gErÄTEOBErSEITE
NO deSIGNATION
T19 Sync Button
The current deck's tempo will be matched to the master deck. (VirtualDJ: Y,
Serato: Y)
T20 CUP Button
Jumps to the last set cue-point and starts playback from this point.
(VirtualDJ: Y, Serato: Y)
T21 Cue Button
If the deck is in play mode, the track jumps back to the last set cue point.
By pressing again, playback starts as long as the button is being held. If the
deck is in pause mode, a new cue point will be set at the current point.
(VirtualDJ: Y, Serato: Y)
T22 Play/Pause Button
Starts and pauses track playback. (VirtualDJ: Y, Serato: Y)
T23 Deck Select Switch
With this button you can select the controllable decks.
(VirtualDJ: Y, Serato: N)
T24 Gain Dial
With this dial the respective channel's gain can be adjusted.
(VirtualDJ: Y, Serato: Y)
T25 EQ Dial
With this dial highs/mids/lows can be adjusted. (VirtualDJ: Y, Serato: Y)
T26 Filter Dial
Regulates the channel filter. By turning the dial to the left, a low pass filter
will be activated; by turning the dial to the right, a hipass filter will be activa-
ted. (VirtualDJ: Y, Serato: Y)
T27 CUE Monitor
With this button the selected deck can be monitored. (VirtualDJ: Y, Serato: Y)
T28 Load Button
By pressing this button, the selected track can be loaded to the repective
deck. (VirtualDJ: Y, Serato: Y)
T29 Linefader
With the linefader the channel volume can be adjusted. (VirtualDJ: Y, Serato:
Y)
T30 Master Volume
With this dial the master output volume can be adjusted. This is an analog
dial which does not send a MIDI signal. (VirtualDJ: Y, Serato: Y)
T31 Booth Volume
With this dial the booth output volume can be adjusted. This is an analog dial
which does not send a MIDI signal. (VirtualDJ: Y, Serato: Y)
T32 Headphones Volume
With this dial the headphones volume can be adjusted. This is an analog dial
which does not send a MIDI signal. (VirtualDJ: Y, Serato: Y)
T33 CUE Mix Fading
With the Cue Mix Dial a pre-mix can be simulated in your headphones. When
in the right position, the master signal is audible; in the left position the cue
signal is audible. (VirtualDJ: Y, Serato: Y)
T34 Sampler Volume
Controls the sample volume. (VirtualDJ: Y, Serato: Y)
T35 Crates Button
Jumps back to folder navigation. By pressing again, a folder will be opened/
closed. (VirtualDJ: Y, Serato. N)
T36 View Button
Changes between browser, effects, samples, and record view. (VirtualDJ: Y,
Serato: N)
T37 Back Button
Serato: Jumps back to crates view.
VirtualDJ: Changes between browser, effects, samples, record view.
T38 Preparation Button
Maximizes playlist view. (VirtualDJ: Y, Serato: N)
T39 Track Navigation
If you are in folder navigation or playlist view, it is possible to browse
through these by turning.
T40 VU Meter
The VU Meter shows the master out's output level.
T41 Crossfader
With this fader you can fade between the decks. Also see -F59-.
SHIFT deSIGNATION -T18-
Fader Start Button
When active, by drawing up the linefader -T29-
the track will be started. By moving down the
linefader the track will jump back to the cue
point. (VirtualDJ: Y, Serato: N)
