PureLink MX - 8000 Owner's Manual

80 x 80 digital modular matrix router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner´s Manual
MX - 8000
80 x 80 Digital Modular Matrix Router

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX - 8000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PureLink MX - 8000

Summary of Contents for PureLink MX - 8000

  • Page 1 Owner´s Manual MX - 8000 80 x 80 Digital Modular Matrix Router...

  • Page 2: Table Of Contents

    Table of Contents CHAPTER ONE - PRODUCT OVERIEW ........................3 1-1 S ............................3 AFETY RECAUTIONS 1-2 W ’ ..............................4 S IN THE 1-3 I ................................ 4 NTRODUCTION 1-4 P & R ............................. 5 AMES EFERENCE 1-5 I ............................8 NSTALLATION UIDLINES CHAPTER TWO - PRODUCT FEATURES ........................

  • Page 3: Chapter One - Product Overiew

    1. PRODUCT OVERVIEW 1-1 SAFETY PRECAUTIONS • All safety instructions should be read and understood before the unit is operated. • The owner’s manual and safety instructions should be retained for future reference. • Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth only.

  • Page 4: Whats In The Box

    AV System Integrators ever made. Field-Upgradeable Modular Design: Because PureLink is truly modular, our matrix routers can be customized in different I/O sizes from 8×8 to 80×80 Non-Blocking Topology: Any input, HDMI, DVI or 3G-SDI (including HDCP protected sources,) can be tied to any or all outputs without limitation.

  • Page 5: Part Names & Reference

    1-4 Part Names & Reference <Front Panel> 1. 7” LCD Touch panel 2. Menu button 3. Power switch 4. Lock 5. Ventilation...
  • Page 6 <MX-8000 HDMI Type> 1. Control card 2. HDMI Input card 3. Ventilation 4. HDMI Output card 5. Power LED 6. AC power port 7. F.G. 8. Ventilation...
  • Page 7 <MX-8000 DVI Type> 1. Control card 2. DVI Input card 3. Ventilation 4. DVI Output card 5. Power LED 6. AC power port 7. F.G. 8. Ventilation...

  • Page 8: Installation Guidlines

    1-5 Installation Guidelines The following installation settings are recommended for optimal performance. • Operational temperature should be 30° C or below • Operational humidity should be 60% or below • Operational environment should be dust-free and well ventilated • Stabilized AC input power (AVR-based power supply) is highly advised 2.

  • Page 9: Product Specifications

    2-2 Product Specifications • Signal Type: TMDS signals, digital R.G.B. 2k • HDMI Data Transmission Band: 2.25 Gbps (single link). • DVI-D Data Transmission band: 1.65 Gbps (single link). • HDMI version 1.3 with deep color 36 bits • Resolution Range: VGA (640*480) ~ WUXGA (1900*1200)@60Hz, 480p~1080i/p. •...
  • Page 10 MX-8000 Front Panel Switches & Functions • Power Switch: turn power to the unit ON or OFF • System Check: troubleshoot when error messages appear • Reset: push button 3-4 seconds to reboot the unit • Touch Screen ON/OFF: turn the touch panel display ON or OFF •...
  • Page 11 Press CHANNEL OUTPUT -> select OUTPUT button (multiple selection) -> Press ENTER Press CANCEL to cancel the set-up and return to the main menu ONE TO ONE: set up each INPUT channel with an OUTPUT channel automatically SET ALL: select all OUTPUTS at a time CLEAR ALL: cancel all selections OK: finalize channel set-up and return to the main menu PRESET SAVE ->...
  • Page 12 The unit also supports non-Video Electronics Standards Association (VESA) resolution, including projectors with unique resolutions. EDID should be set-up first for DVI monitors. **** EDID [Extended Display Identification Data] EDID is defined by a standard published by the Video Electronics Standards Association (VESA). The EDID includes manufacturer name, product type, phosphor or filter type, timings supported by the display, display size, luminance data, and (for digital displays only) pixel mapping data.
  • Page 13 RETURN -> return to INPUT EDID SELECT menu Previewing INPUT/OUTPUT channel or EDID selection: Select PREVIEW on the main menu to open the screen below: INPUT/OUTPUT CHANNEL PREVIEW -> initial screen view INPUT VIEW -> switching status based on input OUTPUT VIEW ->...
  • Page 14 INPUT VIEW -> switching status of inputs/outputs based on input OUTPUT VIEW -> switching status of inputs/outputs based on output MATRIX VIEW -> shows the status of inputs/outputs at the same time ARROW -> move the screen in all directions CANCEL ->...
  • Page 15 CANCEL: return to main menu Select LAN on the right side of the screen to open the LAN set-up menu below: Local IP Address: input local IP address (default: 192.168.000.002) Gateway IP Address: input Gateway IP Address (default: 192.168.000.001) Subnet Mask: input Subnet Mask (default: 255.255.255.255) Mac Address: set up Mac Address (default: 00.08.DC.00.00.00) HEX CHAR SELECT: select alphabet and numbers SAVE: save configuration...
  • Page 16 CANCEL: return to main menu...
  • Page 17 Preview of Channel and System set up: Select SYSTEM INFO to open the screen below. SYSTEM INFO screen displays the current status of channel selection and system set-up. RS232: view RS232 configuration status LAN: view LAN configuration status SYSTEM: view touch-sound set-up CHANNEL: view channel selection set-up Select CANCEL to return to the main menu.

  • Page 18: Product Id Set-Up Guide

    PRESET PREVIEW: view the status of saved preset channels PRESET CALL: change current channels to channels of selected preset CANCEL: return to main menu CHAR: select character input NUM: select number input DELETE: delete input SAVE: save edited name CANCEL: return to main menu Preset Save: Create->...

  • Page 19: Rs-232C (Com Port) Set-Up Guide

    This section is designed for programmers who wish to create their own control programs using the command code. All PureLink digital matrix routers provide a simple character stream control used by external control devices attached to a PureLink device. Command codes are used primarily for control, during system installation and setup, and for diagnostic purposes.
  • Page 20 *255CI01O01! ↵ Ex 1) Command (Connect Input 1 to Output 1) Ack value *255sC I01O01! *255?O03! ↵ Ex 2) Command (Check Input connection status on Output 3) Ack Value *255s? I03O03! General Rules for Command Codes The commands are coded in ASCII and HEXA. Please refer to Table 3.1 on pg. 32 for detailed Ex) *255CI01O01! ↵...
  • Page 21 Table 4.1 Command Codes Characters Tables The table below shows command code characters (keys), which are used to generate control commands, their functions, and short function descriptions. Function Description and Example Byte ASCII 0x2A Start the command Header Code 0x21 End the command Tail Code Execute...
  • Page 22 Command Ack (Acknowledge) Value Response When command code s are entered into a terminal emulation program (such as HyperTerminal) and are accepted by the system, they respond back to the terminal screen one at a time, as noted below in the table. The complete command has executed successfully when all of the entered characters including “s”...
  • Page 23 4.2 Connecting Switches A switch is an active connection between an input (source) signal and one or more output (display) devices. The signals connected in a switch command are either individual signals or groups of signals coming through the connectors on the rear of the unit. The “C”...
  • Page 24 *255ACI01O08,I08O02! ↵ Connect Input 1 to Output 8 and Input 8 to Output 2 *255ACI01O01,I02O02,I03O03! ↵ *255ACI01O01,02,03! ↵ Connect Input 1 to Output 1, Input 2 to Output 2, and Input 3 to Output 3 Connect Input 1 to Output 1, 2, and 3 *255ACI01O01-07! ↵...

  • Page 25: Lan Communication Code Configuration

    *255?I#!↵ or *255?O#!↵ Examples: *255?I01! ↵ Command Codes Action *255?O07! ↵ Check Output connection status on Input 1 *255?ALLIO! ↵ Check Input connection status on Output 7 Check all Input and Output connection status 4.5 Router ID Check User can confirm the router’s Current ID setting. ...

  • Page 26: Connector Pin Assignment

    Connection Checking: User can check the connection status. Example: *255H000! ↵ Command Code s Action Check connection status Function Key On/Off: User can enable or disable the function key located on physical router’s front panel. Example: *255K000! ↵ Command Code s Action Function key On/Off RS232 Cable Pin#2#3 crossed, should test use cable at box (included)
  • Page 27 LAN INPUT Part No. Pin No. Description Remarks Transmit data (+) Transmit data (-) Receive data(+) Not used RJ-45 8 Pin Connector Not used Receive data(-) Not used Not used DVI-D INPUT Part No. Pin No. Description Remarks TMDS DATA 2M TMDS DATA 2P TMDS DATA 2/4 Shield TMDS DATA 4M(N.C)

  • Page 28: Chapter Five - Warranty Information

    (2) year from the date of purchase from Dtrovision or its authorized resellers. If the product does not operate as warranted during the applicable warranty period, PureLink shall, at its option and expense, execute one of the following as necessary: 1.
  • Page 29 PureLink GmbH Hovesaatstraße 6 D-48432 Rheine Telefon: +49 (0) 5971 800 299-0 Fax: +49 (0) 5971 800 299-99 E-mail: info@purelink.de www.purelink.de For order support, please contact your local dealer. For technical support, please contact us at support@purelink.de...
