Page 1 Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems AM/FM stereo AM/FM stereo with CD AM/FM stereo cassette with CD AM/FM stereo with in-dash six CD Climate Controls Heater only Manual heating and air conditioning Automatic temperature control Rear window defroster Lights Headlamps...
Page 2: Table Of Contents
Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire Information Tire Inflation Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction control Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires...
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 7 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 8 Introduction Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Notice to owners of pickup trucks and utility type vehicles Utility vehicles have a significantly higher rollover rate than other types of vehicles.
Page 9 Introduction Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Airbag - Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor...
Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Base instrument cluster Base with Tachometer instrument cluster 2006 F-150 (f12) Owners Guide (post-2002-fmt) USA (fus)
Page 13 Instrument Cluster Family carrier instrument cluster Mid instrument cluster 2006 F-150 (f12) Owners Guide (post-2002-fmt) USA (fus)
Page 14 Instrument Cluster Luxury instrument cluster Harley-Davidson instrument cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 15 Instrument Cluster Service engine soon: The Service engine soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter.
Page 16 Instrument Cluster Mid and Luxury instrument cluster If the brake system warning light BRAKE does not illuminate at this time, seek service immediately from your authorized dealer. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your authorized dealer.
Page 17 Instrument Cluster Door ajar: Illuminates when the ignition is in the ON position and any door is open. Overdrive off (if equipped): Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily or does not illuminate, have the transmission serviced soon, or damage may occur.
Page 18 Instrument Cluster MINI MESSAGE CENTER WARNING DISPLAYS (IF EQUIPPED) Door ajar: Displays when the ignition is in the ON position and any door is open. Low fuel: Displays when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter).
Page 19: Gauges
Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating.
Page 20 Instrument Cluster Odometer: Registers the total miles (kilometers) of the vehicle. • With Mini Message Center • With Full Message Center Refer to Message Center in the Drivers Controls chapter on how to switch the display from Metric to English. Trip odometer: Registers the miles (kilometers) of individual journeys.
Page 21 Instrument Cluster Engine oil pressure gauge: Indicates engine oil pressure. The needle should stay in the normal operating range (between “L” and “H”). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level.
Page 22: Entertainment Systems
Entertainment Systems AUDIO SYSTEMS AM/FM Stereo System (if equipped) Tune: Press to manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Audio: Press to access select various settings. Treble: Press to adjust the treble setting. Use SEEK, SEEK Bass: Press to adjust the bass setting.
Page 23 Entertainment Systems Setting the clock: Press until HR or Mn is displayed. Press SEEK to adjust the hours/minutes. 3. Seek: Press to access the next/previous strong station. 4. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns.
Page 24 Entertainment Systems AM/FM Stereo Single CD/Satellite Compatible Sound System (if equipped) AM/FM Stereo Single CD with MP3/Satellite Compatible Sound System (late availability — if equipped) 2006 F-150 (f12) Owners Guide (post-2002-fmt) USA (fus)
Page 25 Entertainment Systems Tune: In radio mode, press to manually go up ( ) or down ( ) the radio frequency. In menu mode, use to select various settings. In Satellite Radio mode (if equipped), press to enter TEXT MODE and scroll through the current song title, artist, channel category and Sirius Long Channel Name.
Page 26 Entertainment Systems BASS: Press MENU until BASS appears in the display. Use SEEK to adjust the bass levels. BAL (Balance): Press MENU until BAL appears in the display. SEEK to adjust the audio between the left and right speakers. FADE: Press MENU until FADE appears in the display. Use SEEK to adjust the audio between the front and rear speakers.
Page 27 Entertainment Systems 5. Seek: In radio mode, press to access the previous/next strong station. In CD mode, press access the previous/next CD track. In Satellite Radio mode (if equipped), press SEEK to seek to the previous/next channel. If a specific category is selected, (Jazz, Rock, News, etc.), press SEEK to seek to the previous/next channel in...
Page 28 Entertainment Systems FOLDER: press to access the previous folder on MP3 discs, if folders are available. 10. Fast forward: Press to manually advance in a CD track. 11. Rewind: Press to manually reverse in a CD track. 12. Memory presets: To set a station: Select frequency band AM/FM1/FM2;...
Page 29 Entertainment Systems In Satellite radio mode (if equipped), press and release to enter TEXT MODE and display the current song title. While in TEXT MODE, press again to scroll through the current song title, artist, channel category and the SIRIUS long channel name. In TEXT MODE, sometimes the display requires additional text to be displayed.
Page 30 Entertainment Systems AM/FM Single CD/Cassette/Satellite Compatible Sound System (if equipped) Tune: In radio mode, press to manually go up ( ) or down ( ) the radio frequency. In menu mode, use to select various settings. In Satellite Radio mode (if equipped), press to enter TEXT MODE and scroll through the current song title, artist, channel category and Sirius Long Channel Name .
Page 31 Entertainment Systems 2. Seek: In radio mode, press to access the previous/next strong station. In CD mode, press access the previous/next CD track. In Satellite Radio mode (if equipped), press SEEK to seek to the previous/next channel. If a specific category is selected, (Jazz, Rock, News, etc.), press SEEK to seek to the previous/next channel in...
Page 32 Entertainment Systems BASS: Press MENU until BASS appears in the display. Use SEEK to adjust the bass levels. BAL (Balance): Press MENU until BAL appears in the display. SEEK to adjust the audio between the left and right speakers. FADE: Press MENU until FADE appears in the display. Use SEEK to adjust the audio between the front and rear speakers.
Page 33 Entertainment Systems 7. Text: This control currently not supported. 8. Shuffle: Press to play CD tracks in random order on the selected CD. 9. Compress (Compression): In CD mode, brings soft and loud CD passages together for a more consistent listening level. 10.
Page 34 Entertainment Systems 17. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. 18.
Page 35 Entertainment Systems Premium/Audiophile In-Dash Six CD/MP3/Satellite Compatible Sound System (if equipped) Premium/Audiophile In-Dash Six CD/MP3/Satellite Compatible Sound System (late availability — if equipped) 2006 F-150 (f12) Owners Guide (post-2002-fmt) USA (fus)
Page 36 Entertainment Systems Tune/Disc selector: In radio mode, press to manually go up ) or down ( ) the radio frequency. In menu mode, use to select various settings. In CD mode, press to select the desired disc. In Satellite Radio mode (if equipped), press to enter TEXT MODE and scroll through the current song title, artist, channel category and SIRIUS Long Channel Name.
Page 37 Entertainment Systems TREB (Treble): Press MENU until TREBLE appears in the display. SEEK to adjust the treble levels. BASS: Press MENU until BASS appears in the display. Use SEEK to adjust the bass levels. BAL (Balance): Press MENU until the balance display appears. SEEK to adjust the audio between the left and right speakers.
Page 38 Entertainment Systems To activate, press and hold MENU until RDS (ON/OFF) appears in the display. Use SEEK to toggle RDS ON/OFF. When RDS is on, press MENU repeatedly to scroll through Find, Show and RDS. When RDS is Off, you will not be able to access Find and Show functions. Find: RDS must be activated to access the Find function.
Page 39 Entertainment Systems 5. Seek: In radio mode, press to access the previous/next strong station. In CD mode, press access the previous/next CD track. In Satellite Radio mode (if equipped), press SEEK to seek to the previous/next channel. If a specific category is selected, (Jazz, Rock, News, etc.), press SEEK to seek to the previous/next channel in...
Page 40 Entertainment Systems 11. Rewind: Press to manually reverse in a CD track. 12. Memory presets: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset control until sound returns. You may store up to six stations in each frequency band for a total of 18.
Page 41 Entertainment Systems Satellite radio is available only in the continental United States with a valid SIRIUS subscription. 14. AM/FM: Press to select AM/FM1/FM2 frequency band. 15. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 42 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 43 Entertainment Systems label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your authorized dealer for further information.
Page 44 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 45 Entertainment Systems Radio Display Condition Action Required NO TEXT Artist information not Artist information not available. available at this time on this channel. The system is working properly. NO TEXT Song title information Song title information not not available. available at this time on this channel.
Page 46: Climate Controls
Climate Controls HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 47: Manual Heating And Air Conditioning
Climate Controls 3. Set the fan speed to the highest setting. 4. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
Page 48 Climate Controls Rear defroster (if equipped): Press to defrost the rear window. Refer to Rear window defroster (if equipped) later in this chapter for more information. Heated mirrors (if equipped): Press to activate/deactivate. This function will clear snow, fog and thin ice from the side rear view mirrors. 4.
Page 49: Automatic Temperature Control
Climate Controls Panel ( ) and panel/floor ( ) modes: • Move the temperature control to the coolest setting. • Select A/C and recirculated air ( ). Use recirculated air with A/C to provide colder airflow. • Set the fan to the highest speed initially, then adjust to maintain comfort.
Page 50 Climate Controls Temperature conversion: To switch between Fahrenheit and Celsius: If your vehicle is equipped with a full message center, refer to Setup menu in the Message center section of the Driver Controls chapter for more information. If your vehicle is equipped with a mini message center, see your authorized dealer for temperature conversion.
Page 51 Climate Controls Recirculation control: Press to activate/deactivate air recirculation in cabin. Recirculated air may reduce the amount of time to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle. Recirculation can be engaged manually in any other airflow selection except (defrost).
Page 52 Climate Controls Automatic Temperature Control (ATC) system with heated seats (if equipped) Temperature conversion: To switch between Fahrenheit and Celsius: If your vehicle is equipped with a full message center, refer to Units (Fahrenheit/Celsius) in the Driver Controls chapter. If your vehicle is equipped with a mini message center, refer to Mini message center electronic compass temperature display in the Driver Controls Chapter.
Page 53 Climate Controls MAX A/C: For maximum cooling performance, press , A/C, and set the temperature to 60°F and the highest blower setting. Defrost: Distributes outside air through the windshield defroster vents and demister vents. Can be used to clear the windshield of fog and thin ice.
Page 54 Climate Controls 12. A/C control: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO, (defrost) and (floor/defrost). 13. OFF: Outside air is shut out and the fan will not operate. 14.
Page 55: Rear Window Defroster
Climate Controls Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. REAR WINDOW DEFROSTER (IF EQUIPPED) The rear defroster control is located on the climate control panel and works to defrost your rear window from fog and thin ice.
Page 56: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control clockwise to the first position turn on the parking lamps. Rotate clockwise to the second position to also turn on the headlamps. Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 57 Lights At this point, the headlamps and park lamps will turn off. Foglamp control (if equipped) The headlamp control also operates the foglamps. The foglamps can be turned on only when the headlamp control is in the position and the high beams are not turned on.
Page 58 Lights Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system does not activate the tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
Page 59: Turn Signal Control
Lights 3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood. Cover one of the headlamps so no light hits the wall. 4. On the wall or screen you will observe a light pattern with a distinct horizontal edge towards the right.
Page 60 Lights INTERIOR LAMPS Map lamps To turn on the map lamps, press the control next to each lamp. Rear map lamp (if equipped) The rear map lamp lights are located on the end of the overhead rail system. The lamps can be turned on or off by pushing on the lens.
Page 61: Bulb Replacement
Lights Dome/courtesy lamps (if equipped) The dome lamp lights when: • any door is opened. • the instrument panel dimmer switch is rotated up until the courtesy lamps come on. • any of the remote entry controls are pressed and the ignition is OFF.
Page 62 Lights Function Number of Trade number bulbs Headlamps H13 / 9008 Front park/turn lamps 3157A (amber) Front sidemarker Foglamps 9140 Backup lamp (except Harley) 3156 Backup lamp (Harley) 3155 Rear stop/turn/sidemarker/tail 4057K or 3057K lamp High-mount brakelamp Cargo lamp License plate lamp Exterior mounted mirror turn See your dealer signal indicator (if equipped)
Page 63 Lights 5. Remove the bulb by turning it counterclockwise, then pull it straight out. Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.
Page 64 Lights 4. Slide the headlamp assembly forward disconnecting the snap attachment at the fender. 5. Remove bulb socket from the lamp assembly by turning it counterclockwise and then pull the bulb straight out. Install the new bulb(s) in reverse order. Replacing tail/brake/turn signal/backup lamp bulbs 1.
Page 65 Lights Replacing high-mount brake and cargo lamp bulbs Make sure the headlamp control is in the OFF position. 1. Remove the two screws and move the lamp assembly away from the vehicle to expose the bulb sockets. 2. Remove the bulb socket by rotating counterclockwise and pulling it out of the lamp assembly.
Page 66: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...
Page 67 Driver Controls While holding the steering column, pull the lever up to its original position to lock the steering column. Never adjust the steering column when the vehicle is moving. ILLUMINATED VISOR MIRROR (IF EQUIPPED) Lift the mirror cover to turn on the visor mirror lamps.
Page 68 Driver Controls OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. The overhead console can come on rails, which can be removed by the customer, or it can come as a non-rail component of the headliner, which cannot be removed.
Page 69 Driver Controls • When on the overhead rail, adjacent bins must be pinned together. Bins adjacent to the End Cap must be pinned to the End Cap. Bins without pin attachments should not be placed on the overhead rail. • Failure to pin the bins together can allow the bins to become separated from the rail under certain conditions.
Page 70 Driver Controls While pushing upwards with palms, grip the side latches with fingers and squeeze. With pressure applied with palms and side latches squeezed down, pull downward on the entire storage bin and remove. AUXILIARY POWER POINT (12VDC) Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse.
Page 71: Power Windows
Driver Controls The auxiliary power point is located on the instrument panel. Do not use the power point for operating the cigarette lighter element (if equipped). To prevent the fuse from being blown, do not use the power point(s) over the vehicle capacity of 12 VDC/180W.
Page 72 Driver Controls When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings. Press and hold the bottom part of the rocker switch to open the window.
Page 73 Driver Controls • Press and hold the bottom part of the rocker switch to open window all the way to the full open position. • Press and hold the top part of the rocker switch to close the window. All rear seat occupants and/or cargo must be properly restrained and clear of the back window opening before operating the power sliding back window.
Page 74: Mirrors
Driver Controls EXTERIOR MIRRORS Power side view mirrors To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror. 2. Move the control in the direction you wish to tilt the mirror. 3.
Page 75 Driver Controls Heated outside mirrors (if equipped) Heated mirrors remove ice, mist and fog. To activate the heated mirrors, press the rear defrost button located on the climate control panel. Refer to Rear Window Defrost in the Climate Controls chapter for more information.
Page 76: Speed Control
Driver Controls Never adjust the accelerator and brake pedal with feet on the pedals while the vehicle is moving. SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a speed of 30 mph (48 km/h) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 30 mph (48 km/h).
Page 77 Driver Controls Resuming a set speed Press the RES/RESUME control and release it. This will automatically return the vehicle to the previously set speed. The RES/RESUME control will not work if the vehicle speed is not faster than 30 mph (48 km/h).
Page 78 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET control. Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal or the clutch pedal (if equipped). This will not erase your vehicle’s previously set speed, if RES/RESUME is then selected, the vehicle will return to the previously set speed.
Page 79 Driver Controls In Satellite Radio mode (if equipped): • Press and release SEEK to advance through preset channels or press and hold SEEK to increment to the next subscribed channel. In CD mode: • Press and release SEEK to select the next track selection on the CD or press and hold SEEK to fast forward in the current track selection.
Page 80 Driver Controls To open the moon roof: The moon roof is equipped with a one-touch open feature. Press and release control. The moon roof will open to the “comfort” position. Press and release the control again to fully open. To stop the one-touch open feature press either the ROOF control again.
Page 81 Driver Controls When programming your HomeLink Wireless Control System to a garage door or gate, be sure that people and objects are out of the way to prevent potential harm or damage. Do not use the HomeLink Wireless Control System with any garage door opener that lacks safety stop and reverse features as required by U.S.
Page 82 Driver Controls 3. Simultaneously press and hold both the HomeLink and hand-held transmitter button. Do not release the buttons until Step 4 has been completed. Some entry gates and garage door openers may require you to replace Step 3 with procedures noted in the “Gate Operator and Canadian Programming”...
Page 83 Driver Controls Gate Operator & Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting — not allowing enough time for HomeLink to accept the signal from the hand-held transmitter. After completing Steps 1 and 2 outlined in the “Programming” section, replace Step 3 with the following: Note: If programming a garage door opener or gate operator, it is advised to unplug the device during the “cycling”...
Page 84 Driver Controls Erasing HomeLink buttons To erase the three programmed buttons (individual buttons cannot be erased): • Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds.
Page 85 Driver Controls Usually, when something affects the compass readings, the compass will correct itself after a few days of operating your vehicle in normal conditions. If the compass still appears to be inaccurate, a manual calibration may be necessary. Refer to Compass calibration adjustment.
Page 86: Message Center
Driver Controls 1. Start the vehicle. 2. To enter the compass calibration mode, press and hold the button for greater than eight seconds. The display will then show CAL in the display window. 3. Drive the vehicle slowly (less than 3 mph [5 km/h]) in circles until CAL indicator turns off.
Page 87 Driver Controls Info menu This control displays the following control displays: • Odometer/Compass • Trip odometer/Odometer/Compass • Distance to Empty • Average Fuel Economy • Trip Elapsed Drive Time Odometer/Trip odometer Refer to Gauges in the Instrument Cluster chapter. Compass display The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna.
Page 88 Driver Controls Compass zone/calibration adjustment 1. Determine your magnetic zone by referring to the zone map. 2. Turn ignition to the ON position. 3. Start the engine. 4. From Info menu, select the Compass/Odometer function. (Do not select Trip, DTE, or AFE. The top of the message center must be blank).
Page 89 Driver Controls 10. The compass is now calibrated. Distance to empty (DTE) Selecting this function from the INFO menu estimates approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition OFF when refueling to allow this feature to correctly detect the added fuel.
Page 90 Driver Controls 2. Record the highway fuel economy for future reference. It is important to press the RESET control after setting the speed control to get accurate highway fuel economy readings. Trip elapsed drive time Select this function from the INFO menu to display a timer.
Page 91 Driver Controls The sequence of the system check report and how it appears in the message center is as follows: 1. FUEL LEVEL 2. ENGINE TEMP 3. OIL PRESSURE 4. BRAKE FLUID LEVEL 5. CHARGING SYSTEM Units (English/Metric) 1. Select this function from the SETUP menu for the current units to be displayed.
Page 92 Driver Controls Language 1. Select this function from the SETUP menu for the current language to be displayed. 2. Pressing the RESET control cycles the message center through each of the language choices. 3. Press and hold the RESET control to set the language choice. System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems.
Page 93 Driver Controls Warning display Status Door ajar Warning can be reset Low fuel level Warning returns after 10 minutes Check charging system Low brake fluid level Low oil pressure Check engine temperature Reduced engine power Stop engine safely Check fuel cap Warning returns after the ignition key is turned from OFF to ON.
Page 94 Driver Controls LOW BRAKE FLUID LEVEL. Indicates the brake fluid level is low and the brake system should be inspected immediately. Refer to Brake fluid reservoir in the Maintenance and Specifications chapter. LOW OIL PRESSURE. Displayed when the engine oil pressure is low. If this warning message is displayed, check the level of the engine oil.
Page 95: Tailgate
Driver Controls Position the floor mat so that the eyelet is over the pointed end of the retention post. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. To remove the floor mat, reverse the installation procedure.
Page 96 Driver Controls To install, follow the removal procedures in reverse order. BED EXTENDER (IF EQUIPPED) Your vehicle may be equipped with a bed extender designed to extend the pickup box for longer loads. To extend the bed extender: 1. Lower tailgate. 2.
Page 97 Driver Controls To remove the bed extender: 1. Extend the bed extender. 2. Pull the round knobs on each side of the extender to unlock it. Make sure the locking clip screws are loose before removing the extender. 3. Press the locking clips below the middle bar on each side and lift the extender out of the bed.
Page 98: Locks And Security
Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. Refer to the SecuriLock passive anti-theft system section in this chapter for more information.
Page 99 Locks and Security CHILDPROOF DOOR LOCKS (IF EQUIPPED) • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 100 Locks and Security • unlock the vehicle doors without a key. • lock all the vehicle doors without a key. • activate the personal alarm. If there are problems with the remote entry system, make sure to take ALL remote entry transmitters with you to your authorized dealer in order to aid in troubleshooting the problem.
Page 101 Locks and Security (lock) and (unlock) features will work again after: • a door has become ajar, • the ignition is turned to the 3 (ON) position, or • using the UNLOCK control on your remote entry transmitter or unlocking via the keyless entry keypad. Deactivating/activating power door lock/unlock disable feature All vehicle doors must be closed before beginning the procedure.
Page 102 Locks and Security 2. Press the SET control on the driver’s seat. 3. Within 5 five seconds, press one control on the remote transmitter and then press the 1 or 2 control on the driver’s door panel to which you would like to associate with Driver 1 or Driver 2 positions.
Page 103 Locks and Security 2. Do not wipe off any grease on the battery terminals on the back surface of the circuit board. 3. Remove the old battery. Note: Please refer to local regulations when disposing of transmitter batteries. 4. Insert the new battery. Refer to the diagram inside the remote entry transmitter for the correct orientation of the battery.
Page 104 Locks and Security To program the transmitters yourself: • Unlock all doors using the power door lock/unlock control. Insert a key and turn the ignition from the 1 (OFF/LOCK) to the 3 (ON) position and cycle between 1 (OFF/LOCK) and 3 (ON) eight times in rapid succession (within 10 seconds) with the eighth turn ending in the 3 (ON) position.
Page 105 Locks and Security • any door is open. The battery saver will shut off the interior lamps 30 minutes after the last door is closed, even if the dimmer control is on. Perimeter lighting feature (if equipped) The perimeter lighting feature illuminates the exterior of the vehicle in order to provide better visibility to the user while he or she approaches and enters the vehicle.
Page 106 Locks and Security Every two consecutive presses of the control after successfully entering the configuration mode will change the enable/disable condition of the feature. 5. Turn the ignition to the 1 (OFF/LOCK) position to exit programming. Note: After exiting the driver configuration mode, the horn will chirp once to indicate a feature has been activated/deactivated.
Page 107 Locks and Security Power door unlock/lock procedure You must complete Steps 1–5 within 30 seconds, or the procedure will have to be repeated. If the procedure needs to be repeated, you must wait a minimum of 30 seconds to begin again. 1.
Page 108 Locks and Security KEYLESS ENTRY SYSTEM (IF EQUIPPED) You can use the keyless entry keypad to: • lock all vehicle doors. • unlock only the driver’s door. • unlock all vehicle doors. • program/erase the customer keycode. • enable/disable the autolocking feature. The keypad can be operated with the factory set 5–digit entry code;...
Page 109: Anti-Theft System
Locks and Security 4. After the code is entered, the locks will cycle, confirming that the new code has been set. Tips: • Do not set a code that uses five of the same number. • Do not use five numbers in sequential order. •...
Page 110 Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 111 Locks and Security Replacement keys If your keys are lost or stolen and you don’t have an extra coded key, you will need to have your vehicle towed to an authorized dealer. The key codes need to be erased from your vehicle and new coded keys will need to be programmed.
Page 112 Locks and Security 5. Within 10 seconds of removing the second coded key, insert the new unprogrammed key (new key/valet key) into the ignition and turn the ignition from the 1 (OFF/LOCK) position to the 3 (ON) position (maintain ignition in the 3 (ON) position for at least one second, but no more than ten seconds).
Page 113: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 114 Seating and Safety Restraints Push control to lower head restraint. Front seat • Lift the track release bar to move the seat forward or rearward. Make sure that the seat is relatched into place. • Pull the release lever handle located on the side of the seat up to move the seat back forward or backward.
Page 115 Seating and Safety Restraints Using the armrest (if equipped) Push the release control to move the armrest up or down. Using the manual lumbar support For more lumbar support, turn the lumbar support control toward the front of vehicle. For less lumbar support, turn the lumbar support control toward the rear of vehicle.
Page 116 Seating and Safety Restraints Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the passenger sensing system, resulting in serious injury or death in a crash. Always sit upright against your seatback, with your feet on the floor.
Page 117 Seating and Safety Restraints Memory seats/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat and adjustable pedals to two programmable positions. The memory seat control is located on the driver’s seat. • To program position one, move the driver seat, and adjustable pedals to the desired position.
Page 118 Seating and Safety Restraints The head restraints can be moved up and down. Lift the head restraint so that it is located directly or as close as possible behind your head. Push control to lower head restraint. Folding up the rear seats (if equipped ) The rear seat has a split 60/40 cushion.
Page 119: Safety Restraints
Seating and Safety Restraints Returning the seat to seating position Before returning the seatback to its original position, make sure that cargo or any objects are not trapped underneath the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched.
Page 120 Seating and Safety Restraints How does the Personal Safety System work? The Personal Safety System can adapt the deployment strategy of your vehicle’s safety devices according to crash severity and occupant classification and conditions. A collection of crash and occupant sensors provides information to the Restraints Control Module (RCM).
Page 121 Seating and Safety Restraints Front passenger sensing system For airbags to do their job they must inflate with great force, and this force can pose a potentially deadly risk to occupants that are very close to the airbag when it begins to inflate. For some occupants, like infants in rear-facing child seats, this occurs because they are initially sitting very close to the airbag.
Page 122 Seating and Safety Restraints Front outboard safety belt pretensioners The front seat outboard safety belt pretensioners are designed to tighten the safety belts firmly against the occupant’s body during a collision. This maximizes the effectiveness of the safety belt and removes any slack from the safety belt to improve protection.
Page 123 Seating and Safety Restraints Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit in the back seat where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving.
Page 124 Seating and Safety Restraints Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them. Combination lap and shoulder belts 1.
Page 125 Seating and Safety Restraints If you carry large cargo behind the seat or items that might damage or soil the belt, detach the belt from the seat: 1. Release the mini-buckle by inserting a key or safety belt tongue into the slot. 2.
Page 126 Seating and Safety Restraints 2. Buckle the small tongue on the end of the belt into the mini-buckle on the driver’s side. The belt is now ready for use. This mini-buckle should stay buckled at all times unless cargo-carrying makes it necessary to detach the belt.
Page 127 Seating and Safety Restraints 3. Insert the belt tongue into the proper buckle for your seating position until you hear a snap and feel it latch. 4. Make sure the tongue is securely fastened to the buckle by pulling on the tongue.
Page 128 Seating and Safety Restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 129 Seating and Safety Restraints The front and rear safety restraints in the vehicle are combination lap and shoulder belts. The front passenger outboard and rear outboard seat safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 130 Seating and Safety Restraints How to use the automatic locking mode 1. Buckle the combination lap and shoulder belt. • Right front passenger seat • Rear seats (if equipped) 2. Grasp the shoulder portion and pull downward until the entire belt is extracted.
Page 131 Seating and Safety Restraints How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. After any vehicle collision, the safety belt systems at all outboard seating positions (except the driver position, which does not have this feature) must be checked by an authorized dealer to verify that the automatic locking retractor feature for child seats is still...
Page 132 Seating and Safety Restraints Safety belt usage sensors The driver and front outboard passenger safety belt buckles are equipped with sensors that detect if the safety belts are fastened. The sensors provide information to the Personal Safety System which can then adapt the airbag deployment or safety belt pretensioner activation based upon safety belt usage.
Page 133 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 134 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
Page 135 Seating and Safety Restraints If... Then... The driver’s and front The BeltMinder feature will not passenger’s safety belts are activate. buckled before the ignition switch is turned to the ON position or less than 1-2 minutes have elapsed since the ignition switch has been turned ON...
Page 136 Seating and Safety Restraints Reasons given... Consider... “Belts are uncomfortable” We design our safety belts to enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 137 Seating and Safety Restraints Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the Belt Minder feature please follow the directions stated below.
Page 138: Airbags
Seating and Safety Restraints • After Step 3, the restraint system warning light (airbag light) will be turned on for three seconds. 4. Within 10 seconds of the light turning on, buckle then unbuckle the safety belt. • This will disable the BeltMinder feature for that seating position if it is currently enabled.
Page 139 Seating and Safety Restraints • Front passenger sensing system • Passenger airbag off indicator light. The airbag supplemental restraints are an integral part of the Personal Safety System. They are designed to be deployed in cases where the Personal Safety System has determined the occupant conditions and crash severity are appropriate to activate these devices.
Page 140 Seating and Safety Restraints To properly position yourself away from the airbag: • Move your seat to the rear as far as you can while still reaching the pedals comfortably. • Recline the seat slightly one or two degrees from the upright position. Do not put anything on or over the airbag cover (1).
Page 141 Seating and Safety Restraints Children and airbags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seat than in the front seat.
Page 142 Seating and Safety Restraints How does the airbag supplemental restraint system work? The airbag SRS is designed to activate when the vehicle sustains sufficient longitudinal deceleration. The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system.
Page 143 Seating and Safety Restraints If the airbag has deployed, the airbag will not function again and must be replaced immediately. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a collision. Determining if the system is operational The SRS uses readiness lights in the instrument cluster or a tone to indicate the condition of the system.
Page 144 Seating and Safety Restraints The front passenger sensing system will disable (will not inflate) the front passenger’s frontal airbag if: • the front passenger seat is unoccupied, or has small/medium objects in the front seat, • the system determines that an infant is present in a rear-facing infant seat that is installed according to the manufacturer’s instructions, •...
Page 145 Seating and Safety Restraints • When the front passenger sensing system enables the front passenger frontal airbag (may inflate), the indicator will be unlit and stay unlit. If a person of adult size is sitting in the front passenger’s seat, but the passenger airbag off or pass airbag off indicator lamp is lit, it is possible that the person isn’t sitting properly in the seat.
Page 146 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Guide.
Page 147: Child Restraints
Seating and Safety Restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Airbag supplemental restraint system (SRS) in this chapter for special instructions about using airbags. Important child restraint precautions You are required by law to use safety restraints for children in the U.S.
Page 148 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 149 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 150 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 151 Seating and Safety Restraints Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a collision. SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child.
Page 152 36 kg (80 pounds) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
Page 153 Seating and Safety Restraints 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat...
Page 154 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 155 Seating and Safety Restraints 8. Allow the safety belt to retract to remove any slack in the belt. 9. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward.
Page 156 Seating and Safety Restraints 2. If the center lap/shoulder safety belt has been disconnected from the seat to carry large cargo behind the seat, reconnect it by buckling the small buckle on the end of the belt into the mini-buckle on the driver’s side.
Page 157 Seating and Safety Restraints 5. Insert the belt tongue into the proper buckle for that seating positions until you hear a snap and feel it latch. Make sure the tongue is securely latched to the buckle by pulling on the tongue. 6.
Page 158 Seating and Safety Restraints 9. Check from time to time to be sure that there is no slack in the lap/shoulder belt. The shoulder belt must be snug to keep the lap belt tight during a collision. Installing child safety seats in the front row lap belt seating positions (SuperCab and SuperCrew) Installing a child safety seat in the front row lap seating position should be avoided if at all possible.
Page 159 Seating and Safety Restraints The passenger seats of your vehicle are equipped with built-in tether strap anchors located behind the seats as described below. The tether anchors in your vehicle may be loops of webbing above the seatback or an anchor bracket behind the seat on the rear edge of the seat cushion.
Page 160 Seating and Safety Restraints • You may need to pull the seatback forward to access the tether anchors. Make sure the seatback is locked in the upright position before installing the child seat. 4. Clip the tether strap to the anchor as shown. •...
Page 161 Seating and Safety Restraints If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. Rear seat tether strap attachment There are three loops of webbing just above the back of the rear seat (along the bottom edge of the rear window) in the SuperCab and SuperCrew.
Page 162 Seating and Safety Restraints 2. Route the tether strap behind the head restraint supports to a loop behind an adjacent seating position, and hook the strap hook onto the loop. If using the driver’s side, pass the strap behind the shoulder belt mounting for the center seat.
Page 163 Seating and Safety Restraints Your vehicle is equipped with LATCH anchors for child seat installation at the following seating positions (LATCH is not available on F150 Regular cab) : • F150 SuperCab and SuperCrew The anchors on both sides of the center of the rear seat are provided for child seats at the outboard seats, and are further apart than the pairs of lower anchors for child seat installation at other seats.
Page 164 Seating and Safety Restraints If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat.
Page 165: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 166 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter.
Page 167 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 168 Tires, Wheels and Loading Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 169 Tires, Wheels and Loading Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture.
Page 170 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 171: Tire Information
Tires, Wheels and Loading higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door. The cold inflation pressure should never be set lower than the recommended pressure on the Safety Compliance Certification Label or Tire Label.
Page 172 Tires, Wheels and Loading 6. Visually inspect the tires to make sure there are no nails or other objects embedded that could poke a hole in the tire and cause an air leak. 7. Check the sidewalls to make sure there are no gouges, cuts or bulges. TIRE CARE Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and...
Page 173 Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 174 Tires, Wheels and Loading It is recommended that the two front tires or two rear tires generally be replaced as a pair. Safety practices Driving habits have a great deal to do with your tire mileage and safety. • Observe posted speed limits •...
Page 175 Tires, Wheels and Loading Front wheel drive (FWD) vehicles and those with an independent rear suspension (if equipped) may require alignment of all four wheels. The tires should also be balanced periodically. An unbalanced tire and wheel assembly may result in irregular tire wear. Tire rotation Rotating your tires at the recommended interval (as indicated in the scheduled maintenance information that comes with your vehicle) will...
Page 176 Tires, Wheels and Loading Note: After having your tires rotated, inflation pressure must be checked and adjusted to the vehicle requirements. INFORMATION CONTAINED ON THE TIRE SIDEWALL Both U.S. and Canada Federal regulations require tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a U.S.
Page 177 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. 7. H: Indicates the tire’s speed rating. The speed rating denotes the speed at which a tire is designed to be driven for extended periods of time under a standard condition of load and inflation pressure.
Page 178 Tires, Wheels and Loading 9. M+S or M/S: Mud and Snow, or AT: All Terrain, or AS: All Season. 10. Tire Ply Composition and Material Used: Indicates the number of plies or the number of layers of rubber-coated fabric in the tire tread and sidewall.
Page 179 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 180 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 181: Vehicle Loading
Tires, Wheels and Loading SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
Page 182 Tires, Wheels and Loading Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 183 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 184 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 185 Tires, Wheels and Loading GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door.
Page 186 Tires, Wheels and Loading Maximum Loaded Trailer Weight – is the highest possible weight of a fully loaded trailer the vehicle can tow. It assumes a vehicle with only mandatory options, no cargo (internal or external), a tongue load of 10–15% (conventional trailer) or king pin weight of 15–25% (fifth wheel trailer), and driver only (150 lb.
Page 187 Tires, Wheels and Loading 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle.
Page 188: Trailer Towing
Tires, Wheels and Loading Special loading instructions for owners of pickup trucks and utility-type vehicles For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in the Driving chapter of this Owner’s Guide. Loaded vehicles may handle differently than unloaded vehicles.
Page 189 Tires, Wheels and Loading Regular Cab 4x2 (126” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.2L (with 3.31 7200 (3266) 2400 (1089) manual 3.55 8500 (3856) 3700 (1678) transmission) 4.2L (with 3.55 10000 (4536) 5200 (2358) automatic 3.73 10500 (4763)
Page 190 Tires, Wheels and Loading Regular Cab 4x4 (126” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L 3.55 11500 (5216) 6300 (2857) 4.6L 3.73 12000 (5443) 6800 (3084) 5.4L (with 17” 3.55 13000 (5897) 7700 (3492) tires) 5.4L (with 18”...
Page 191 Tires, Wheels and Loading SuperCab 4x2 (132.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.55 11500 (5216) 6300 (2858) tires) 4.6L (with 18” 3.55 11000 (4989) 5800 (2630) tires) 4.6L (with 17” 3.73 12000 (5443) 6800 (3084)
Page 192 Tires, Wheels and Loading SuperCab 4x2 (144.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 5.4L (with 18” 3.55 13500 (6123) 8100 (3674) or 20” tires) 5.4L (with 17” 3.73 15000 (6804) 9500 (4309) tires) 5.4L (with 18”or 3.73 14500 (6577) 9000 (4082)
Page 193 Tires, Wheels and Loading SuperCab 4x4 (132.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 5.4L (with 17” 3.55 13000 (5897) 7400 (3356) tires) 5.4L (with 18” 3.55 12500 (5670) 6900 (3129) tires) 5.4L (with 17” 3.73 13500 (6123) 7900 (3583)
Page 194 Tires, Wheels and Loading Super Cab 4x4 (144.5” wheelbase) Harley-Davidson Version (not available for F-150 Lobo) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 5.4L 3.73 11500 (5216) 5600 (2540) SuperCab 4x4 (163” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb.
Page 195 Tires, Wheels and Loading Crew Cab 4x4 (138.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.73 12200 (5534) 6500 (2948) tires) 4.6L (with 18” 3.73 11700 (5307) 6000 (2722) tires) 5.4L (with 17” 3.55 14000 (6350) 8200 (3719)
Page 196 Tires, Wheels and Loading Crew Cab 4x4 (150.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.73 12200 (5534) 6400 (2902) tires) 4.6L (with 18” 3.73 11700 (5307) 5900 (2676) tires) 5.4L (with 17” 3.55 14000 (6350) 8100 (3674)
Page 197 Tires, Wheels and Loading Load equalizing hitch When hooking up a trailer using a load equalizing hitch, always use the following procedure: 1. Park the unloaded vehicle on a level surface. With the ignition on and all doors closed, allow the vehicle to stand for several minutes so that it can level.
Page 198 Tires, Wheels and Loading Using a step bumper (if equipped) The rear bumper is equipped with an integral hitch and only requires a ball with a one inch (25.4 mm) shank diameter. The bumper has a 5,000 lb. (2,270 kg) trailer weight and 500 lb. (227 kg) tongue weight capacity. If it is necessary to relocate the trailer hitch ball position, a frame-mounted trailer hitch must be installed.
Page 199: Recreational Towing
Tires, Wheels and Loading • After you have traveled 50 miles (80 km), thoroughly check your hitch, electrical connections and trailer wheel lug nuts. • To aid in engine/transmission cooling and A/C efficiency during hot weather while stopped in traffic, place the gearshift lever in P (Park) (automatic transmission) or N (Neutral) (manual transmissions).
Page 200 If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, you must disconnect the front (4x4 only) and rear driveshafts. Ford recommends the driveshafts be removed/installed only by a qualified technician at an authorized dealer. See your authorized dealer for driveshaft removal/installation.
Page 201: Driving
Driving STARTING Positions of the ignition 1. OFF/LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. Note: The ignition key cannot be removed from the ignition unless the gearshift lever is securely latched in P (Park). 2.
Page 202 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 203 Driving • Make sure the parking brake is set. BRAKE If starting a vehicle with a manual transmission: • Make sure the parking brake is set. • Push the clutch pedal to the floor 3. Turn the key to 3 (ON) without turning the key to 4 (START).
Page 204 Driving Starting the engine 1. Turn the key to 3 (ON) without turning the key to 4 (START). If there is difficulty in turning the key, rotate the steering wheel until the key turns freely. 2. Turn the key to 4 (START), then release the key as soon as the engine starts.
Page 205: Brakes
Driving If the engine fails to start using the preceding instructions (flexible fuel vehicles only) 1. Press and hold down the accelerator 1/3 to 1/2 way to floor, then crank the engine. 2. When the engine starts, release the key, then gradually release the accelerator pedal as the engine speeds up.
Page 206 Driving Base instrument cluster with and without tachometer BRAKE Mid and Luxury instrument cluster BRAKE Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an Anti-lock Braking System (ABS). This system helps you maintain steering control during emergency stops by keeping the brakes from locking.
Page 207 Driving Base instrument cluster with and without tachometer BRAKE Mid and Luxury instrument cluster BRAKE Parking brake To set the parking brake (1), press the parking brake pedal down until the pedal stops. The BRAKE warning lamp will illuminate and will remain illuminated until the parking brake is released.
Page 208: Traction Control
Driving TRACTION CONTROL (IF EQUIPPED) Your vehicle may be equipped with a Traction Control system. This system helps you maintain the stability and steerability of your vehicle, especially on slippery road surfaces such as snow- or ice-covered roads and gravel roads. The system will allow your vehicle to make better use of available traction in these conditions.
Page 209 Driving STEERING To help prevent damage to the power steering system: • Never hold the steering wheel at its furthest turning points (until it stops) for more than a few seconds when the engine is running. • Do not operate the vehicle with a low power steering pump reservoir fluid level (below the MIN mark on the reservoir).
Page 210: Transmission Operation
Driving PREPARING TO DRIVE Utility vehicles have a significantly higher rollover rate than other types of vehicles. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Your vehicle has larger tires and increased ground clearance, giving the vehicle a higher center of gravity than a passenger car.
Page 211 Driving 2. Locate the round access plug on the underside of the steering column cover. 3. Remove the access plug using a flat head screwdriver, then push the override button using a flat head screwdriver, apply the brake pedal and shift the transmission into N (Neutral).
Page 212 Driving 2. Open the center console bin. Using a screwdriver, carefully pry off the console finish panel surrounding the shifter mechanism by inserting a screwdriver into the latch slot as shown. 3. Remove console finish panel assembly to expose the inside of the gearshift.
Page 213 Driving If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer. Understanding the gearshift positions of the 4–speed automatic transmission Your vehicle’s automatic transmission is equipped with a special shift strategy that insures maximum heater performance during cold weather operation.
Page 214 Driving To put your vehicle in P (Park): • Come to a complete stop • Move the gearshift lever and securely latch it in P (Park) Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle.
Page 215 Driving • Floor-shift transmission The transmission control indicator (TCIL) will illuminate on the instrument cluster. Drive (not shown) Drive is activated when the transmission control switch is pressed. • This position allows for all forward gears except overdrive. • O/D OFF lamp is illuminated. •...
Page 216 Driving • Allows upshifts by moving gearshift lever. • Will not downshift into 1 (First) at high speeds; allows for 1 (First) when vehicle reaches slower speeds. Forced downshifts • Allowed in D (Overdrive) or Drive. • Depress the accelerator to the floor. •...
Page 217 Driving During each shift, the clutch pedal must be fully depressed to the floor. Failure to fully depress the clutch pedal to the floor may cause increased shift efforts, prematurely wear transmission components or damage the transmission. Make sure the floor mat is properly positioned so it doesn’t interfere with the full extension of the clutch pedal.
Page 218 Driving Maximum downshift speeds 4 - 3 45 mph (72 km/h) 17 mph (27 km/h) 3 - 2 35 mph (56 km/h) 13 mph (21 km/h) 2 - 1 20 mph (32 km/h) 7 mph (11 km/h) Downshift at lower speeds when driving on slippery surfaces. Reverse 1.
Page 219 Driving To help avoid personal injury, always use caution when in reverse and when using the RSS. This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 220 Driving The RSS automatically turns on when the gearshift lever is placed in R (Reverse) and the ignition is ON. An RSS control allows the driver to turn the RSS on and off. To turn the RSS off, the ignition must be ON, and the gear selector in R (Reverse).
Page 221 Driving • 4X4 LOW – Momentarily illuminates when the engine is started. Illuminates when 4L is selected. Using a manual 4WD system (if equipped) 2H (2WD High) – Power to the rear wheels only; used for street and highway driving. Provides optimal smoothness and fuel economy at high speeds.
Page 222 Driving 3. Place the transmission in N (Neutral). 4. Move the transfer case lever through N (Neutral) directly to the desired position. • If the transfer case will not engage into 4L (4WD Low), allow the vehicle to coast at a speed below 3 mph (5 km/h), then repeat Steps 2 through 4.
Page 223 Driving 4L (4WD Low) - Uses extra gearing to provide maximum power to all four wheels at reduced speeds. Intended only for off-road applications such as deep sand, steep grades or pulling heavy objects. 4L (4WD Low) will not engage while the vehicle is moving above 3 mph (5 km/h); this is normal and should be no reason for concern.
Page 224 Driving AWD (Auto) - Power delivered to all four wheels, as required, for increased traction. This is appropriate for all on-road driving conditions, such as dry road surfaces, wet pavement, snow, gravel and shallow sand. 4H (Lock) - The “4X4 HI” light will illuminate in the instrument cluster when this position is selected.
Page 225 Driving steering and braking control of your vehicle, you must have all four wheels on the ground and they must be rolling, not sliding or spinning. Basic operating principles • Do not use 4WD on dry, hard surfaced roads. Doing so will produce excessive noise, increase tire wear and may damage drive components.
Page 226 Driving Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur. Do not rock the vehicle for more than a few minutes or damage to the transmission and tires may occur or the engine may overheat.
Page 227 Driving the driveline. Therefore, the vehicle is free to roll even if the automatic transmission is in P (Park) or the manual transmission is in gear. Do not leave the vehicle unattended with the transfer case in the N (Neutral) position.
Page 228 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 229 Driving Driving on hilly or sloping terrain Although natural obstacles may make it necessary to travel diagonally up or down a hill or steep incline, you should always try to drive straight up or straight down. Avoid driving crosswise or turning on steep slopes or hills.
Page 230 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 231 Snow Plow Prep Package is not available. Installing the snowplow Weight limits and guidelines for selecting and installing the snowplow can be found in the Ford Truck Body Builders Layout Book, Snowplow section, found at www.fleet.ford.com/truckbbas. A typical installation affects the following: •...
Page 232 Operating the vehicle with the snowplow attached Ford recommends that the F–150 be limited to low speed, personal-use snow removal. Do not use your vehicle for snow removal until it has been driven at least 500 miles (800 km).
Page 233 Do not attempt to service, repair, or modify the air bag supplemental restraint system (SRS) or its fuses. See your Ford or Lincoln Mercury dealer. Transmission operation while plowing •...
Page 234 Driving Engine temperature while plowing When driving with a plow, your engine may run at a higher temperature than normal because the attached snowplow blade will restrict airflow to the radiator. If you are driving more than 15 miles (24 km) at temperatures above freezing, angle the plow blade either full left or full right to provide maximum airflow to the radiator.
Page 235: Roadside Emergencies
50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start • lock-out assistance (key replacement cost is the customer’s responsibility) •...
Page 236 1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1–800–241–3673;...
Page 237: Fuel Pump Shut-Off Switch
Roadside Emergencies HAZARD FLASHER The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Push in the flasher control and all front and rear direction signals will flash.
Page 238: Fuses And Relays
Roadside Emergencies This switch is located in the front passenger’s footwell, behind the kick panel access cover, to the left of the fuse box. The access cover needs to be removed to reset the fuel pump shut-off switch. To reset the switch: 1.
Page 239 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 240 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 10A* Run/Accessory - Wipers, Instrument cluster, Audio for XL/STX 20A* Stop/Turn lamps, Brake on/off switch 7.5A* Power mirrors, Memory seats and pedals 10A* DVD battery power, Power fold mirror...
Page 241 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 10A* Heated mirrors, Switch indicator 20A* Fuel pump relay, Fuel injectors, Intake manifold runner control (4.2L) 20A* Trailer tow back-up lamps relay (PCB1), Trailer tow parklamp relay (R201) 10A* A/C clutch, 4x4 solenoid PCM relay coil...
Page 242 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 15A* Battery saver power for demand lamps 10A* LH low beam headlamp 20A* Horn relay (PCB3), Horn power Passenger Air bag Deactivation (PAD) warning lamp, Cluster air bag warning lamp, Cluster RUN /START power SecuriLock transceiver (PATS), PCM IGN monitor...
Page 243 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 20A* Cigar lighter, Diagnostic connector power 10A* Trailer tow left turn/stop lamps 30A** Starter solenoid 20A** Ignition switch feed 20A** ABS valves — Not used 30A** Electric trailer brakes 30A** Trailer tow battery charge 30A**...
Page 244 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description R202 Half ISO relay Fog lamps R203 Half ISO relay * Mini fuses ** Cartridge fuses Auxiliary relay box The relay box is located in the engine compartment on the left fender. •...
Page 245 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 246 Roadside Emergencies When driving with one of the dissimilar spare tires listed above, do not: • Exceed 50 mph (80 km/h) • Load the vehicle beyond maximum vehicle load rating listed on the Safety Compliance Label • Tow a trailer •...
Page 247 Roadside Emergencies • Winter weather driving capability • Wet weather driving capability • All-Wheel driving capability (if applicable) • Load leveling adjustment (if applicable) When driving with the full-size dissimilar spare tire/wheel additional caution should be given to: • Towing a trailer •...
Page 248 Roadside Emergencies 2. Fully insert the jack handle through the bumper hole and into the guide tube through the access hole in the rear bumper. 3. Turn the handle counterclockwise until tire is lowered to the ground, the tire can be slid rearward and the cable is slightly slack. 4.
Page 249 Roadside Emergencies 3. Block the diagonally opposite wheel. 4. Obtain the spare tire and jack from their storage locations. 5. Use the tip of the lug wrench to remove any wheel trim. 6. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground.
Page 250 Roadside Emergencies • Rear To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 251 Roadside Emergencies • Seven lug nut wheel 12. Stow the flat tire. Refer to Stowing the flat/spare tire. 13. Stow the jack and lug wrench. Make sure the jack is fastened so it does not rattle when you drive. 14. Unblock the wheels. Stowing the flat/spare tire Note: Failure to follow spare tire stowage instructions may result in failure of cable or loss of spare tire.
Page 252: Lug Nut Torque
M14 x 2.0 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 253 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
Page 254 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 2006 F-150 (f12) Owners Guide (post-2002-fmt) USA (fus)
Page 255 Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
Page 256 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 257 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 258: Wrecker Towing
Ford recommends your vehicle be towed with a wheel lift or flatbed. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 259: Customer Assistance
Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 260 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 261 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the BBB...
Page 262 You are not bound by the decision but may choose to accept it. If you choose to accept the BBB AUTO LINE decision then Ford must abide by the accepted decision as well. If the arbitrator has decided in...
Page 263 United States and Canada, provided by a network of more than 4,600 participating authorized dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this...
Page 264 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 265: Reporting Safety Defects (U.s. Only)
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your authorized dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 266: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 267 Cleaning WAXING Applying Motorcraft Paint Sealant (ZC-45) to your vehicle every six months will assist in reducing minor scratches and paint damage. • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product.
Page 268 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 269 Cleaning • 4.6L engine • 5.4L engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer.
Page 270 Cleaning • For plastic headlamp lenses, use Motorcraft Ultra Clear Spray Glass Cleaner (ZC-23). WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly. If the wipers do not wipe properly, substances on the vehicle’s glass or the wiper blades may be the cause.
Page 271 Cleaning INSTRUMENT PANEL AND CONSOLE (HARLEY-DAVIDSON F150 ONLY) Your Harley-Davidson F150 instrument panel and console is uniquely painted with both high and low gloss paints that require special care. The high gloss area is similar to that of the vehicle’s exterior; the low gloss area is designed to help protect the driver from undesirable windshield reflection.
Page 272 Cleaning INTERIOR TRIM • Clean the interior trim areas with a damp cloth, then with a clean, dry cloth; you may also use Motorcraft Dash & Vinyl Cleaner (ZC-38-A). • Do not use household or glass cleaners as these may damage the finish.
Page 273 Cleaning Leather seats for the King Ranch SuperCrew only (if equipped) Your vehicle is equipped with seating covered in premium, top-grain leather which is extremely durable, but still requires special care and maintenance in order to ensure longevity and comfort. Regular cleaning and conditioning will maintain the appearance of the leather.
Page 274 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 275 Cleaning Motorcraft Detail Wash (ZC-3–A) Motorcraft Dusting Cloth (ZC-24) Motorcraft Engine Shampoo and Degreaser (U.S. only) (ZC-20) Motorcraft Engine Shampoo (Canada only) (CXC-66-A) Motorcraft One Step Wash and Wax Concentrate (ZC-6-A) Motorcraft Paint Sealant (ZC-45) Motorcraft Premium Car Wash Concentrate (U.S. only) (ZC-17-B) Motorcraft Premium Glass Cleaner (Canada only) (CXC-100) Motorcraft Premium Liquid Wax (ZC-53-A) Motorcraft Premium Windshield Washer Concentrate (ZC-32–A)
Page 276: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service.
Page 277 Maintenance and Specifications • Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral). 2. Block the wheels. To reduce the risk of vehicle damage and/or personal burn injuries do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 278: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.2L V6 engine 1. Battery 2. Clutch fluid reservoir (manual transmission) 3. Power steering fluid reservoir 4. Brake fluid reservoir 5. Engine coolant reservoir 6. Air filter assembly 7. Engine oil filler cap 8.
Page 279 Maintenance and Specifications 4.6L V8 1. Battery 2. Transmission fluid dipstick (automatic transmission) 3. Engine oil filler cap 4. Power steering fluid reservoir 5. Engine oil dipstick 6. Brake fluid reservoir 7. Engine coolant reservoir 8. Air filter assembly 9. Windshield washer fluid reservoir 2006 F-150 (f12) Owners Guide (post-2002-fmt) USA (fus)
Page 280 Maintenance and Specifications 5.4L V8 1. Battery 2. Transmission fluid dipstick (automatic transmission) 3. Air filter assembly 4. Power steering fluid reservoir 5. Engine oil dipstick 6. Brake fluid reservoir 7. Engine coolant reservoir 8. Engine oil filler cap 9. Windshield washer fluid reservoir 2006 F-150 (f12) Owners Guide (post-2002-fmt) USA (fus)
Page 281 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16-A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 282: Engine Oil
Maintenance and Specifications Poor wiper quality can be improved by cleaning the wiper blades and the windshield, refer to Windows and wiper blades in the Cleaning chapter. To prolong the life of the wiper blades, it is highly recommended to scrape off the ice on the windshield before turning on the wipers.
Page 283 Maintenance and Specifications • 4.2L V6 engine • 4.6L/5.4L V8 engine 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. 2006 F-150 (f12) Owners Guide (post-2002-fmt) USA (fus)
Page 284 Maintenance and Specifications • If the oil level is between the lower and upper holes or between the MIN and MAX marks (depending on application), the oil level is acceptable. DO NOT ADD OIL. • 4.2L V6 engine • 4.6L/5.4L V8 engine •...
Page 285 Change your engine oil and filter according to the appropriate schedule listed in scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 286: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
Page 287 Maintenance and Specifications Battery posts, terminals and related accessories contain lead and lead compounds. Wash hands after handling. Because your vehicle’s engine is also electronically controlled by a computer, some control conditions are maintained by power from the battery. When the battery is disconnected or a new battery is installed, the engine must relearn its idle and fuel trim strategy for optimum driveability and performance.
Page 288: Engine Coolant
Maintenance and Specifications ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the intervals listed in scheduled maintenance information. The coolant concentration should be maintained at 50/50 coolant and distilled water, which equates to a freeze point of -34°F (-36°C). Coolant concentration testing is possible with a hydrometer or antifreeze tester (such as the Rotunda Battery and Antifreeze Tester, 014–R1060).
Page 289 Motorcraft Premium Gold Engine Coolant from yellow to golden tan. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine Coolant or any orange-colored extended life product with your factory filled coolant can result in degraded corrosion protection.
Page 290 Maintenance and Specifications • A large amount of water without engine coolant may be added, in case of emergency, to reach a vehicle service location. In this instance, the cooling system must be drained and refilled with a 50/50 mixture of engine coolant and distilled water as soon as possible.
Page 291 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 292 Maintenance and Specifications If you drive in extremely hot climates: • It is still necessary to maintain the coolant concentration above 40%. • NEVER decrease the coolant concentration below 40%. • Decreased engine coolant concentrations below 40% will decrease the corrosion protection characteristics of the engine coolant and may cause engine damage.
Page 293 Maintenance and Specifications When this occurs the vehicle will still operate. However: • The engine power will be limited. • The air conditioning system will be disabled. Continued operation will increase the engine temperature: • The engine will completely shut down. •...
Page 294 Maintenance and Specifications WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 295 Maintenance and Specifications • Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury.
Page 296 Maintenance and Specifications Flexible fuel components and standard unleaded gasoline fuel components are not interchangeable. If your vehicle is not serviced in accordance with flexible fuel vehicles procedures, damage may occur and your warranty may be invalidated. When refueling always shut the engine off and never allow sparks or open flames near the filler neck.
Page 297 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 298 Repairs to correct the effects of using a fuel for which your vehicle was not designed may not be covered by your warranty. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. 2006 F-150 (f12)
Page 299 Maintenance and Specifications Octane recommendations Do not be concerned if your engine sometimes knocks lightly. However, if it knocks heavily under most driving conditions while you are (R+M)/2 METHOD using fuel with the recommended octane rating, see your authorized dealer to prevent any engine damage. Unleaded Gasoline engines Your vehicle is designed to use “Regular”...
Page 300 Maintenance and Specifications FFV engine (if equipped) Your FFV will operate well on ordinary “Regular” unleaded gasoline, but only the highest quality fuel ethanol will provide the same level of protection and performance. To identify if your vehicle is an FFV, check your VIN or the label on the inside of your fuel filler door.
Page 301 Maintenance and Specifications The advertised capacity is the amount of the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty.
Page 302 Maintenance and Specifications Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy under current driving conditions. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy.
Page 303 Maintenance and Specifications • Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in scheduled maintenance information. Conditions • Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed. •...
Page 304 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 305 Maintenance and Specifications Please consult your Warranty Guide for complete emission warranty information. On board diagnostics (OBD-II) Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD-II). This OBD-II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
Page 306 Maintenance and Specifications • Next, at least 20 minutes driving in stop-and-go, city-type traffic with at least four idle periods. Allow the vehicle to sit for at least eight hours without starting the engine. Then, start the engine and complete the above driving cycle. The engine must warm up to its normal operating temperature.
Page 307 If the fluid level drops, refill the fluid level to the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Ford specifications. Refer to Lubricant specifications in this chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 308 Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid (if equipped) Refer to your scheduled maintenance information for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, i.e., if the transmission slips or shifts slowly or if you notice some sign of fluid leakage.
Page 309 Maintenance and Specifications You can check the fluid without driving if the ambient temperature is above 50°F (10°C). However, if fluid is added at this time, an overfill condition could result when the vehicle reaches normal operating temperature. The transmission fluid should be in this range if at normal operating temperature (150°F-170°F COLD...
Page 310 Maintenance and Specifications If an overfill occurs, excess fluid should be removed by an authorized dealer. COLD FoMoCo 5L 3P -7A020- CB An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. Do not use supplemental transmission fluid additives, treatments or cleaning agents.
Page 311 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Lubricant specifications section in this chapter. TRANSFER CASE FLUID (IF EQUIPPED) 1. Clean the filler plug.
Page 312: Air Filter(S)
Use only fluid that meets Ford specifications. Refer to the Lubricant specifications section in this chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 313 Maintenance and Specifications Changing the air filter element • 4.2L/4.6L engines 1. Loosen the clamp that secures the air filter element in place. 2. Carefully separate the two halves of the air filter housing. 3. Remove the air filter element from the open end of the air filter housing.
Page 314 Maintenance and Specifications • 5.4L Engine 1. Release two retainer clamps. 2. Pull air filter tray assembly out toward front of vehicle and lift air filter element up and out of housing. The air filter box needs to be free of any debris before installing a new air filter.
Page 315: Part Numbers
PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 316: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid Motorcraft Fill to line or step and clutch High (for clutch) on fluid Performance reservoir DOT 3 Motor Vehicle Brake Fluid Engine Motorcraft 4.2L V6 engine 17.6 quarts (16.7L)
Page 317 Maintenance and Specifications Fluid Ford Part Application Capacity Name Power Motorcraft Fill to between MIN steering MERCON and MAX lines on fluid reservoir Transfer Motorcraft 4x4 vehicles 2.0 quarts (1.9L) case fluid MERCON Transmission Motorcraft 5–speed manual 3.75 quarts (3.5L)
Page 318 Add 4 oz. (118 ml) of Additive Friction Modifier XL–3 or equivalent meeting Ford specification EST-M2C118–A, for complete fill of 8.8 inch and 9.75 inch Traction-Lok axles. Service refill capacity is determined by filling the axle to the bottom of the filler hole with the vehicle on a level surface.
Page 319: Lubricant Specifications
Maintenance and Specifications LUBRICANT SPECIFICATIONS Ford part Ford part Ford Item name or number specification equivalent Motorcraft SAE Front axle 80W-90 XY-80W-90-QL WSP-M2C197-A (4X4) Premium Rear Axle Lubricant Motorcraft SAE 75W-140 Rear Rear axle XY-75W140-QL WSL-M2C192-A Axle Lubricant (synthetic) Motorcraft High...
Page 320 Maintenance and Specifications Ford part Ford part Ford Item name or number specification equivalent Hinges, latches, Motorcraft striker plates, Silicone Brake fuel filler door Caliper Grease XG-3-A ESE-M1C171-A hinge and door and Dielectric check arm Compound Motorcraft Lock cylinders Penetrating and...
Page 321: Engine Data
Maintenance and Specifications Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle. Check the container to verify the fluid being added is of the correct type. Refer to your scheduled maintenance information to determine the correct service interval.
Page 322 Maintenance and Specifications VEHICLE DIMENSIONS Regular Cab Vehicle Styleside 6.5’ Flareside 6.5’ Styleside 8.0’ dimensions box - inches box - inches box - inches (mm) (mm) (mm) (1) Overall 211.2 (5364) 211.2 (5364) 229.8 (5837) length (2) Overall 78.9 (2005) 78.9 (2005) 78.9 (2005) width...
Page 323 Maintenance and Specifications SuperCab Vehicle Styleside 5.5’ Styleside / Styleside 8.0’ dimensions box - inches Flareside 6.5’ box - inches (mm) box - inches (mm) (mm) (1) Overall 217.8 (5532) 229.8 (5837) 248.4 (6309) length (2) Overall 78.9 (2005) 78.9 (2005) 78.9 (2005) width (3) Overall...
Page 324 Maintenance and Specifications Super Crew Vehicle dimensions Styleside 5.5’ box - Styleside 6.5’ box - inches (mm) inches (mm) (1) Overall length 223.8 (5685) 235.8 (5990) (2) Overall width 78.9 (2005) 78.9 (2005) (3) Overall height – 73.5 (1867) / 73.5 (1867) / 4x2/4x4 76.0 (1931)
Page 325 Maintenance and Specifications Super Crew Vehicle dimensions Styleside 5.5’ box - Styleside 6.5’ box - inches (mm) inches (mm) (4) Wheelbase 138.5 (3518) 150.5 (3823 ) (5) Track - Front 67.0 (1701) 67.0 (1701) (5) Track - Rear 67.0 (1701) 67.0 (1701) 2006 F-150 (f12) Owners Guide (post-2002-fmt)
Page 326 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
Page 327 Maintenance and Specifications The Vehicle Identification Number (VIN) contains the following information: 1. World manufacturer identifier 2. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint System 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6.
Page 328: Accessories
Accessories GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 329 Accessories Lifestyle Bedliners and bedmats Cargo organization and management Rear seat entertainment systems Towing mirrors Trailer hitches, wiring harnesses and accessories Peace of mind Mobile-Ease hands free communication system Remote start Vehicle security systems For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: •...
Page 330: Index
