Component
1 UP
2 Micro SD
Card Slot
3 DOWN
4 LED
5 MIC
6 LCD
7 OK
8 AV Port
9 MENU/
MODE
10 POWER
11 Bracket
Slot
12 Micro USB
Port
13 RESET
14 Camera
Lens
15 LEDs
16 Speaker
UNIDEN iGO CAM 600
Description
In Menu list, move the cursor, one line up.
Use this slot to insert the micro SD card.
In Menu list, move the cursor, one line down.
•
Flashes blue when the unit is recording.
•
Glows blue when powered on.
•
Glows red when charging.
Records sound
LCD
•
In Record mode, press to start or stop video recording.
•
In Photo mode, press to take a photo.
•
Press to confirm a selection in the Menu.
•
Press to confirm a change in the settings.
Connects to an external device.
•
In Standby, open the menu.
•
Press and hold to switch between various modes
(video, photo, playback).
•
While recording, press to manually lock the files.
Press and hold to either switch on or off the unit.
Fit the bracket hook of the windshield mount.
•
Connect to External Power (9V-12V DC IN)
•
Connect to PC for data (SD card) transfer
(Use only Uniden's USB
•
Connect to the Car Battery for Parking Mode.
If the device fails to operate properly, try resetting the
device. Press the reset button by using a fine pen.
Lens
Infrared night vision LEDs
Speaker
Converter
6
cable).
