output Output ASCII Input6 Byte Tail Output ASCII ASSIGNMENT STATUS REQUEST: check the status of present input/output channels Byte Header Command...

  • Page 14: Lan (Tcp/Ip) Communication Setting

    4-2 LAN (TCP/IP) communication setting In order to control the matrix through LAN port first of all, internet IP should be set. Set up as follows: -Execute MultiTerm.exe or hyper terminal program -RS-232 Communication setting for set the IP address. After setting as above, please connect communication cable via RS232 and then matrix turn on Press ‘C’...
  • Page 15 Set up IP Address D key is displayed existing set information. G key is input gateway IP. S key is input subnet mark I key is input matrix IP H key is input hardware address If all inputs are completed, then exit the configuration by press E key. Connect matrix to your network via LAN 1.
  • Page 16 Copyright 2007 Dtrovision LLC.

  • Page 17: Connector Pin Assignment

    4-3 Connector Pin Assignment Power Input Part No. Pin No. Description Remarks VCC( DC12V) Power Jack(4P) VCC(DC12V) RS-232C Input Part No. Pin No. Description Remarks Not used Rx D Tx D Not used D-SUB 9 Pin Connector Not used Not used Not used Not used LAN Input...

  • Page 18: Warranty Information

    5 Warranty Information 5.1 One Year Warranty Dtrovision warrants this HDMI Matrix router to be free from defects in workmanship and materials, under normal use and service for a period of one (1) year from the date of purchase from Dtrovision or its authorized resellers.

This manual is also suitable for:

Hx-8800
