Professional Style Range Hood
INSTALLATION INSTRUCTIONS
AND OPERATION MANUAL
- READ AND SAVE THESE INSTRUCTIONS -
- READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -
ALL WIRING MUST BE DONE
ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES.
KOBE Brand Range Hood
CH-177 Models
CH7730SQ
CH7736SQ
CH7742SQ
CH7748SQ
BY A PROFESSIONAL AND IN
Advertisement
Table of Contents
Related Manuals for KOBE CH7730SQ
Summary of Contents for KOBE CH7730SQ
-
Page 1: Installation Instructions
AND OPERATION MANUAL - READ AND SAVE THESE INSTRUCTIONS - - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING - ALL WIRING MUST BE DONE ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES. CH-177 Models CH7730SQ CH7736SQ CH7742SQ CH7748SQ BY A PROFESSIONAL AND IN... - Page 2 KOBE RANGE HOODS authorized agents. Any repair carried out without the supervision of KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not hold responsible for...
-
Page 3: Important Safety Instructions
- IMPORTANT SAFETY INSTRUCTIONS - W ARNING – TO REDUCE THE RISK OF PERSONAL INJURY IN THE EVENT OF A RANGE TOP GREASE FIRE: Keep fan, optional filter and grease-laden surfaces clean. Always turn hood ON when cooking at high heat. ... - Page 4 - CONTENTS OF RANGE HOOD PACKAGE - (Must keep all materials for returns or refunds) 1) KOBE Range Hood 2) Two Impeller Safety Screen 3) Two Round and Two Oval Oil Containers 4) Halogen Lights 12V20W 5) One Plastic Multi Duct Exhaust Base (6” Round, 7” Round or 3¼” x 10” Options) 6) Installation/Owner’s Manual &...
-
Page 5: Preparing The Installa Tion Loca Tion
- PREPARING THE INSTALLA TION LOCA TION - INTERIOR OF HOOD MAY HAVE VERY SHARP EDGES, PLEASE WEAR PROTECTIVE GLOVES IF YOU HAVE TO OPEN THE HOOD FOR CLEANING OR SERVICING. NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. -
Page 6: Installing The Range Hood
- INSTALLING THE RANGE HOOD - (Keep all packing materials for return or exchange) Temporarily wire the hood to test for proper operation before installing. Before installing, please peel protective film off the hood first, if any. NOTE: The recommended distance from range hood bottom to top of the cooking surface is between 28”... - Page 7 b) For rear venting: Unscrew the rectangular plastic vent portion at the back of the hood. {Fig.4} Turn the vent piece over so that the flat surface is facing you. Cut along the indented outline until there is a 3¼” X 10” opening. Fasten plastic vent piece with the raised surface facing outward back onto the hood.
-
Page 8: Safety Warning
3) Follow installation instructions from the section For Mounting on a Cabinet with a Flush Bottom. Making The Electrical Connection (SHOULD BE DONE BY A LICENSED PROFESSIONAL) INTERIOR OF HOOD MAY HAVE VERY SHARP EDGES, PLEASE WEAR PROTECTIVE GLOVES IF YOU HAVE TO OPEN THE HOOD FOR CLEANING OR SERVICING. - Page 9 This KOBE hood is equipped with a 10-second time delay operation, four control buttons located on the front of the hood, powerful centrifugal turbine impellers with safety screen covers, bright 12 volt 20 watts halogen lights, and 4 oil containers. The four control buttons (from left to right) are the Light Control, the Speed Control (cycles through Low, Medium, High, QuietMode), alternate Speed Control (cycles through Low, QuietMode, High, Medium) and the Power Control buttons.
- Page 10 - MAINTENANCE OF THE HOOD - INTERIOR OF HOOD MAY HAVE VERY SHARP EDGES, PLEASE WEAR PROTECTIVE GLOVES IF YOU HAVE TO OPEN THE HOOD FOR CLEANING OR SERVICING. Cleaning To clean the hood surface, use only mild soap or detergent solutions. Dry up surfaces using soft cloth.
-
Page 11: Troubleshooting Guide
Changing the Light Bulb 1) Make sure all control switches are off and range hood is unplugged. CAUTION: Wait until light is cool to the touch before changing. 2) Use a flat head screwdriver to pop out the protective covering. 3) Gently pull out the defective halogen light and discard. -
Page 12: Circuit Diagram
- CIRCUIT DIAGRAM - CH-177 Models... - Page 13 - PARTS -...
-
Page 14: Parts List
Plastic Multi Duct Exhaust Attachment Plastic Vent Cover Plastic Rear Vent Cover Plastic Vent Cover Screw Rear Plastic Vent Cover Frame Hood Casing Motor Chamber Motor Turbine Impeller 10 Oil Tunnel Ring 11 Oil Tunnel 12 Bottom Casing 13 Rear Oil Container 14 Impeller Safety Screen 15 Oil Container for Safety Screen 16 Power Cord... -
Page 15: Specification
STYLE Size Dimension (WxDxH) Net Weight (lbs) Features: Stainless Steel #304 Fan Type Control Button Halogen Light (12 Volts) Duct Free* Safety Screen Oil Container Accessories: (Additional Purchase) Back panel 6” Round Charcoal Filter Multi Duct Exhaust: 6” Round (Top) 7”... - Page 16 CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT, REQUEST SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance by the carrier, he/she assumes responsibility for its safe arrival. Damages should be reported to carrier and a claim filed.
-
Page 17: Warranty Certificate
KOBE Range Hoods warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective. -
Page 18: Consequential Damage
This warranty gives you specific legal rights, and may have rights that vary from state to state. SERVICE For service contact: Should you require technical assistance, please call your dealer or KOBE Range Hoods. KOBE Range Hoods 1039 South San Gabriel Blvd., San Gabriel, CA 91776 Tel: 1-626-309-1356 Monday thru Friday, 9 a.m.
