Page 1 Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo with single CD AM/FM stereo with in-dash six CD Climate Controls Heater only Manual heating and air conditioning Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control...
Page 2: Table Of Contents
Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire Information Tire Inflation Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction control Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires...
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 7 Introduction To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority.
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Airbag - Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor...
Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Standard instrument cluster Optional instrument cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 11 Instrument Cluster converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately by your authorized dealer. Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Check fuel cap: Illuminates when CHECK the fuel cap may not be properly...
Page 12 Instrument Cluster Airbag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately by your authorized dealer. A chime will also sound when a malfunction in the supplemental restraint system has been detected. Safety belt: Reminds you to fasten your safety belt.
Page 13 Instrument Cluster Traction Control system (if equipped): Illuminates when the Traction Control is turned OFF and will flash when active. If the light remains on, have the system serviced immediately, refer to the Driving chapter for more information. Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter).
Page 14: Gauges
Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range. If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 15 Instrument Cluster Odometer: Registers the total miles (kilometers) of the vehicle. Trip odometer: Registers the miles (kilometers) of individual journeys. To reset, depress the reset control. Tachometer (if equipped): Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.
Page 16: Entertainment Systems
Entertainment Systems AUDIO SYSTEMS AM/FM stereo with single CD — Premium (if equipped) AM/FM stereo with single CD/MP3 — Premium (if equipped) 2006 Focus (foc) Owners Guide (post-2002-fmt) USA (fus)
Page 17 Entertainment Systems Tune selector: Press to manually increase/decrease the radio frequency. 2. Phone/mute: Press to mute the playing media. Press again to return to the playing media. 3. Menu: Press MENU to access the main menu functions. Use the Tune selector ( ) or SEEK...
Page 18 Entertainment Systems Speed sensitive volume: Radio volume automatically adjusts according to vehicle speed to compensate for road and wind noise. Press the Tune selector ( ) or SEEK to turn off or select rates 1 through 7. Rate 7 compensates the most volume at higher speeds. Setting the clock: Upon initial battery connect, this function is displayed first among MENU functions.
Page 19 Entertainment Systems 10. Fast forward: Press and hold to manually advance the CD. 11. Rewind: Press and hold to manually reverse the CD. 12. Memory presets: To set a station: Select frequency band AM/FM1/FM2; tune to a desired station, press and hold the preset button until the display shows that the preset is set.
Page 20 Entertainment Systems AM/FM Stereo with In–dash 6CD —Premium /Audiophile (if equipped) Tune Selector: Press to manually increase/decrease the radio frequency when in tuner mode or to choose a different disc when in CD mode with multiple discs in the changer. 2.
Page 21 Entertainment Systems To activate RDS, press and hold MENU until RDS ON or RDS OFF appears in the display. Press MENU again to continue to FIND and SHOW functions. Press the Tune Selector ( ) or SEEK toggle RDS on/off and to scroll through the FIND and SHOW functions. Track/Folder mode:Available only on MP3 discs in CD mode.
Page 22 Entertainment Systems 5. Seek up: Press for next strong station or CD track. Press and hold for continuous seek functionality. 6. Text: Press in CD mode to display track title, artist and album title. This feature will only function if the CDs are manufactured with the CD text feature. 7.
Page 23 Entertainment Systems 16. ON/OFF/Volume: Press to turn ON/OFF; turn to increase/decrease the volume levels. If the volume is set above a certain level and the ignition is turned off, for at least a minute, the volume will come back on at a “nominal” listening level when the ignition switch is turned back 17.
Page 24 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 25: Climate Controls
Climate Controls HEATER ONLY SYSTEM (IF EQUIPPED) 1. Air flow selections: Controls the direction of the airflow in the cabin. See the following for a brief description on each control. : Distributes air through the instrument panel vents. : Distributes air through the instrument panel vents and the floor vents.
Page 26: Manual Heating And Air Conditioning
Climate Controls 2. Adjust the temperature control to maintain comfort. 3. Set the fan speed to the highest setting. 4. Direct the outer instrument panel vents toward the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.
Page 27 Climate Controls 5. A/C: Provides cabin cooling. 6. Temperature selection: Controls the temperature of the airflow in the cabin. Max A/C: For maximum cabin cooling performance, select A/C (5) (4). Operating tips • To reduce fog build up on the windshield during humid weather, place the air flow selector in the position and turn the fan on.
Page 28: Rear Window Defroster
Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. • A small LED will illuminate when the rear defroster is activated. The ignition must be in the ON position to operate the rear window defroster.
Page 29: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. High beams Pull the lever towards you to activate. Pull the lever towards you again to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate.
Page 30 Lights Foglamp control (if equipped) The headlamp control also operates the foglamps. The foglamps can be turned on when the headlamp control is in the or the position and the high beams are not turned on. Pull headlamp control towards you to turn foglamps on.
Page 31: Turn Signal Control
Lights 4. On the wall or screen you will observe an area of high intensity light. The top of the high intensity area should touch the horizontal reference line. If not, the beam will need to be adjusted. 5. Locate the vertical adjuster on each headlamp, then use a 7 mm Allen wrench or a Phillips screwdriver to adjust the headlamp...
Page 32: Bulb Replacement
Lights Reading lamps (if equipped) The reading lamps are operated by separate on/off controls. Theater dimming: The dome lamp dims about 20 seconds after the doors are closed. BULB REPLACEMENT Headlamp Condensation The headlamps are vented to equalize pressure. When moist air enters the headlamp(s) through the vents, there is a possibility that condensation can occur.
Page 33 Lights Function Trade number High-mount brakelamp Dome lamp (front/rear) 12V10W Map lamp 12V6W Luggage compartment 12V10W To replace all instrument panel lights - see your authorized dealer Replacing exterior bulbs Check the operation of all the bulbs frequently. Replacing headlamp bulbs 1.
Page 34 Lights Replacing front parking lamp/turn signal bulbs 1. Make sure the headlamp control is in the OFF position and open the hood. 2. Remove the bulb socket from the lamp assembly by turning counterclockwise. 3. Pull the bulb straight out of the socket.
Page 35 Lights Replacing tail/brake/backup lights and turn signal bulbs (sedan) 1. Make sure the headlamp control is in the OFF position and then open the trunk. 2. From inside the luggage compartment remove the three wing nuts of the light housing. 3.
Page 36 Lights Replacing side marker bulbs 1. Make sure the headlamp control is in the OFF position. 2. Remove the front shield from the bumper. 3. Reach under the front fender, grasp the bulb socket and turn it counterclockwise to remove it. 4.
Page 37 Lights 3dr & 5dr and wagon 1. Make sure the headlamp control is in the OFF position. 2. Remove the screws using a Torx T20 screwdriver and then remove the plastic cover. 3. Unclip the bulb holder from the reflector. 4.
Page 38 Lights Replacing interior lamps 1. Make sure the headlamp switch is in the OFF position. 2. Switch off the interior lamps. 3. Pry out the light assembly with a flat screwdriver at the side opposite the switch. Install in reverse order. Replacing reading bulbs 1.
Page 39: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Move the lever down for a single wipe. For intermittent operation, move control up one position and adjust the rotary control to the desired speed. For normal operation, move control up two positions. For high speed operation, move control up three positions. Mist function: To mist, push and release the windshield washer control quickly.
Page 40 Driver Controls TILT AND TELESCOPE STEERING COLUMN (IF EQUIPPED) Pull the locking lever down to adjust and telescope the steering column position. Return the lever to its original position to secure the wheel. The telescope function is adjusted by moving the wheel toward the driver to telescope out and toward the instrument panel to telescope in.
Page 41 Driver Controls Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: • Place the VELCRO hook onto the side of the aftermarket transmitter opposite of the button. •...
Page 42: Power Windows
Driver Controls To prevent the battery from being discharged, do not use the power point longer than necessary when the engine is not running. Always keep the power point caps closed when not being used. Cigar lighter (if equipped) Do not plug optional electrical accessories into the cigarette lighter socket.
Page 43: Mirrors
Driver Controls Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the rear window controls slide the control to the left. Slide the control to the right to restore the window controls. EXTERIOR MIRRORS Power side view mirrors (if equipped) To adjust your mirrors:...
Page 44 Driver Controls Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved. Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release 2.
Page 45 Driver Controls Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 30 mph (48 km/h). Increasing speed while using speed control There are two ways to set a higher speed:...
Page 46 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET ACCEL control. Turning off speed control Press the speed control OFF control. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased.
Page 47 Driver Controls the instrument panel to seek to the next radio station down the frequency band or the previous CD track. • MODE: Press and hold to toggle through AM/FM1/FM2/CD modes. Press and release to move to the next preset radio station, or the next Press in all modes to abort a traffic message during broadcasting.
Page 48 Driver Controls Before operating the moonroof you should verify that it is free of obstructions and ensure that children and/or pets are not in the proximity of moon roof opening. Do not let children play with the moon roof or leave children unattended in the vehicle.
Page 49 Driver Controls POSITIVE RETENTION FLOOR MAT Do not install additional floor mats on top of the factory installed floor mats as they may interfere with the accelerator or the brake pedals. Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in.
Page 50 Driver Controls To reduce the risk of injury, the luggage cover must be properly attached to the mounting clips. Do not place any objects on the cargo area cover. They may obstruct your vision or strike occupants of the vehicle in the case of a sudden stop or collision.
Page 51 Driver Controls LUGGAGE RACK (IF EQUIPPED) The maximum recommended load is 220 lbs (100 kg) on the luggage rack structure. The load must be placed directly on the dealer installed cross-bars (if equipped) and luggage rack. The vehicle’s roof panel is not designed to carry a load.
Page 52: Locks And Security
Locks and Security KEYS The key operates all locks on your vehicle. You should always carry a second key with you in a safe place in case you require it in an emergency. Your keys are coded to your vehicle; using a non-coded key will not permit your vehicle to start.
Page 53 Locks and Security To deactivate/reactivate the autolock feature using the power door unlock control You must complete steps 1-7 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, you must wait 30 seconds. 1.
Page 54 Locks and Security CHILDPROOF DOOR LOCKS (IF EQUIPPED) • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 55 Locks and Security To open the luggage compartment door (lid) from within the luggage compartment, pull the illuminated “T” shaped handle and push up on the trunk lid. The handle is composed of a material that will glow for hours in darkness following brief exposure to ambient light.
Page 56 Locks and Security REMOTE ENTRY SYSTEM (IF EQUIPPED) This device complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 57 Locks and Security Unlocking the doors 1. Press and release to unlock the driver’s door. Note: The interior lamps will illuminate. 2. With the all-door remote entry, press and release again within three seconds to unlock all the doors. The remote entry system activates the illuminated entry feature. This feature turns on the interior lamps for 25 seconds or until the ignition is turned to the 3 (ON) position.
Page 58 Locks and Security Opening the luggage compartment Press once to open the luggage compartment. Note: This feature will only operate with the ignition in the 1 (LOCK) or the 2 (OFF) position. • Ensure that the trunk is closed and latched before driving your vehicle.
Page 59 Locks and Security 4. Insert the new battery. Refer to the diagram inside the remote entry transmitter for the correct orientation of the battery. Press the battery down to ensure that the battery is fully seated in the battery housing cavity.
Page 60: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 61 Locks and Security Replacing coded keys can be very costly. Store an extra programmed key away from the vehicle in a safe place to help prevent any inconveniences. Please visit an authorized dealer to purchase additional spare or replacement keys. Programming spare keys You can program your own coded keys to your vehicle.
Page 62 Locks and Security 10. Turn the ignition from the 2 (OFF) position to the 3 (ON) position. Keep the ignition in the 3 (ON) position for at least one second, but no more than 10 seconds. 11. Your new, unprogrammed key is now programmed. If the key has been successfully programmed it will start the vehicle’s engine and the theft indicator light will illuminate for three seconds and then go out.
Page 63 Locks and Security Triggering the anti-theft system The armed system will be triggered if any door, liftgate/trunk or the hood is opened without using the key or the remote entry transmitter. 2006 Focus (foc) Owners Guide (post-2002-fmt) USA (fus)
Page 64: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 65 Seating and Safety Restraints Adjusting the front manual seat Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the passenger sensing system, resulting in serious injury or death in a crash.
Page 66 Seating and Safety Restraints Lift the control to adjust the angle of the seatback. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Heated seats (if equipped) The heated seats switch is located on the center console.
Page 67 Seating and Safety Restraints Tip/slide front seat (3–door) Lift the control and fold the seatback forward. The seat can be slid forward to allow easier entry to the rear seats. Slide the seat back and fold back the seatback until it locks with a distinct click.
Page 68 Seating and Safety Restraints Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision.
Page 69: Safety Restraints
Seating and Safety Restraints Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision.
Page 70 Seating and Safety Restraints Your vehicle’s Personal Safety System consists of: • Driver and passenger dual-stage airbag supplemental restraints. • Front safety belts with pretensioners, energy management retractors, and safety belt usage sensors. • Driver’s seat position sensor. • Front crash severity sensor. •...
Page 71 Seating and Safety Restraints Front crash severity sensor The front crash severity sensor enhances the ability to detect the severity of an impact. Positioned up front, it provides valuable information early in the crash event on the severity of the impact. This allows your Personal Safety System to distinguish between different levels of crash severity and modify the deployment strategy of the...
Page 72 Seating and Safety Restraints restrain children in the rear seat. The sensor also turns off the airbag when the passenger seat is empty to prevent unnecessary replacement of the airbag(s) after a collision. When the front passenger seat is occupied and the sensing system has turned off the passenger’s frontal airbag, the “pass airbag off”...
Page 73 Seating and Safety Restraints • The warning light will either flash or stay lit. • The warning light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and warning light are repaired.
Page 74 Seating and Safety Restraints Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only.
Page 75 Seating and Safety Restraints The front outboard and rear safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat safety belts have two types of locking modes. Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 76 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford Motor Company recommends that all passenger safety belt assemblies and attaching hardware should be inspected by an authorized dealer after any collision to verify that the automatic locking retractor feature for child seats is still working properly.
Page 77 Seating and Safety Restraints Three door models are equipped with a safety belt parking feature for the driver and front passenger. The purpose of the parking feature is to allow the driver or passenger to reach the safety belt. Fasten your safety belt as normal, and the belt will slide to the front of the steel bar along the bottom of the door.
Page 78 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 79 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
Page 80 Seating and Safety Restraints If... Then... The driver’s and front The BeltMinder feature will not passenger’s safety belts are activate. buckled before the ignition switch is turned to the ON position or less than 1-2 minutes have elapsed since the ignition switch has been turned ON...
Page 81 Seating and Safety Restraints Reasons given... Consider... “Belts are uncomfortable” We design our safety belts to enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 82 Seating and Safety Restraints Do not sit on top of a buckled safety belt to avoid the BeltMinder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the BeltMinder feature please follow the directions stated below. One time disable If at any time the driver/front passenger quickly buckles then unbuckles the safety belt for that seating position, the BeltMinder is disabled for...
Page 83: Airbags
Seating and Safety Restraints • Step 3 must be completed within 50 seconds after the safety belt warning light turns off. 3. For the seating position being disabled, at a moderate speed, buckle then unbuckle the safety belt 9 times, ending in the unbuckled state. (Step 3 must be completed within 50 seconds after the safety belt warning light turns off.) •...
Page 84 Seating and Safety Restraints Airbags DO NOT inflate slowly or gently, and the risk of injury from a deploying airbag is the greatest close to the trim covering the airbag module. Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries.
Page 85 Seating and Safety Restraints Do not put anything on or over the airbag module. Placing objects on or over the airbag inflation area may cause those objects to be propelled by the airbag into your face and torso causing serious injury. Do not attempt to service, repair, or modify the airbag supplemental restraint systems or its fuses.
Page 86 Seating and Safety Restraints How does the airbag supplemental restraint system work? The airbag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates airbag inflation. The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system.
Page 87 Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 88 Seating and Safety Restraints • the system determines that a small child is present in a forward-facing child restraint that is installed according to the manufacturer’s instructions, • the system determines that a small child is present in a booster seat, •...
Page 89 Seating and Safety Restraints • When the front passenger sensing system enables the front passenger frontal airbag (may inflate), the indicator will be unlit and stay unlit. If a person of adult size is sitting in the front passenger’s seat, but the passenger airbag off or pass airbag off indicator lamp is lit, it is possible that the person isn’t sitting properly in the seat.
Page 90 Seating and Safety Restraints The front passenger sensing system may detect small or medium objects placed on the seat cushion. For most objects that are in the front passenger seat, the passenger airbag will be disabled. Even though the passenger airbag is disabled, the pass airbag off lamp may or may not be illuminated according to the table below.
Page 91 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Guide.
Page 92 Seating and Safety Restraints Any alteration/modification to the front passenger seat may affect the performance of the front passenger sensing system. Determining if the system is operational The supplemental restraint system uses a warning indicator light in the instrument cluster or a back-up tone to indicate the condition of the system.
Page 93 Seating and Safety Restraints Do not attempt to service, repair, or modify the airbag SRS, its fuses or the seat cover on a seat containing an airbag. See your authorized dealer. All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided.
Page 94: Child Restraints
Seating and Safety Restraints The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system. Rather, it means the forces were not of the type sufficient to cause activation. Side airbags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration.
Page 95 Seating and Safety Restraints Do not leave children, unreliable adults, or pets unattended in your vehicle. Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather, they could burn a small child. Check seat covers and buckles before you place a child anywhere near them.
Page 96 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 97 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 98 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 99 80 lb. (36 kg) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and...
Page 100 Seating and Safety Restraints tether anchors. For more information on top tether straps and anchors, refer to Attaching safety seats with tether straps in this chapter. For more information of LATCH anchors refer to Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments in this chapter.
Page 101 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 102 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 103 Seating and Safety Restraints Attaching child safety seats with tether straps Most new forward-facing child safety seats include a tether strap which goes over the back of the seat and hooks to an anchoring point. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap.
Page 104 Seating and Safety Restraints • On Sedan’s the anchors are located on the rear back panel. • For 3–door/5–door and Wagon, the anchors are located on the back of the rear seat. 4. On a sedan, open the tether anchor cover. 5.
Page 105 Seating and Safety Restraints 7. Tighten the child safety seat tether strap according to the manufacturer’s instructions. If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. Attaching child safety seats with Lower Anchor and Tethers for Children (LATCH) attachments for child seat anchors Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at specific seating positions in your vehicle.
Page 106 Seating and Safety Restraints The LATCH anchors are located on the rear section of the seat cushion, at the bottom of the seatback. Follow the child seat manufacturer’s instructions to properly install safety seats with LATCH attachments. Attach the LATCH lower attachments of the child seat only to the appropriate locations shown.
Page 107: Tires, Wheels And Loading
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 108 Tires, Wheels and Loading The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 109: Tire Inflation
(including spare, if equipped). Inflate all tires to the inflation pressure recommended by Ford Motor Company. Use a tire gauge to check the tire inflation pressure, including the spare (if equipped), at least monthly and before long trips. You are strongly...
Page 110 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 111: Tire Information
Tires, Wheels and Loading To check the pressure in your tire(s): 1. Make sure the tires are cool, meaning they are not hot from driving even a mile. Note: If you have to drive a distance to get air for your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump.
Page 112 Tires, Wheels and Loading Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Inspect all your tires, including the spare, frequently, and replace them if one or more of the following conditions exist: Tire wear When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to help prevent your vehicle from skidding and...
Page 113 Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 114 Tires, Wheels and Loading Never spin the tires in excess of the 35 mph (55 km/h) point indicated on the speedometer. Highway hazards No matter how carefully you drive there’s always the possibility that you may eventually have a flat tire on the highway. Drive slowly to the closest safe area out of traffic.
Page 115 Tires, Wheels and Loading • Front Wheel Drive (FWD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 116 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 117 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
Page 118 Tires, Wheels and Loading 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
Page 119 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 120 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 121: Vehicle Loading
Snow cable type chains should only be fitted to size P185/60R15 tires. P185/60R15 tires are not offered by Ford as original equipment. To operate the vehicle with snow chains these tires must be purchased and mounted separately.
Page 122 Tires, Wheels and Loading Vehicle Curb Weight – is the weight of your new vehicle when you picked it up from your authorized dealer plus any aftermarket equipment. Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment.
Page 123 Tires, Wheels and Loading GVW (Gross Vehicle Weight) – is the Vehicle Curb Weight + cargo + passengers. GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or...
Page 124 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 125 Tires, Wheels and Loading 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs. 4. The resulting figure equals the available amount of cargo and luggage load capacity.
Page 126: Trailer Towing
Tires, Wheels and Loading 1400 – (2 x 220) – (9 x 100) = 1400 – 440 – 900 = 60 lb. Now you have the load capacity to transport the cement and your friend home. In metric units, the calculation would be: 635 kg — (2 x 99 kg) — (9 x 45 kg) = 635 —...
Page 127 Tires, Wheels and Loading Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transaxle damage, structural damage, increased risk of loss of vehicle control, vehicle rollover and/or serious personal injury. Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle.
Page 128 Tires, Wheels and Loading authorized dealer or trailer rental agency for proper instructions and equipment for hooking up trailer lamps. Driving while you tow When towing a trailer: • Turn off the speed control. The speed control may shut off automatically when you are towing on long, steep grades.
Page 129: Recreational Towing
Tires, Wheels and Loading RECREATIONAL TOWING Follow these guidelines for your specific powertrain combination to tow your vehicle with all four wheels on the ground (such as behind a recreational vehicle). These guidelines are designed to ensure that your transmission is not damaged due to insufficient lubrication.
Page 130: Driving
Driving STARTING Positions of the ignition 1. LOCK, locks the steering wheel, automatic transaxle gearshift lever and allows key removal. 2. OFF, shuts the engine and all electrical accessories off without locking the steering wheel. 3. ON, all electrical circuits operational.
Page 131 Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions When the engine starts, the idle RPM runs faster to warm the engine. If the engine idle speed does not slow down automatically, have the vehicle checked.
Page 132 Driving If starting a vehicle with a manual transaxle: 1. Make sure the parking brake is set. 2. Push the clutch pedal to the floor. • Turn the key to 3 (ON) without turning the key to 4 (START). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights.
Page 133: Brakes
Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important ventilating information If the engine is idling while the vehicle is stopped for a long period of time, open the windows at least one inch (2.5 cm) or adjust the heating or air conditioning to bring in fresh air.
Page 134 Driving Four-wheel anti-lock brake system (ABS) (if equipped) Your vehicle may be equipped with an Anti-lock Braking System (ABS). This system helps you maintain steering control during emergency stops by keeping the brakes from locking. Noise from the ABS pump motor and brake pedal pulsation may be observed during ABS braking;...
Page 135: Traction Control
Driving The BRAKE warning lamp will illuminate and will remain illuminated until the parking brake BRAKE is released. To release, press and hold the button (2), pull the handle up slightly, then push the handle down. Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park) (automatic transmission) or in 1 (First) (manual transmission).
Page 136: Transmission Operation
Driving The Traction Control switch is located on the center console, by the gearshift lever. The Traction Control system will automatically turn on every time the ignition is turned off and on. If you should become stuck in snow or ice or on a very slippery road surface, try switching the Traction Control system off by pressing the switch.
Page 137 Driving If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1. Apply the parking brake, turn ignition key to LOCK, then remove the key. When the key is in the ignition and in the OFF position, the automatic transmission shift lever can be moved from the P (Park) position without the brake pedal depressed.
Page 138 Driving Understanding the gearshift positions of the 4–speed automatic transaxle This vehicle is equipped with an adaptive Transmission Shift Strategy. Adaptive Shift Strategy offers the optimal transmission operation and shift quality. When the vehicle’s battery has been disconnected for any type of service or repair, the transmission will need to relearn the normal shift strategy parameters, much like having to reset your radio stations when your vehicle battery has been disconnected.
Page 139 Driving R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll.
Page 140 Driving • Will not downshift into 1 (First) at high speeds; allows for 1 (First) when vehicle reaches slower speeds. If your vehicle gets stuck in mud or snow If your vehicle gets stuck in mud or snow, it may be rocked out by shifting between forward and reverse gears, stopping between shifts in a steady pattern.
Page 141 Driving Recommended shift speeds Upshift according to the following chart: Recommended upshifts (for best fuel economy) when accelerating 5-speed manual transaxle Shift from: 1 - 2 14 mph (23 km/h) 2 - 3 24 mph (39 km/h) 3 - 4 32 mph (51 km/h) 4 - 5 44 mph (71 km/h)
Page 142 Driving DRIVING THROUGH WATER If driving through deep or standing water is unavoidable, proceed very slowly especially when the depth is not known. Never drive through water that is higher than the bottom of the wheel rims (for cars) or the bottom of the hubs (for trucks).
Page 143: Roadside Emergencies
36,000 miles (60,000 km), whichever occurs first on Ford and Mercury vehicles, and four years or 50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start •...
Page 144 1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1–800–241–3673;...
Page 145: Fuel Pump Shut-Off Switch
Roadside Emergencies FUEL PUMP SHUT-OFF SWITCH This device stops the electric fuel pump from sending fuel to the engine when your vehicle has had a substantial jolt. After an accident, if the engine cranks but does not start, this switch may have been activated.
Page 146 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 147 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description — Starter relay — Not used — Not used — Not used — Daytime running lamps — Not used — Not used —...
Page 148 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Sunroof Horn 7.5A A/C switch, Instrument cluster 7.5A Interior lamps, Power mirrors — Not used — Not used PCM relay coil Rear defroster — Not used Stop lamps, Shift interlock Rear wiper, Sunroof (ignition) —...
Page 149 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 7.5A PATS modules, Instrument cluster 7.5A Radio (Start) Power locks (GEM) Fuse 63 is located on the back of the fuse panel. See your authorized dealer for service of this fuse. Power distribution box The power distribution box is located in the engine compartment.
Page 150 Roadside Emergencies To remove a fuse, use the fuse puller tool provided on the power distribution box cover. The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description Main power supply (to passenger compartment fuse panel) —...
Page 151 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description Fuel pump motor Anti-lock Brake System (ABS) (valves) — Not used — Not used Low beam (left-hand side) Low beam (right-hand side) Heated Exhaust Gas Oxygen (HEGO) sensors Heater blower motor Engine module (KAP) Low beams High beams, Fog lamps...
Page 152 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 153 Roadside Emergencies 1. T-type mini-spare: This spare tire begins with the letter “T” for tire size and may have “Temporary Use Only” molded in the sidewall 2. Full-size dissimilar spare with label on wheel: This spare tire has a label on the wheel that states: “THIS TIRE AND WHEEL FOR TEMPORARY USE ONLY”...
Page 154 Roadside Emergencies • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability • All-Wheel driving capability (if applicable) • Load leveling adjustment (if applicable) When driving with the full-size dissimilar spare tire/wheel additional caution should be given to: •...
Page 155 Roadside Emergencies If the vehicle slips off the jack, you or someone else could be seriously injured. 2. Place gearshift lever in P (Park) (automatic transaxle) or R (Reverse) (manual transaxle), turn engine OFF, and block the diagonally opposite wheel. 3.
Page 156 Roadside Emergencies 5. If equipped with a 6–spoke wheel cover that’s bolted on, remove the four plastic nuts by turning counterclockwise 1/4 turn for access to the lug nuts. Note: To avoid damage to the wheel cover, the 6–spoke wheel cover cannot be removed until the tire is off the vehicle.
Page 157: Lug Nut Torque
M12 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 158: Jump Starting
Roadside Emergencies JUMP STARTING The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Batteries contain sulfuric acid which can burn skin, eyes and clothing, if contacted. Do not attempt to push-start your vehicle.
Page 159 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 160 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 161 Roadside Emergencies 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 162 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 163: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If your vehicle is to be towed from the rear using wheel lift equipment, the front wheels (drive wheels) must be placed on a dolly to prevent damage to the transmission.
Page 164: Customer Assistance
Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 165 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 166 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the BBB...
Page 167 You are not bound by the decision but may choose to accept it. If you choose to accept the BBB AUTO LINE decision then Ford must abide by the accepted decision as well. If the arbitrator has decided in...
Page 168 United States and Canada, provided by a network of more than 4,600 participating authorized dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this...
Page 169 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 170: Reporting Safety Defects (U.s. Only)
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your authorized dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 171: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 172 Cleaning WAXING Applying Motorcraft Paint Sealant (ZC-45) to your vehicle every six months will assist in reducing minor scratches and paint damage. • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product.
Page 173 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 174 Cleaning WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly. If the wipers do not wipe properly, substances on the vehicle’s glass or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, water repellant coatings, tree sap, or other organic contamination;...
Page 175 Cleaning INTERIOR For fabric, carpets, cloth seats, safety belts and seats equipped with side airbags: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Motorcraft Professional Strength Carpet & Upholstery Cleaner (ZC-54). •...
Page 176 Cleaning FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 177: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service.
Page 178 Maintenance and Specifications Working with the engine on • Automatic transmission: 1. Set the parking brake and shift to P (Park). 2. Block the wheels. • Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral).
Page 179: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.0L/2.3L I4 Engines 1. Windshield washer fluid reservoir 2. Engine coolant reservoir 3. Engine oil filler cap 4. Brake/Clutch fluid reservoir 5. Power distribution box 6. Battery 7. Automatic transaxle fluid dipstick (if equipped) 8.
Page 180 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 181: Engine Oil
Maintenance and Specifications Poor wiper quality can be improved by cleaning the wiper blades and the windshield, refer to Windows and wiper blades in the Cleaning chapter. To prolong the life of the wiper blades, it is highly recommended to scrape off the ice on the windshield before turning on the wipers.
Page 182 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine’s warranty use Motorcraft SAE 5W-20 or an equivalent 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 183: Battery
Change your engine oil and filter according to the appropriate schedule listed in scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 184 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 185: Engine Coolant
Maintenance and Specifications If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 186 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 187 Motorcraft Premium Gold Engine Coolant from yellow to golden tan. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine Coolant or any orange-colored extended life product with your factory filled coolant can result in degraded corrosion protection.
Page 188 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 189 Maintenance and Specifications Severe climates If you drive in extremely cold climates (less than –34° F [–36° C ]): • It may be necessary to increase the coolant concentration above 50%. • NEVER increase the coolant concentration above 60%. • Increased engine coolant concentrations above 60% will decrease the overheat protection characteristics of the engine coolant and may cause engine damage.
Page 190 Maintenance and Specifications How fail-safe cooling works If the engine begins to overheat: • The engine coolant temperature gauge will move to the red (hot) area. • The “Check Engine” indicator light will illuminate. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation.
Page 191 Maintenance and Specifications FUEL FILTER For fuel filter replacement, see your authorized dealer. Refer to scheduled maintenance information for the appropriate intervals for changing the fuel filter. Replace the fuel filter with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used.
Page 192 Maintenance and Specifications • Extinguish all smoking materials and any open flames before refueling your vehicle. • Always turn off the vehicle before refueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 193 Maintenance and Specifications Refueling Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 194 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 195 Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 196 Maintenance and Specifications • The indicator may come on. For more information on the “check engine” or the “service engine soon” indicator, refer to Warning lights and chimes in the Instrument Cluster chapter. ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver.
Page 197 Maintenance and Specifications • Have the vehicle loading and distribution the same every time. Your results will be most accurate if your filling method is consistent. Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in miles or kilometers).
Page 198 Maintenance and Specifications • Revving the engine before turning it off may reduce fuel economy. • Using the air conditioner or defroster may reduce fuel economy. • You may want to turn off the speed control in hilly terrain if unnecessary shifting between third and fourth gear occurs.
Page 199 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 200 Maintenance and Specifications Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 201 Maintenance and Specifications Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system. If the indicator is on, refer to the description in the Warning lights and chimes section of the Instrument Cluster chapter.
Page 202 Maintenance and Specifications BRAKE/CLUTCH FLUID Brake and clutch systems are supplied from the same reservoir. The fluid level will drop slowly as the brakes wear, and will rise when the brake components are replaced. Fluid levels between the “MIN” and “MAX”...
Page 203 Maintenance and Specifications 6. Install the dipstick making sure it is fully seated in the filler tube. 7. Remove the dipstick and inspect the fluid level. The fluid should be in the designated areas for normal operating temperature. Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the outside temperatures are...
Page 204 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to Lubricant specifications in this chapter. 2006 Focus (foc) Owners Guide (post-2002-fmt)
Page 205: Part Numbers
PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 206: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid Motorcraft High Fill to line on and clutch Performance reservoir fluid DOT 3 Motor Vehicle Brake Fluid Engine Motorcraft 2.0L engine 6.1 quarts (5.75L) coolant Premium Gold Engine Coolant 2.3L engine...
Page 207 Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the requirements of Ford specification WSS-M2C930-A and the API Certification mark. 2006 Focus (foc)
Page 208: Lubricant Specifications
Maintenance and Specifications LUBRICANT SPECIFICATIONS Ford Part Ford Part Ford Item Name or Number Specification Equivalent Brake fluid Motorcraft High PM-1 or PM-1-C ESA-M6C25-A Performance DOT 3 Motor WSS-M6C62-A Vehicle Brake Fluid Door latch, hood Multi-Purpose XG-4 or XL-5 ESB-M1C93–B...
Page 209 Maintenance and Specifications Ford Part Ford Part Ford Item Name or Number Specification Equivalent Engine coolant Motorcraft VC-7-A (U.S., WSS- Premium Gold except CA, OR M97B51-A1 Engine Coolant and NM), (yellow-colored) VC-7-B (CA, OR and NM) Cooling system Motorcraft VC-6...
Page 210 Maintenance and Specifications VEHICLE DIMENSIONS Vehicle Sedan - inches 3dr/5dr - Wagon - dimensions (mm) inches (mm) inches (mm) (1) Overall length 175.2 (4450) 168.5 (4279) 178.5 (4533) (2) Overall width 78.7 (1998) 78.7 (1998) 78.7 (1998) (3) Overall height 57.1 (1451) 57.2 (1452) 59.4 (1509)
Page 211 Maintenance and Specifications • 3dr/5dr 2006 Focus (foc) Owners Guide (post-2002-fmt) USA (fus)
Page 212 Maintenance and Specifications • Wagon IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure by the trailing edge of the driver’s door or...
Page 213 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. Please note that in the graphic, XXXX is representative of your vehicle identification number. The Vehicle Identification Number (VIN) contains the following information: 1.
Page 214 Maintenance and Specifications TRANSMISSION/TRANSAXLE CODE DESIGNATIONS You can find a transmission/transaxle code on the Safety Compliance Certification Label. The following table tells you which transmission or transaxle each code represents. Description Code Four-speed automatic Five-speed manual (MTX75) 2006 Focus (foc) Owners Guide (post-2002-fmt) USA (fus)
Page 215: Accessories
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 216 Accessories Interior style Electrochromatic compass/temperature interior mirrors Floor mats Scuff plates Speed control Lifestyle Bike racks Cargo organization and management Peace of mind First aid and highway safety kits Full vehicle covers Keyless entry keypads Locking gas cap Mobile-Ease hands free communication system Remote start Vehicle security systems Wheel locks...
Page 217 Accessories • To avoid interference with other vehicle functions, such as anti-lock braking systems, amateur radio users who install radios and antennas onto their vehicle should not locate the Amateur Radio Antennas in the area of the driver’s side hood. •...
Page 218: Index
Index maintenance-free ....183 replacement, specifications ...205 Air cleaner filter .......205 servicing ........183 Airbag supplemental restraint BeltMinder ........79 system ......83–84, 92 and child safety seats ....85 Brakes ........133–134 description ......84, 92 anti-lock ........134 disposal ........94 anti-lock brake system driver airbag ......86, 93 (ABS) warning light ....134 indicator light ......92 fluid, checking and adding ..202...
Page 219 Cruise control specifications ....208–209 (see Speed control) ....43 refill capacities ......206 Customer Assistance ....143 service points ......179 Ford Extended Service starting after a collision ..145 Plan ..........168 Engine block heater ....133 Getting assistance outside Engine fan .........179 the U.S. and Canada ....169 Getting roadside assistance ...143...
Page 220 Index Fuel ..........191 Heating calculating fuel economy ..196 heater only system ....25 cap ...........193 Hood ..........178 capacity ........206 choosing the right fuel ...194 comparisons with EPA fuel economy estimates ....199 Ignition .......130, 209–210 detergent in fuel .....195 filling your vehicle Infant seats with fuel ....191, 193, 196 (see Safety seats) .......99...
Page 221: Remote Audio Controls
Index Lane change indicator Power distribution box (see Turn signal) ......31 (see Fuses) .......149 Power door locks ......52 Liftgate ........50 Power mirrors ......43 Lights, warning and indicator ..10 anti-lock brakes (ABS) ..134 Power point .........41 Load limits .........121 Power steering ......136 fluid, checking and adding ..201 Locks fluid, refill capacity ....206...
Page 222 Index Occupant Classification label .........120 Sensor ........71 replacing ........113 safety belt maintenance ...78 rotating ........114 warning light and chime ..78–79 safety practices .......113 sidewall information ....115 Safety seats for children ....99 snow tires and chains ....120 Safety Compliance spare tire .........152 Certification Label ....212 terminology ......108 Seat belts...
Page 223 Index Washer fluid ......180 Windshield washer fluid and wipers Water, Driving through .....142 checking and adding fluid ..180 Windows operation ........39 replacing wiper blades ...180 power .........42 rear wiper/washer .....39 Wrecker towing ......163 2006 Focus (foc) Owners Guide (post-2002-fmt) USA (fus)

Ford Focus 2006 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Quick Links

Table of Contents

Related Manuals for Ford Focus 2006

Summary of Contents for Ford Focus 2006

Table of Contents
