12.
DISASSEMBLY INSTRUCTION
1. Nokia 7310 Supernova disassembly.
3. Press the release button and open the C-COVER with the
SRT-6.
5. Open the clips of the A-Cover beginning on the shown side.
7. Remove the A-COVER.
Page
11
(14)
CONFIDENTIAL
Copyright © 2008 NOKIA. All rights reserved.
7310 Supernova RM-378/RM-379
2. You will need the Standard Tool Kit v2 and the Camera
Removal Tool SS-88.
4. Remove the C-COVER.
6. Continue on the other side.
8. Remove the Keymat.
Service Manual Level 1&2
ISSUE 1
