Parameter Range
Specifies the LFO rate.
When TEMPO SYNC is OFF:
0–127
RATE
When TEMPO SYNC is ON:
16, 12, 8 (
1/4 ( ), 3/16 ( ), 1/6 ( ), 1/8 ( ), 3/32, 1/12, 1/16, 1/24, 1/32
PITCH DEPTH -63–+63
FILTER DEPTH -63–+63
AMP DEPTH
-63–+63
PAN DEPTH
-63–+63

D BEAM ASSIGN Parameters

This setting specifies the parameter whose value will be modified by the D BEAM controller when you press the D BEAM
[EFFECTS/ASSIGN] button.
This setting applies to the current tone.
Hold down the D BEAM [EFFECTS/ASSIGN] button and operate the button, knob, or slider for one of the parameters listed
below.
* With the D BEAM ASSIGN parameter, you cannot assign the parameter to be changed by holding down the [CANCEL/
SHIFT] button.
Parameter Range
RATE
FADE-TIME
LFO PITCH-DEPTH
FILTER-DEPTH
AMP-DEPTH
PITCH
DETUNE
PWM
PW
OSC
PITCH-ENV-A
PITCH-ENV-D
PITCH-ENV-DEPTH
48
Explanation
), 4 ( ), 2 ( ), 1 ( ), 3/4 ( ), 2/3 ( ), 1/2 ( ), 3/8 ( ), 1/3 ( ),
Specifies the amount of modulation applied to the
tone's pitch.
Specifies the amount of modulation applied to the
tone's cutoff frequency.
Specifies the amount of modulation applied to the
tone's level.
Specifies the amount of modulation applied to the
tone's pan.
Explanation
Modify the LFO rate (frequency, p. 37).
Modify the time over which the LFO amplitude reaches the maximum (p. 37).
Modify the vibrato (pitch modulation) depth (p. 37).
Modify the wah (cutoff frequency modulation) depth (p. 37).
Modify the tremolo (volume modulation) depth (p. 37).
Modify the tone's pitch (p. 31).
Modify the pitch more finely (p. 31).
If the asymmetrical pulse wave is selected for WAVE, modify the overtone structure(p. 31).
If the asymmetrical pulse wave is selected for WAVE, modify the width of the pulse waveform's upper
portion (p. 32).
Modify the attack time of the pitch envelope (p. 32).
Modify the decay time of the pitch envelope (p. 32).
Modify the amount of pitch change produced by the pitch envelope (p. 32).
Panel operation
1. Hold down the [CANCEL/SHIFT] button and move the
pitch bend/modulation lever away from yourself.
2. Turn the [RATE] knob.
3. Press the [CANCEL/SHIFT] button.
1. Hold down the [CANCEL/SHIFT] button and move the
pitch bend/modulation lever away from yourself.
2. Move the [PITCH DEPTH] slider.
3. Press the [CANCEL/SHIFT] button.
1. Hold down the [CANCEL/SHIFT] button and move the
pitch bend/modulation lever away from yourself.
2. Move the [FILTER DEPTH] slider.
3. Press the [CANCEL/SHIFT] button.
1. Hold down the [CANCEL/SHIFT] button and move the
pitch bend/modulation lever away from yourself.
2. Move the [AMP DEPTH] slider.
3. Press the [CANCEL/SHIFT] button.
1. Hold down the [CANCEL/SHIFT] button and move the
pitch bend/modulation lever away from yourself.
2. Hold down the [CANCEL/SHIFT] button and move the
[AMP DEPTH] slider.
3. Press the [CANCEL/SHIFT] button.
