Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 7 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 8 Driving chapter. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Notice to owners of pickup trucks and utility type vehicles Utility vehicles have a significantly higher rollover rate than other types of vehicles.
Page 9 Introduction Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Airbag - Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor...
Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Base instrument cluster Base with Tachometer instrument cluster...
Page 13 Instrument Cluster Family carrier instrument cluster Mid instrument cluster...
Page 14 Instrument Cluster Luxury instrument cluster Harley-Davidson instrument cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 15 Instrument Cluster Service engine soon: The Service engine soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter.
Page 16 Instrument Cluster low brake fluid level and the brake system should be inspected immediately by your authorized dealer. Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your authorized dealer.
Page 17 Instrument Cluster Traction Control : Illuminates when the Traction Control active. If the light remains on, have the system serviced immediately, refer to the Driving chapter for more information. Four wheel drive low: Illuminates when four-wheel drive low is engaged. Four wheel drive high: Illuminates 4x4 HI when four-wheel drive high is...
Page 18 Instrument Cluster Check fuel cap: Displays when the fuel cap may not be properly installed. Continued driving with this display on may cause the Service engine soon warning light to come on. Refer to Fuel filler cap in the Maintenance and Specifications chapter.
Page 19: Gauges
Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating.
Page 20 Instrument Cluster Odometer: Registers the total miles (kilometers) of the vehicle. • With Mini Message Center • With Full Message Center Refer to Message Center in the Drivers Controls chapter on how to switch the display from Metric to English. Trip odometer: Registers the miles (kilometers) of individual journeys.
Page 21 Instrument Cluster Engine oil pressure gauge: Indicates engine oil pressure. The needle should stay in the normal operating range (between “L” and “H”). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level.
Page 22: Entertainment Systems
Entertainment Systems AUDIO SYSTEMS AM/FM Stereo System (if equipped) Tune: Press to manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Audio: Press to access select various settings. Treble: Press to adjust the treble setting. SEEK, SEEK Bass: Press to adjust the bass setting.
Page 23 Entertainment Systems Setting the clock: Press until HR or Mn is displayed. Press SEEK to adjust the hours/minutes. 3. Seek: Press to access the next/previous strong station. 4. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns.
Page 24: Am/Fm Stereo With Cd
Entertainment Systems AM/FM Stereo Single CD/Satellite Compatible Sound System (if equipped) Tune: In radio mode, press to manually go up ( ) or down ( ) the radio frequency. In menu mode, use to select various settings. In Satellite Radio mode (if equipped), press to enter TEXT MODE and scroll through the current song title, artist, channel category and Sirius Long Channel Name.
Page 25 Entertainment Systems 3. Menu: Press to toggle through the following modes: CATEGORY (Satellite Radio if equipped): Press MENU until the currently active category appears in the display (CATEGORY MODE). In CATEGORY MODE, press to scroll through the list of available Sirius channel Categories (Pop, Rock, News, etc.) Press SEEK SCAN to select the category.
Page 26 Entertainment Systems CLOCK (Setting the clock): Press MENU until SELECT HOUR or SELECT MINS is displayed. Use SEEK, SEEK to adjust the hours/minutes. 4. Aux: Press to toggle between FES/DVD and AUX. If no auxiliary sources are available, NO AUX AUDIO will be displayed.
Page 27 Entertainment Systems 9. Repeat: Press to repeat the current CD track. 10. Fast forward: Press to manually advance in a CD track. 11. Rewind: Press to manually reverse in a CD track. 12. Memory presets: To set a station: Select frequency band AM/FM1/FM2;...
Page 28: Am/Fm Stereo Cassette With Cd
Entertainment Systems 16. CD: Press to enter CD mode. If a CD is already loaded into the system, CD play will begin where it ended last. 17. CD eject: Press to eject a CD. 18. CD slot: Insert a CD label side AM/FM Single CD/Cassette/Satellite Compatible Sound System (if equipped) Tune: In radio mode,...
Page 29 Entertainment Systems In TEXT MODE, sometimes the display text requires additional text to be displayed. When the > indicator is active press SEEK to view the additional display text. When the < indicator is active press SEEK to view to the previous display text. In CATEGORY MODE, press to scroll through the list of available Sirius channel Categories (Pop, Rock, News, etc.).
Page 30 Entertainment Systems display. Press to select a different category. You may also select CATEGORY ALL to seek all available Sirius categories and channels. Satellite radio is available only in the continental United States. TREB (Treble): Press MENU until TREBLE appears in the display. SEEK to adjust the treble levels.
Page 31 Entertainment Systems 6. Tape eject: Press to eject a tape. 7. Text: This control currently not supported. 8. Shuffle: Press to play CD tracks in random order on the selected CD. 9. Compress (Compression): In CD mode, brings soft and loud CD passages together for a more consistent listening level.
Page 32 Entertainment Systems 17. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. 18.
Page 33: Am/Fm Stereo With In-Dash Six Cd
Entertainment Systems Premium/Audiophile In-Dash Six CD/MP3/Satellite Compatible Sound System (if equipped) Tune/Disc selector: In radio mode, press to manually go up ) or down ( ) the radio frequency. In menu mode, use to select various settings. In CD mode, press to select the desired disc. In Satellite Radio mode (if equipped), press to enter TEXT MODE and scroll through the current song title, artist, channel category...
Page 34 Entertainment Systems 2. Phone/mute: Press to mute the playing media. Press again to return to the playing media. 3. Menu: Press to toggle through the following modes: CATEGORY (Satellite Radio if equipped): Press MENU until the currently active category appears in the display (CATEGORY MODE). In CATEGORY MODE, press to scroll through the list of available Sirius channel Categories (Pop, Rock, News, etc.) Press...
Page 35 Entertainment Systems Occupancy mode: (Available on Audiophile radios only): Press MENU repeatedly to access. Press SEEK to optimize sound for ALL SEATS, DRIVERS SEAT or REAR SEATS. CLOCK (Setting the clock): Press until SELECT HOUR or SELECT MINS is displayed. Press SEEK to adjust the hours/minutes.
Page 36 Entertainment Systems 5. Seek: In radio mode, press to access the previous/next strong station. In CD mode, press access the previous/next CD track. In Satellite Radio mode (if equipped), press SEEK to seek to the previous/next channel. If a specific category is selected, (Jazz, Rock, News, etc.), press SEEK to seek to the previous/next channel in...
Page 37 Entertainment Systems In Satellite Radio mode (if equipped), there are 18 available presets, six each for SAT1, SAT2 and SAT3. To save satellite channels in your memory presets, tune to the desired channel then press and hold a preset control until sound returns. Satellite radio is available only in the continental United States.
Page 38 Entertainment Systems GENERAL AUDIO INFORMATION Radio frequencies: AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz Radio reception factors: There are three factors that can affect radio reception: •...
Page 39 (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 40 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 41 Entertainment Systems Radio Display Condition Action Required ACQUIRING Radio requires more No action required. than two seconds to This message should produce audio for the disappear shortly. selected channel. SAT FAULT Internal module or If this message does system failure not clear within a short present.
Page 42 Entertainment Systems Radio Display Condition Action Required NO TEXT Category information Category information not available. not available at this tome on this channel. The system is working properly. NO SIGNAL Loss of signal. You are in a location that is blocking the SIRIUS signal (i.e., tunnel, under an overpass, dense foliage,...
Page 43: Climate Controls
Climate Controls HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 44: Manual Heating And Air Conditioning
Climate Controls 3. Set the fan speed to the highest setting. 4. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
Page 45 Climate Controls Rear defroster (if equipped): Press to defrost the rear window. Refer to Rear window defroster (if equipped) later in this chapter for more information. Heated mirrors (if equipped): Press to activate/deactivate. This function will clear snow, fog and thin ice from the side rear view mirrors. 4.
Page 46: Automatic Temperature Control
Climate Controls Panel ( ) and panel/floor ( ) modes: • Move the temperature control to the coolest setting. • Select A/C and recirculated air ( ). Use recirculated air with A/C to provide colder airflow. • Set the fan to the highest speed initially, then adjust to maintain comfort.
Page 47 Climate Controls Temperature conversion: To switch between Fahrenheit and Celsius: If your vehicle is equipped with a full message center, refer to Setup menu in the Message center section of the Driver Controls chapter for more information. If your vehicle is equipped with a mini message center, see your authorized dealer for temperature conversion.
Page 48 Climate Controls engaged manually in any other airflow selection except (defrost). Recirculation may turn off automatically. 5. A/C control: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO, (defrost) and (floor/defrost).
Page 49 Climate Controls Automatic Temperature Control (ATC) system with heated seats (if equipped) Temperature conversion: To switch between Fahrenheit and Celsius: If your vehicle is equipped with a full message center, refer to Units (Fahrenheit/Celsius) in the Driver Controls chapter. If your vehicle is equipped with a mini message center, refer to Mini message center electronic compass temperature display in the Driver Controls Chapter.
Page 50 Climate Controls MAX A/C: For maximum cooling performance, press , A/C, and set the temperature to 60°F and the highest blower setting. Defrost: Distributes outside air through the windshield defroster vents and demister vents. Can be used to clear the windshield of fog and thin ice.
Page 51 Climate Controls 12. A/C control: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO, (defrost) and (floor/defrost). 13. OFF: Outside air is shut out and the fan will not operate. 14.
Page 52: Rear Window Defroster
Climate Controls Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. REAR WINDOW DEFROSTER (IF EQUIPPED) The rear defroster control is located on the climate control panel and works to defrost your rear window from fog and thin ice.
Page 53: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control clockwise to the first position turn on the parking lamps. Rotate clockwise to the second position to also turn on the headlamps. Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 54 Lights High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. In order for the DRLs to function: •...
Page 55 Lights Foglamp control (if equipped) The headlamp control also operates the foglamps. The foglamps can be turned on only when the headlamp control is in the position and the high beams are not turned on. Pull headlamp control towards you to turn foglamps on.
Page 56 Lights Vertical aim adjustment 1. Park the vehicle directly in front of a wall or screen on a level surface, approximately 25 feet (7.6 meters) away. • (1) 8 feet (2.4 meters) • (2) Center height of lamp to ground •...
Page 57: Turn Signal Control
Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Map lamps To turn on the map lamps, press the control next to each lamp. Rear map lamp (if equipped) The rear map lamp lights are located on the end of the overhead rail system.
Page 58 Lights Rear dome lamp (if equipped) • ON or : The dome light will stay on. • DOOR or middle position: The dome light will only come on if a door is opened. • OFF or : The lamp will not come on at all.
Page 59: Bulb Replacement
Lights BULB REPLACEMENT Headlamp Condensation The headlamps are vented to equalize pressure. When moist air enters the headlamp(s) through the vents, there is a possibility that condensation can occur. This condensation is normal and will clear within 45 minutes of headlamp operation. Using the right bulbs Replacement bulbs are specified in the chart below.
Page 60 Lights Replacing headlamp bulbs 1. Make sure that the headlamp control is in the OFF position and open the hood. 2. At the top and inboard side of the headlamp, peel the protective cover back from the lower screws and loosen the three retaining screws.
Page 61 Lights Replacing front parking lamp/turn signal/sidemarker bulbs 1. Make sure the headlamp control is in the OFF position and open the hood. 2. At the top and inboard side of the headlamp, peel the protective cover back from the lower screws and loosen the three retaining screws.
Page 62 Lights Replacing tail/brake/turn signal/backup lamp bulbs 1. Make sure the headlamp control is in the OFF position. 2. Open the tailgate to expose the lamp assembly screws and remove the two screws from the tail lamp assembly. 3. Carefully pull the lamp assembly straight rearward from the tailgate pillar to disengage two hidden snap-in retainers.
Page 63 Lights Replacing foglamp bulbs (if equipped) 1. Make sure the headlamp control is in the OFF position. 2. Remove the bulb socket from the foglamp by turning counterclockwise. 3. Disconnect the electrical connector from the foglamp bulb. Install the new bulb in reverse order. Replacing exterior mounted mirror turn signal indicator lamp bulbs For bulb replacement, see your authorized dealer.
Page 64: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...
Page 65 Driver Controls ILLUMINATED VISOR MIRROR (IF EQUIPPED) Lift the mirror cover to turn on the visor mirror lamps. CENTER CONSOLE (IF EQUIPPED) The center console offers several useful storage features. These include: 1. Cupholders 2. Tissue holder in lid 3. Power point 4.
Page 66 Driver Controls 1. To open the bins, move the center latch forward which will allow the door to be opened. 2. The latches on the side of the bins are to enable the user to remove the bin or add a dealer purchased feature.
Page 67 Driver Controls Bin Removal Attach and remove bins from the rail using the following instructions: Place both palms on the underside of the storage bin, avoiding the storage bin door. Push upwards with palms.
Page 68 Driver Controls While pushing upwards with palms, grip the side latches with fingers and squeeze. With pressure applied with palms and side latches squeezed down, pull downward on the entire storage bin and remove.
Page 69 Driver Controls AUXILIARY POWER POINT (12VDC) Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse. Do not hang any type of accessory or accessory bracket from the plug.
Page 70: Power Windows
Driver Controls POWER WINDOWS (IF EQUIPPED) Do not leave children unattended in the vehicle and do not let children play with the power windows. They may seriously injure themselves. When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings.
Page 71 Driver Controls Power Sliding Back Window (if equipped) To operate the power sliding back window, the ignition switch must be in the Run or Accessory position. • Press and hold the bottom part of the rocker switch to open window all the way to the full open position.
Page 72: Mirrors
Driver Controls EXTERIOR MIRRORS Power side view mirrors To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror. 2. Move the control in the direction you wish to tilt the mirror. 3.
Page 73 Driver Controls Heated outside mirrors (if equipped) Heated mirrors remove ice, mist and fog. To activate the heated mirrors, press the rear defrost button located on the climate control panel. Refer to Rear Window Defrost in the Climate Controls chapter for more information.
Page 74: Speed Control
Driver Controls Never adjust the accelerator and brake pedal with feet on the pedals while the vehicle is moving. SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a speed of 30 mph (48 km/h) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 30 mph (48 km/h).
Page 75 Driver Controls Resuming a set speed Press the RES/RESUME control and release it. This will automatically return the vehicle to the previously set speed. The RES/RESUME control will not work if the vehicle speed is not faster than 30 mph (48 km/h).
Page 76 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET control. Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal or the clutch pedal (if equipped). This will not erase your vehicle’s previously set speed, if RES/RESUME is then selected, the vehicle will return to the previously set speed.
Page 77 Driver Controls In any mode: • Press VOL + or − to adjust volume. Climate control features Press TEMP + or - to adjust temperature. Press FAN + or - to adjust fan speed. MOON ROOF (IF EQUIPPED) The moon roof control is located on the overhead console. Do not let children play with the moon roof or leave children unattended in the vehicle.
Page 78 Driver Controls To open the moon roof: The moon roof is equipped with a one-touch open feature. Press and release control. The moon roof will open to the “comfort” position. Press and release the control again to fully open. To stop the one-touch open feature press either the ROOF control again.
Page 79 Driver Controls When programming your HomeLink Wireless Control System to a garage door or gate, be sure that people and objects are out of the way to prevent potential harm or damage. Do not use the HomeLink Wireless Control System with any garage door opener that lacks safety stop and reverse features as required by U.S.
Page 80 Driver Controls 3. Simultaneously press and hold both the HomeLink and hand-held transmitter button. Do not release the buttons until Step 4 has been completed. Some entry gates and garage door openers may require you to replace Step 3 with procedures noted in the “Gate Operator and Canadian Programming”...
Page 81 Driver Controls Gate Operator & Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting — not allowing enough time for HomeLink to accept the signal from the hand-held transmitter. After completing Steps 1 and 2 outlined in the “Programming” section, replace Step 3 with the following: Note: If programming a garage door opener or gate operator, it is advised to unplug the device during the “cycling”...
Page 82 Driver Controls Erasing HomeLink buttons To erase the three programmed buttons (individual buttons cannot be erased): • Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds.
Page 83 Driver Controls Usually, when something affects the compass readings, the compass will correct itself after a few days of operating your vehicle in normal conditions. If the compass still appears to be inaccurate, a manual calibration may be necessary. Refer to Compass calibration adjustment.
Page 84: Message Center
Driver Controls 1. Start the vehicle. 2. To enter the compass calibration mode, press and hold the button for greater than eight seconds. The display will then show CAL in the display window. 3. Drive the vehicle slowly (less than 3 mph [5 km/h]) in circles until CAL indicator turns off.
Page 85 Driver Controls Info menu This control displays the following control displays: • Odometer/Compass • Trip odometer/Odometer/Compass • Distance to Empty • Average Fuel Economy • Trip Elapsed Drive Time Odometer/Trip odometer Refer to Gauges in the Instrument Cluster chapter. Compass display The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna.
Page 86 Driver Controls Compass zone/calibration adjustment 1. Determine your magnetic zone by referring to the zone map. 2. Turn ignition to the ON position. 3. Start the engine. 4. From Info menu, select the Compass/Odometer function. (Do not select Trip, DTE, or AFE. The top of the message center must be blank).
Page 87 Driver Controls 10. The compass is now calibrated. Distance to empty (DTE) Selecting this function from the INFO menu estimates approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition OFF when refueling to allow this feature to correctly detect the added fuel.
Page 88 Driver Controls 1. Drive the vehicle at least 5 miles (8 km) with the speed control system engaged to display a stabilized average. 2. Record the highway fuel economy for future reference. It is important to press the RESET control after setting the speed control to get accurate highway fuel economy readings.
Page 89 Driver Controls The sequence of the system check report and how it appears in the message center is as follows: 1. FUEL LEVEL 2. ENGINE TEMP 3. OIL PRESSURE 4. BRAKE FLUID LEVEL 5. CHARGING SYSTEM Units (English/Metric) 1. Select this function from the SETUP menu for the current units to be displayed.
Page 90 Driver Controls Language 1. Select this function from the SETUP menu for the current language to be displayed. 2. Pressing the RESET control cycles the message center through each of the language choices. 3. Press and hold the RESET control to set the language choice. System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems.
Page 91 Driver Controls Warning display Status Door ajar Warning can be reset Low fuel level Warning returns after 10 minutes Check charging system Low brake fluid level Low oil pressure Check engine temperature Reduced engine power Stop engine safely Check fuel cap Warning returns after the ignition key is turned from OFF to ON.
Page 92 Driver Controls CHECK CHARGING SYSTEM. Displayed when the electrical system is not maintaining proper voltage. If you are operating electrical accessories when the engine is idling at a low speed, turn off as many of the electrical loads as soon as possible. If the warning stays on or comes on when the engine is operating at normal speeds, have the electrical system checked as soon as possible.
Page 93: Tailgate
Driver Controls POSITIVE RETENTION FLOOR MAT Only use one set of floor mats at any given time. Position the floor mat so that the eyelet is over the pointed end of the retention post. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal.
Page 94 Driver Controls Tailgate removal Your tailgate is removable to allow more room for loading. 1. Lower the tailgate. 2. Use a screwdriver to pry the spring clip (on each connector) past the head of the support screw. Disconnect cable. 3. Disconnect the other cable. 4.
Page 95 Driver Controls 4. Evenly push down on the extender and push the round knobs in on each side locking it in place. Green markings on the shaft indicate the locked position. The locking clip screws below the middle bar can be tightened counterclockwise for extra security.
Page 96: Locks And Security
Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. Refer to the SecuriLock passive anti-theft system section in this chapter for more information.
Page 97 Locks and Security CHILDPROOF DOOR LOCKS (IF EQUIPPED) • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 98 Locks and Security • unlock the vehicle doors without a key. • lock all the vehicle doors without a key. • activate the personal alarm. If there are problems with the remote entry system, make sure to take ALL remote entry transmitters with you to your authorized dealer in order to aid in troubleshooting the problem.
Page 99 Locks and Security (lock) and (unlock) features will work again after: • a door has become ajar, • the ignition is turned to the 3 (ON) position, or • using the UNLOCK control on your remote entry transmitter or unlocking via the keyless entry keypad. Deactivating/activating power door lock/unlock disable feature All vehicle doors must be closed before beginning the procedure.
Page 100 Locks and Security Activating the memory feature To activate this feature: 1. Position the seat and adjustable pedals to the positions you desire. 2. Press the SET control on the driver’s seat. 3. Within 5 five seconds, press one control on the remote transmitter and then press the 1 or 2 control on the driver’s door panel to which you would like to associate with Driver 1...
Page 101 Locks and Security 2. Do not wipe off any grease on the battery terminals on the back surface of the circuit board. 3. Remove the old battery. Note: Please refer to local regulations when disposing of transmitter batteries. 4. Insert the new battery. Refer to the diagram inside the remote entry transmitter for the correct orientation of the battery.
Page 102 Locks and Security To program the transmitters yourself: • Unlock all doors using the power door lock/unlock control. Insert a key and turn the ignition from the 1 (OFF/LOCK) to the 3 (ON) position and cycle between 1 (OFF/LOCK) and 3 (ON) eight times in rapid succession (within 10 seconds) with the eighth turn ending in the 3 (ON) position.
Page 103 Locks and Security The inside lights will not turn off if: • they have been turned on with the dimmer control, or • any door is open. The battery saver will shut off the interior lamps 30 minutes after the last door is closed, even if the dimmer control is on.
Page 104 Locks and Security 4. Within five seconds, press the control two times. Note: One horn chirp should be heard, indicating the system has been disabled. Conversely, a horn chirp followed by a honk will indicate the system is enabled. Pressing the power door control two times again will turn the feature ON if it was previously OFF, or OFF if it was previously ON.
Page 105 Locks and Security Power door unlock/lock procedure You must complete Steps 1–5 within 30 seconds, or the procedure will have to be repeated. If the procedure needs to be repeated, you must wait a minimum of 30 seconds to begin again. 1.
Page 106 Locks and Security Message center procedure For information regarding the activation and deactivation of the autolocks feature using the message center, refer to Message center (if equipped) in the Driver Controls chapter. KEYLESS ENTRY SYSTEM (IF EQUIPPED) You can use the keyless entry keypad to: •...
Page 107 Locks and Security Programming a personal entry code To create your own personal entry code: 1. Enter the factory set code (keypad will illuminate when pressed). 2. Within five seconds press the 1 • 2 on the keypad. 3. Enter your personal 5-digit code. Each number must be entered within five seconds of each other.
Page 108: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 109 Locks and Security Automatic arming The vehicle is armed immediately after switching the ignition to the 1 (OFF/LOCK) position. Automatic disarming Switching the ignition to the 3 (ON) position with a coded key disarms the vehicle. Replacement keys If your keys are lost or stolen and you don’t have an extra coded key, you will need to have your vehicle towed to an authorized dealer.
Page 110 Locks and Security 1. Insert the first previously programmed coded key into the ignition and turn the ignition from the 1 (OFF/LOCK) position to the 3 (ON) position (maintain ignition in the 3 (ON) position for at least one second, but no more than ten seconds).
Page 111: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 112 Seating and Safety Restraints Push control to lower head restraint. Front seat • Lift the track release bar to move the seat forward or rearward. Make sure that the seat is relatched into place. • Pull the release lever handle located on the side of the seat up to move the seat back forward or backward.
Page 113 Seating and Safety Restraints Using the armrest (if equipped) Push the release control to move the armrest up or down. Using the manual lumbar support For more lumbar support, turn the lumbar support control toward the front of vehicle. For less lumbar support, turn the lumbar support control toward the rear of vehicle.
Page 114 Seating and Safety Restraints Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the passenger sensing system, resulting in serious injury or death in a crash. Always sit upright against your seatback, with your feet on the floor.
Page 115 Seating and Safety Restraints Memory seats/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat and adjustable pedals to two programmable positions. The memory seat control is located on the driver’s seat. • To program position one, move the driver seat, and adjustable pedals to the desired position.
Page 116 Seating and Safety Restraints The head restraints can be moved up and down. Lift the head restraint so that it is located directly or as close as possible behind your head. Push control to lower head restraint. Folding up the rear seats (if equipped ) The rear seat has a split 60/40 cushion.
Page 117: Safety Restraints
Seating and Safety Restraints Returning the seat to seating position Before returning the seatback to its original position, make sure that cargo or any objects are not trapped underneath the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched.
Page 118 Seating and Safety Restraints How does the Personal Safety System work? The Personal Safety System can adapt the deployment strategy of your vehicle’s safety devices according to crash severity and occupant classification and conditions. A collection of crash and occupant sensors provides information to the Restraints Control Module (RCM).
Page 119 Seating and Safety Restraints in rear-facing child seats, this occurs because they are initially sitting very close to the airbag. For other occupants, this occurs when the occupant is not properly restrained by seat belts or child safety seats and they move forward during pre-crash braking.
Page 120 Seating and Safety Restraints position the occupant relative to the airbag to improve protection. The safety belt pretensioners can be either activated alone or, if the collision is of sufficient severity, together with the airbags. Front outboard safety belt energy management retractors The front safety belt energy management retractors allow webbing to be pulled out of the retractor in a gradual and controlled manner in response to the occupant’s forward momentum.
Page 121 Seating and Safety Restraints To reduce the risk of injury, make sure children sit in the back seat where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.
Page 122 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 123 Seating and Safety Restraints 2. Insert the belt into the clip on the back panel. Protect the stowed belt if you carry cargo this may damage or soil the belt. If the belt has been disconnected to carry large objects behind the seat, reconnect it as follows: 1.
Page 124 Seating and Safety Restraints shortened, but pinches the webbing to keep the lap portion from getting longer. The cinch tongue is designed to slip during a crash, so always wear the shoulder belt properly and don’t allow any slack in either the lap or shoulder portions.
Page 125 Seating and Safety Restraints Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only.
Page 126 Seating and Safety Restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 127 Seating and Safety Restraints When to use the automatic locking mode • Anytime a child safety seat is installed in a front outboard passenger in a Regular Cab/ SuperCab/ SuperCrew or any rear seating position of a SuperCab or SuperCrew. The Regular Cab front center seatbelt has a cinch mechanism.
Page 128 Seating and Safety Restraints 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 129 Seating and Safety Restraints The driver and front outboard passenger safety belt pretensioners are designed to activate only during certain frontal or near-frontal collisions with sufficient longitudinal deceleration. A safety belt buckle pretensioner is a device which tightens the webbing of the lap and shoulder belts during some collisions in such a way that they fit more snugly against the body.
Page 130 Seating and Safety Restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and right front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 131 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 132 Seating and Safety Restraints BeltMinder The BeltMinder feature is a supplemental warning to the safety belt warning function. This feature provides additional reminders by intermittently sounding a chime and illuminating the safety belt warning lamp in the instrument cluster when the driver’s and front passenger’s safety belt is unbuckled.
Page 133 Seating and Safety Restraints If... Then... The driver’s or front The BeltMinder feature is activated - passenger’s safety belt becomes the safety belt warning light illuminates unbuckled for approximately 1 and the warning chime sounds for minute while the vehicle is 6 seconds every 30 seconds, repeating traveling at least 3 mph (5 km/h) for approximately 5 minutes or until...
Page 134 Seating and Safety Restraints Reasons given... Consider... “Traffic is light” Nearly 1 of 2 deaths occur in single-vehicle crashes, many when no other vehicles are around. “Belts wrinkle my clothes” Possibly, but a serious crash can do much more than wrinkle your clothes, particularly if you are unbelted.
Page 135 Seating and Safety Restraints Read Steps 1 - 4 thoroughly before proceeding with the deactivation/activation programming procedure. The driver and front passenger BeltMinder features can be deactivated/activated by performing the following procedure: Before following the procedure, make sure that: • The parking brake is set •...
Page 136: Airbags
Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 1. Airbag cover The airbag supplemental restraint system is designed to work in conjunction with the safety belts to help protect the driver and front outboard passenger from certain upper body injuries. The term “supplemental restraint”...
Page 137 Seating and Safety Restraints Important SRS precautions All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an airbag (SRS) is provided. Always transport children 12 years old and under in the back seat if your vehicle has a back seat.
Page 138 Seating and Safety Restraints Do not put anything on or over the airbag cover (1). Placing objects on or over the airbag cover may cause those objects to be thrown by the airbag into your face and torso or may result in a failure of the airbag to inflate properly, both of which could result in serious injury.
Page 139 Seating and Safety Restraints Children and airbags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seat than in the front seat.
Page 140 Seating and Safety Restraints How does the airbag supplemental restraint system work? The airbag SRS is designed to activate when the vehicle sustains sufficient longitudinal deceleration. The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system.
Page 141 Seating and Safety Restraints If the airbag has deployed, the airbag will not function again and must be replaced immediately. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a collision. Determining if the system is operational The SRS uses readiness lights in the instrument cluster or a tone to indicate the condition of the system.
Page 142 Seating and Safety Restraints The front passenger sensing system will disable (will not inflate) the front passenger’s frontal airbag if: • the front passenger seat is unoccupied, or has small/medium objects in the front seat, • the system determines that an infant is present in a rear-facing infant seat that is installed according to the manufacturer’s instructions, •...
Page 143 Seating and Safety Restraints • When the front passenger sensing system enables the front passenger frontal airbag (may inflate), the indicator will be unlit and stay unlit. If a person of adult size is sitting in the front passenger’s seat, but the passenger airbag off or pass airbag off indicator lamp is lit, it is possible that the person isn’t sitting properly in the seat.
Page 144 Seating and Safety Restraints The front passenger sensing system may detect small or medium objects placed on the seat cushion. For most objects that are in the front passenger seat, the passenger airbag will be disabled. Even though the passenger airbag is disabled, the pass airbag off lamp may or may not be illuminated according to the table below.
Page 145 Seating and Safety Restraints To reduce the risk of possible serious injury: Do not stow objects in seat back map pocket (if equipped) or hang objects off seat back if a child is in the front passenger seat. Do not place objects underneath the front passenger seat or between the seat and the center console (if equipped).
Page 146: Child Restraints
Seating and Safety Restraints If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Guide.
Page 147 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 148 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 149 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 150 Seating and Safety Restraints Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a collision. SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child.
Page 151 36 kg (80 pounds) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
Page 152 Seating and Safety Restraints 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat...
Page 153 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 154 Seating and Safety Restraints 8. Allow the safety belt to retract to remove any slack in the belt. 9. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward.
Page 155 Seating and Safety Restraints 2. If the center lap/shoulder safety belt has been disconnected from the seat to carry large cargo behind the seat, reconnect it by buckling the small buckle on the end of the belt into the mini-buckle on the driver’s side.
Page 156 Seating and Safety Restraints 5. Insert the belt tongue into the proper buckle for that seating positions until you hear a snap and feel it latch. Make sure the tongue is securely latched to the buckle by pulling on the tongue. 6.
Page 157 Seating and Safety Restraints 9. Check from time to time to be sure that there is no slack in the lap/shoulder belt. The shoulder belt must be snug to keep the lap belt tight during a collision. Installing child safety seats in the front row lap belt seating positions (SuperCab and SuperCrew) Installing a child safety seat in the front row lap seating position should be avoided if at all possible.
Page 158 Seating and Safety Restraints Attaching child safety seats with tether straps Most new forward-facing child safety seats include a tether strap which goes over the back of the seat and hooks to an anchoring point. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap.
Page 159 Seating and Safety Restraints Front seat tether strap attachment 1. Position the child safety seat on the seat cushion. 2. Route the child safety seat tether strap over the back of the seat and under the head restraint. 3. Locate the correct anchor for the selected seating position. •...
Page 160 Seating and Safety Restraints • Front seat Regular Cab center (located on back panel) If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Install the child safety seat tightly using the LATCH anchors or safety belts.
Page 161 Seating and Safety Restraints Rear seat tether strap attachment There are three loops of webbing just above the back of the rear seat (along the bottom edge of the rear window) in the SuperCab and SuperCrew. These loops are to be used as both routing loops and anchor loops for up to three child safety seat tether straps.
Page 162 Seating and Safety Restraints 3. Install the child safety seat tightly using the LATCH anchors or safety belts. Follow the instructions in this chapter. 4. Tighten the tether strap according to the child seat manufacturer’s instructions. Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments for child seat anchors Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle.
Page 163 Seating and Safety Restraints The lower anchors for child seat installation are located at the rear section of the seat between the cushion and seat back. The LATCH anchors are below the locator buttons on the seat back. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments.
Page 164: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 165 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter.
Page 166: Tire Information
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 167 Tires, Wheels and Loading Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 168: Tire Inflation
Tires, Wheels and Loading Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture.
Page 169 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 170 Tires, Wheels and Loading higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door. The cold inflation pressure should never be set lower than the recommended pressure on the Safety Compliance Certification Label or Tire Label.
Page 171 Tires, Wheels and Loading 6. Visually inspect the tires to make sure there are no nails or other objects embedded that could poke a hole in the tire and cause an air leak. 7. Check the sidewalls to make sure there are no gouges, cuts or bulges. TIRE CARE Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and...
Page 172 Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 173 Tires, Wheels and Loading It is recommended that the two front tires or two rear tires generally be replaced as a pair. Safety practices Driving habits have a great deal to do with your tire mileage and safety. • Observe posted speed limits •...
Page 174 Tires, Wheels and Loading Front wheel drive (FWD) vehicles and those with an independent rear suspension (if equipped) may require alignment of all four wheels. The tires should also be balanced periodically. An unbalanced tire and wheel assembly may result in irregular tire wear. Tire rotation Rotating your tires at the recommended interval (as indicated in the scheduled maintenance information that comes with your vehicle) will...
Page 175 Tires, Wheels and Loading Note: After having your tires rotated, inflation pressure must be checked and adjusted to the vehicle requirements. INFORMATION CONTAINED ON THE TIRE SIDEWALL Both U.S. and Canada Federal regulations require tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a U.S.
Page 176 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. 7. H: Indicates the tire’s speed rating. The speed rating denotes the speed at which a tire is designed to be driven for extended periods of time under a standard condition of load and inflation pressure.
Page 177 Tires, Wheels and Loading 9. M+S or M/S: Mud and Snow, or AT: All Terrain, or AS: All Season. 10. Tire Ply Composition and Material Used: Indicates the number of plies or the number of layers of rubber-coated fabric in the tire tread and sidewall.
Page 178 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 179 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 180: Vehicle Loading
Tires, Wheels and Loading SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
Page 181 Tires, Wheels and Loading Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 182 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 183 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 184 Tires, Wheels and Loading GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door.
Page 185 Tires, Wheels and Loading Maximum Loaded Trailer Weight – is the highest possible weight of a fully loaded trailer the vehicle can tow. It assumes a vehicle with only mandatory options, no cargo (internal or external), a tongue load of 10–15% (conventional trailer) or king pin weight of 15–25% (fifth wheel trailer), and driver only (150 lb.
Page 186 Tires, Wheels and Loading 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle.
Page 187: Trailer Towing
Tires, Wheels and Loading Special loading instructions for owners of pickup trucks and utility-type vehicles For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in the Driving chapter of this Owner’s Guide. Loaded vehicles may handle differently than unloaded vehicles.
Page 188 Tires, Wheels and Loading Regular Cab 4x2 (126” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.2L (with 3.31 7200 (3266) 2400 (1089) manual 3.55 8500 (3856) 3700 (1678) transmission) 4.2L (with 3.55 10000 (4536) 5200 (2358) automatic 3.73 10500 (4763)
Page 189 Tires, Wheels and Loading Regular Cab 4x4 (126” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L 3.55 11500 (5216) 6300 (2857) 4.6L 3.73 12000 (5443) 6800 (3084) 5.4L (with 17” 3.55 13000 (5897) 7700 (3492) tires) 5.4L (with 18”...
Page 190 Tires, Wheels and Loading SuperCab 4x2 (132.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.55 11500 (5216) 6300 (2858) tires) 4.6L (with 17” 3.73 12000 (5443) 6800 (3084) tires) 4.6L (with 18” 3.55 11000 (4989) 5800 (2630)
Page 191 Tires, Wheels and Loading SuperCab 4x2 (144.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.55 11700 (5307) 6400 (2903) tires) 4.6L (with 18” 3.55 11200 (5081) 5900 (2677) tires) 4.6L (with 17” 3.73 12200 (5534) 6900 (3130)
Page 192 Tires, Wheels and Loading SuperCab 4x4 (132.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.55 11500 (5216) 6000 (2721) tires) 4.6L (with 18” 3.55 11500 (5216) 5500 (2494) tires) 4.6L (with 17” 3.73 12000 (5443) 6500 (2948)
Page 193 Tires, Wheels and Loading SuperCab 4x4 (144.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.55 11700 (5307) 6200 (2812) tires) 4.6L (with 18” 3.55 11700 (5307) 5700 (2585) tires) 4.6L (with 17” 3.73 12200 (5534) 6700 (3039)
Page 194 Tires, Wheels and Loading Crew Cab 4x2 (138.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.55 11700 (5307) 6300 (2858) tires) 4.6L (with 18” 3.55 11700 (5307) 5800 (2630) tires) 4.6L (with 17” 3.73 12200 (5534) 6800 (3084)
Page 195 Tires, Wheels and Loading Crew Cab 4x2 (150.5” wheelbase) Engine Rear axle ratio Maximum Maximum GCWR-lb. (kg) trailer weight-lb. (kg) 4.6L (with 17” 3.55 11700 (5307) 6200 (2812) tires) 4.6L (with 18” 3.55 11700 (5307) 5700 (2585) tires) 4.6L (with 17” 3.73 12200 (5534) 6700 (3039)
Page 196 Tires, Wheels and Loading Trailer frontal area considerations: • Not to exceed towing vehicle frontal area without Class IV trailer towing package • Not to exceed 60 square feet (5.52 square meters) with Class IV trailer towing package Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle.
Page 197 Tires, Wheels and Loading Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications. The trailer brakes must meet local and Federal regulations. Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system.
Page 198 Tires, Wheels and Loading Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your Scheduled Maintenance Information for more information. Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination.
Page 199: Recreational Towing
Tires, Wheels and Loading Exceeding these limits may allow water to enter vehicle components: • causing internal damage to the components. • affecting driveability, emissions and reliability. Replace the rear axle lubricant any time the axle has been submerged in water.
Page 200 If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, you must disconnect the front (4x4 only) and rear driveshafts. Ford recommends the driveshafts be removed/installed only by a qualified technician at an authorized dealer. See your authorized dealer for driveshaft removal/installation.
Page 201: Driving
Driving STARTING Positions of the ignition 1. OFF/LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. Note: The ignition key cannot be removed from the ignition unless the gearshift lever is securely latched in P (Park). 2.
Page 202 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 203 Driving • Make sure the parking brake is set. BRAKE If starting a vehicle with a manual transmission: • Make sure the parking brake is set. • Push the clutch pedal to the floor 3. Turn the key to 3 (ON) without turning the key to 4 (START).
Page 204 Driving Starting the engine 1. Turn the key to 3 (ON) without turning the key to 4 (START). If there is difficulty in turning the key, rotate the steering wheel until the key turns freely. 2. Turn the key to 4 (START), then release the key as soon as the engine starts.
Page 205: Brakes
Driving To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. BRAKES Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by an authorized dealer.
Page 206 Driving ABS warning lamp The ABS lamp in the instrument cluster momentarily illuminates when the ignition is turned on. If the light does not illuminate during start up, remains on or flashes, the ABS may be disabled and may need to be serviced. Even when the ABS is disabled, normal braking is still effective.
Page 207: Traction Control
Driving Mid and Luxury instrument cluster BRAKE To release, pull the lever (2). Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park) (automatic transmission) or in 1 (First) (manual transmission). TRACTION CONTROL (IF EQUIPPED) Your vehicle may be equipped with a Traction Control system.
Page 208 Driving The Traction Control switch, located on the center console, has an indicator light that illuminates when the system is off. The Traction Control system will automatically turn on every time the ignition is turned off and on. The Traction Control system should normally be left on.
Page 209: Transmission Operation
Driving TRACTION-LOK AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface. Under normal conditions, the Traction-Lok axle functions like a standard rear axle. The axle may exhibit a slight noise or vibration in tight turns with low vehicle speed. This is normal behavior and indicates the axle is working.
Page 210 Driving has blown or the vehicle’s brakelamps are not operating properly. Refer to Fuses and relays in the Roadside Emergencies chapter. If the fuse is not blown, perform the following procedure: 1. Apply the parking brake, turn the ignition to OFF/LOCK, then remove the key.
Page 211 Driving has blown or the vehicle’s brakelamps are not operating properly. Refer to Fuses and relays in the Roadside Emergencies chapter. If the fuse is not blown, perform the following procedure: 1. Apply the parking brake, turn the ignition to LOCK, then remove the key.
Page 212 Driving Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly.
Page 213 Driving • Depress the brake pedal • Move the gearshift lever into the desired gear • Release the parking brake. To put your vehicle in P (Park): • Come to a complete stop • Move the gearshift lever and securely latch it in P (Park) Always set the parking brake fully and make sure the gearshift is latched in P (Park).
Page 214 Driving • Column-shift transmission • Floor-shift transmission The transmission control indicator (TCIL) will illuminate on the instrument cluster. Drive (not shown) Drive is activated when the transmission control switch is pressed. • This position allows for all forward gears except overdrive. •...
Page 215 Driving • To return to D (Overdrive), move the gearshift lever into the D (Overdrive) position. • Selecting 2 (Second) at higher speeds will cause the transmission to downshift to second gear at the appropriate vehicle speed. 1 (First) • Provides maximum engine braking. •...
Page 216 Driving 2. Press the clutch pedal to the floor, then put the gearshift lever in the neutral position. 3. Start the engine, then press the brake pedal and release the parking brake. 4. Move the gearshift lever to 1st gear, then slowly release the clutch pedal while slowly pressing on the accelerator.
Page 217 Driving Maximum downshift speeds Shift from: Transfer case position (if equipped) 2H or 4H 55 mph (89 km/h) 21 mph (34 km/h) (Overdrive) - 4 4 - 3 45 mph (72 km/h) 17 mph (27 km/h) 3 - 2 35 mph (56 km/h) 13 mph (21 km/h) 2 - 1 20 mph (32 km/h)
Page 218 Driving To help avoid personal injury, always use caution when in reverse and when using the RSS. This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 219 Driving The RSS automatically turns on when the gearshift lever is placed in R (Reverse) and the ignition is ON. An RSS control allows the driver to turn the RSS on and off. To turn the RSS off, the ignition must be ON, and the gear selector in R (Reverse).
Page 220 Driving • 4X4 LOW – Momentarily illuminates when the engine is started. Illuminates when 4L is selected. Using a manual 4WD system (if equipped) 2H (2WD High) – Power to the rear wheels only; used for street and highway driving. Provides optimal smoothness and fuel economy at high speeds.
Page 221 Driving 3. Place the transmission in N (Neutral). 4. Move the transfer case lever through N (Neutral) directly to the desired position. • If the transfer case will not engage into 4L (4WD Low), allow the vehicle to coast at a speed below 3 mph (5 km/h), then repeat Steps 2 through 4.
Page 222 Driving 4L (4WD Low) - Uses extra gearing to provide maximum power to all four wheels at reduced speeds. Intended only for off-road applications such as deep sand, steep grades or pulling heavy objects. 4L (4WD Low) will not engage while the vehicle is moving above 3 mph (5 km/h); this is normal and should be no reason for concern.
Page 223 Driving AWD (Auto) - Power delivered to all four wheels, as required, for increased traction. This is appropriate for all on-road driving conditions, such as dry road surfaces, wet pavement, snow, gravel and shallow sand. 4H (Lock) - The “4X4 HI” light will illuminate in the instrument cluster when this position is selected.
Page 224 Driving steering and braking control of your vehicle, you must have all four wheels on the ground and they must be rolling, not sliding or spinning. Basic operating principles • Do not use 4WD on dry, hard surfaced roads. Doing so will produce excessive noise, increase tire wear and may damage drive components.
Page 225 Driving Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur. Do not rock the vehicle for more than a few minutes or damage to the transmission and tires may occur or the engine may overheat.
Page 226 Driving the driveline. Therefore, the vehicle is free to roll even if the automatic transmission is in P (Park) or the manual transmission is in gear. Do not leave the vehicle unattended with the transfer case in the N (Neutral) position.
Page 227 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and...
Page 228 Driving Driving on hilly or sloping terrain Although natural obstacles may make it necessary to travel diagonally up or down a hill or steep incline, you should always try to drive straight up or straight down. Avoid driving crosswise or turning on steep slopes or hills.
Page 229 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 230 Snow Plow Prep Package is not available. Installing the snowplow Weight limits and guidelines for selecting and installing the snowplow can be found in the Ford Truck Body Builders Layout Book, Snowplow section, found at www.fleet.ford.com/truckbbas. A typical installation affects the following: •...
Page 231 Operating the vehicle with the snowplow attached Ford recommends that the F–150 be limited to low speed, personal-use snow removal. Do not use your vehicle for snow removal until it has been driven at least 500 miles (800 km).
Page 232 Do not attempt to service, repair, or modify the air bag supplemental restraint system (SRS) or its fuses. See your Ford or Lincoln Mercury dealer. Transmission operation while plowing •...
Page 233 Driving Engine temperature while plowing When driving with a plow, your engine may run at a higher temperature than normal because the attached snowplow blade will restrict airflow to the radiator. If you are driving more than 15 miles (24 km) at temperatures above freezing, angle the plow blade either full left or full right to provide maximum airflow to the radiator.
Page 234: Roadside Emergencies
50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start • lock-out assistance (key replacement cost is the customer’s responsibility) •...
Page 235 1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673;...
Page 236: Hazard Flasher Switch
Roadside Emergencies HAZARD FLASHER The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Push in the flasher control and all front and rear direction signals will flash.
Page 237: Fuel Pump Shut-Off Switch
Roadside Emergencies FUEL PUMP SHUT-OFF SWITCH This device stops the electric fuel pump from sending fuel to the engine when your vehicle has had a substantial jolt. After an accident, if the engine cranks but does not start, this switch may have been activated.
Page 238 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 239 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 10A* Run/Accessory - Wipers, Instrument cluster, Audio for XL/STX 20A* Stop/Turn lamps, Brake on/off switch 7.5A* Power mirrors, Memory seats and pedals 10A* DVD battery power, Power fold mirror...
Page 240 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 20A* Fuel pump relay, Fuel injectors, Intake manifold runner control (4.2L) 20A* Trailer tow back-up lamps relay (PCB1), Trailer tow parklamp relay (R201) 10A* A/C clutch, 4x4 solenoid PCM relay coil 10A* Climate control module power,...
Page 241 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 10A* LH low beam headlamp 20A* Horn relay (PCB3), Horn power Passenger Air bag Deactivation (PAD) warning lamp, Cluster air bag warning lamp, Cluster RUN /START power SecuriLock transceiver (PATS), PCM IGN monitor 15A* PCM 4x4 power...
Page 242 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description 20A** Ignition switch feed 20A** ABS valves — Not used 30A** Electric trailer brakes 30A** Trailer tow battery charge 30A** Power door locks (BSM) 30A** Passenger power seat 30A** Driver power seat, Adjustable pedals...
Page 243 Roadside Emergencies Auxiliary relay box The relay box is located in the engine compartment on the left fender. • With Daytime Running Lamp (DRL) and 4x4 options • Without Daytime Running Lamp (DRL) and 4x4 options The relays are coded as follows: Fuse/Relay Fuse Amp Description...
Page 244: Changing Tires
Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 245 Roadside Emergencies Use of one of the dissimilar spare tires listed above at any one wheel location can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs •...
Page 246 Roadside Emergencies Location of the spare tire and tools The spare tire and tools for your vehicle are stowed in the following locations: Tool Location Spare tire Under the vehicle, just forward of the rear bumper Jack, jack handle and lug nut Regular Cab: Behind the interior wrench trim on the passenger side of the...
Page 247 Roadside Emergencies Tire change procedure To help prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed.
Page 248 Roadside Emergencies 7. Position the jack according to the following guides and turn the jack handle clockwise until the wheel is completely off the ground. When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the transmission is in P (Park).
Page 249 Roadside Emergencies 9. Replace the flat tire with the spare tire, making sure the valve stem is facing outward. Reinstall the lug nuts until the wheel is snug against the hub. Do not fully tighten the lug nuts until the wheel has been lowered. 10.
Page 250: Lug Nut Torque
M14 x 2.0 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 251: Jump Starting
Roadside Emergencies JUMP STARTING The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Batteries contain sulfuric acid which can burn skin, eyes and clothing, if contacted. Do not attempt to push-start your vehicle.
Page 252 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 253 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 254 Roadside Emergencies 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 255 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 256: Wrecker Towing
Ford recommends your vehicle be towed with a wheel lift or flatbed. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 257: Customer Assistance
Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 258 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 259 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the...
Page 260 You are not bound by the decision but may choose to accept it. If you choose to accept the BBB AUTO LINE decision then Ford must abide by the accepted decision as well. If the arbitrator has decided in...
Page 261 United States and Canada, provided by a network of more than 4,600 participating authorized dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this...
Page 262 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 263: Reporting Safety Defects (U.s. Only)
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your authorized dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 264: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 265 Cleaning PAINT CHIPS Your authorized dealer has touch-up paint and sprays to match your vehicle’s color. Take your color code (printed on a sticker in the driver’s door jamb) to your authorized dealer to ensure you get the correct color. •...
Page 266 Cleaning • 4.2L engine • 4.6L engine...
Page 267 Cleaning • 5.4L engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. •...
Page 268 Cleaning available from your authorized dealer. This washer fluid contains special solution in addition to alcohol which helps to remove the hot wax deposited on the wiper blade and windshield from automated car wash facilities. Be sure to replace wiper blades when they appear worn or do not function properly.
Page 269 Cleaning • Do not use silicone or Teflon-based products. Dust the high gloss areas with a clean, dry cloth, or use Motorcraft Dusting Cloth (ZC-24 or ZC-25) or Motorcraft Dusting Cloth Mitts (ZC-47). For general cleaning, use mild, soapy water and a soft, damp cloth, then dry with a clean, dry cloth, or use or use Motorcraft Dash &...
Page 270 Cleaning • If a ring forms on the fabric after spot cleaning, clean the entire area immediately (but do not oversaturate) or the ring will set. • Do not use household cleaning products or glass cleaners, which can stain and discolor the fabric and affect the flame retardant abilities of the seat materials.
Page 271 Cleaning Cleaning For dirt, use a vacuum cleaner then use a clean, damp cloth or soft brush. For routine cleaning, wipe the surface with a soft, damp cloth. For more thorough cleaning, wipe the surface with a mild soap. If the leather cannot be completely cleaned using a mild soap and water solution, the leather may be cleaned using a commercially available cleaning product “Tanners Preserve Leather Cleaner”...
Page 272 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 273 Cleaning Motorcraft Spot and Stain Remover (U.S. only) (ZC-14) Motorcraft Tire Clean and Shine (ZC-28) Motorcraft Triple Clean (U.S. only) (ZC-13) Motorcraft Ultra-Clear Spray Glass Cleaner (ZC-23) Motorcraft Vinyl Cleaner (Canada only) (CXC-93) Motorcraft Vinyl Conditioner (Canada only) (CXC-94) Motorcraft Wheel and Tire Cleaner (ZC-37–A)
Page 274: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service.
Page 275 Maintenance and Specifications 2. Block the wheels. • Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral). 2. Block the wheels. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 276: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.2L V6 engine 1. Battery 2. Clutch fluid reservoir (manual transmission) 3. Power steering fluid reservoir 4. Brake fluid reservoir 5. Engine coolant reservoir 6. Air filter assembly 7. Engine oil filler cap 8.
Page 277 Maintenance and Specifications 4.6L V8 1. Battery 2. Transmission fluid dipstick (automatic transmission) 3. Engine oil filler cap 4. Power steering fluid reservoir 5. Engine oil dipstick 6. Brake fluid reservoir 7. Engine coolant reservoir 8. Air filter assembly 9. Windshield washer fluid reservoir...
Page 278 Maintenance and Specifications 5.4L V8 1. Battery 2. Transmission fluid dipstick (automatic transmission) 3. Air filter assembly 4. Power steering fluid reservoir 5. Engine oil dipstick 6. Brake fluid reservoir 7. Engine coolant reservoir 8. Engine oil filler cap 9. Windshield washer fluid reservoir...
Page 279 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 280: Engine Oil
Maintenance and Specifications Poor wiper quality can be improved by cleaning the wiper blades and the windshield, refer to Windows and wiper blades in the Cleaning chapter. To prolong the life of the wiper blades, it is highly recommended to scrape off the ice on the windshield before turning on the wipers.
Page 281 Maintenance and Specifications • 4.2L V6 engine • 4.6L/5.4L V8 engine 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again.
Page 282 Maintenance and Specifications • If the oil level is between the lower and upper holes or between the MIN and MAX marks (depending on application), the oil level is acceptable. DO NOT ADD OIL. • 4.2L V6 engine • 4.6L/5.4L V8 engine •...
Page 283 Change your engine oil and filter according to the appropriate schedule listed in scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 284: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance information for the service interval schedules.
Page 285 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 286: Engine Coolant
Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the intervals listed in scheduled maintenance information.
Page 287 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 288 • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (U.S., except CA, OR and NM), VC-7–B (CA, OR and NM), meeting Ford Specification WSS-M97B51–A1. Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
Page 289 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 290 Maintenance and Specifications Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in this section. Fill your engine coolant reservoir as outlined in Adding engine coolant in this section. Severe climates If you drive in extremely cold climates (less than –34°...
Page 291 Maintenance and Specifications How fail-safe cooling works If the engine begins to overheat: • The engine coolant temperature gauge will move to the red (hot) area. • The mini message center (if equipped) will indicate “Check Gauges”, refer to Warning Lights and Chimes in the Instrument Cluster chapter.
Page 292: Fuel Information
Maintenance and Specifications Never remove the coolant reservoir cap while the engine is running or hot. 5. Restart the engine and take your vehicle to an authorized dealer. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to an authorized dealer as soon as possible.
Page 293 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before refueling your vehicle. • Always turn off the vehicle before refueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 294 Maintenance and Specifications Refueling Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 295 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 296 Repairs to correct the effects of using a fuel for which your vehicle was not designed may not be covered by your warranty. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Octane recommendations Your vehicle is designed to use “Regular”...
Page 297 Maintenance and Specifications Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components. If you have run out of fuel: • You may need to cycle the ignition from off to on several times after refueling, to allow the fuel system to pump the fuel from the tank to the engine.
Page 298 Maintenance and Specifications • Use the same filling rate setting (low — medium — high) each time the tank is filled. • Allow no more than three automatic click-offs when filling. • Always use fuel with the recommended octane rating. •...
Page 299 Maintenance and Specifications • Idling for long periods of time (greater than one minute) may waste fuel. • Anticipate stopping; slowing down may eliminate the need to stop. • Sudden or hard accelerations may reduce fuel economy. • Slow down gradually. •...
Page 300 Maintenance and Specifications • To maximize the fuel economy, drive with the tonneau cover installed (if equipped). • Using fuel blended with alcohol may lower fuel economy. • Fuel economy may decrease with lower temperatures during the first 8–10 miles (12–16 km) of driving. •...
Page 301 Maintenance and Specifications If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 302 Maintenance and Specifications 3. The fuel cap may not have been securely tightened. See Fuel filler cap in this chapter. These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel and/or properly tightening the fuel cap. After three driving cycles without these or any other temporary malfunctions present, the indicator should turn off—A driving cycle consists of a...
Page 303 Maintenance and Specifications POWER STEERING FLUID Check the power steering fluid. Refer to scheduled maintenance for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
Page 304 If the fluid level drops, refill the fluid level to the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Ford specification ESA-M6C25–A. Refer to Lubricant specifications in this chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 305 Maintenance and Specifications 1. Clean the reservoir cap before removal to prevent dirt and water from entering the reservoir. 2. Remove cap and rubber diaphragm from reservoir. 3. Add fluid until the level reaches the step in the reservoir. 4. Reinstall rubber diaphragm and cap onto reservoir.
Page 306 Maintenance and Specifications 4. Latch the gearshift lever in P (Park) and leave the engine running. 5. Remove the dipstick, wiping it clean with a clean, dry lint free rag. If necessary, refer to Identifying components in the engine compartment in this chapter for the location of the dipstick.
Page 307 Maintenance and Specifications High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
Page 308 4. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to Lubricant specifications in this chapter.
Page 309 Use only fluid that meets Ford specifications. Refer to Lubricant specifications in this chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 310: Air Filter(S)
Maintenance and Specifications AIR FILTER Refer to scheduled maintenance information for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the Motorcraft air filter element listed. Refer to Motorcraft part numbers in this chapter. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 311 Maintenance and Specifications • 5.4L Engine 1. Release two retainer clamps. 2. Pull air filter tray assembly out toward front of vehicle and lift air filter element up and out of housing. The air filter box needs to be free of any debris before installing a new air filter.
Page 312: Part Numbers
PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 313: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid Motorcraft Fill to line or step and clutch High (for clutch) on fluid Performance reservoir DOT 3 Motor Vehicle Brake Fluid Engine Motorcraft 4.2L V6 engine 17.6 quarts (16.7L)
Page 314 Maintenance and Specifications Fluid Ford Part Application Capacity Name Fuel tank Reg. Cab 6.5’ box / 26.0 gallons (98.4L) SuperCab 5.5’ box SuperCrew 5.5’ box 30 gallons (113.6L) SuperCrew 6.5’ box 27 gallons (102.2L) Standard 35.7 gallons (135.1L) Optional Reg. Cab 8’ box / 27 gallons (102.1L)
Page 315 Maintenance and Specifications Fluid Ford Part Application Capacity Name Rear axle Motorcraft 8.8/9.75 inch axle 5.5 pints (2.6L) 75W-140 High Performance 10.25 inch axle 6.9 pints (3.3L) Rear Axle Lubricant (synthetic) Windshield Motorcraft 4.25 quarts (4.0L) washer fluid Premium Windshield...
Page 316: Lubricant Specifications
Add 4 oz. (118 ml) of Additive Friction Modifier XL–3 or equivalent meeting Ford specification EST-M2C118–A, for complete fill of 8.8 inch and 9.75 inch Traction-Lok axles. Service refill capacity is determined by filling the axle to the bottom of the filler hole with the vehicle on a level surface.
Page 317 Maintenance and Specifications Ford part Ford part Ford Item name or number specification equivalent Motorcraft High Performance Brake fluid and DOT 3 Motor PM-1 ESA-M6C25-A clutch fluid Vehicle Brake Fluid Motorcraft VC-7–A (except Premium Gold CA, OR and WSS- Engine coolant...
Page 318 Maintenance and Specifications Ford part Ford part Ford Item name or number specification equivalent Transmission Premium /steering/parking Long-Life Grease brake linkages and pivots, XG-1-C ESA-M1C75-B brake and clutch pedal shaft (if equipped) Power steering Motorcraft fluid, transfer MERCON ATF case fluid (4X4)
Page 319 Maintenance and Specifications MERCON and MERCON V type fluids are not interchangeable. DO NOT mix MERCON and MERCON V. Use of a transmission fluid that indicates dual usage (MERCON and MERCON V) in an automatic transmission application requiring MERCON may cause transmission damage.
Page 320 Maintenance and Specifications...
Page 321 Maintenance and Specifications SuperCab Vehicle Styleside 5.5’ Styleside / Styleside 8.0’ dimensions box - inches Flareside 6.5’ box - inches (mm) box - inches (mm) (mm) (1) Overall 217.8 (5532) 229.8 (5837) 248.4 (6309) length (2) Overall 78.9 (2005) 78.9 (2005) 78.9 (2005) width (3) Overall...
Page 322 Maintenance and Specifications Super Crew Vehicle dimensions Styleside 5.5’ box - Styleside 6.5’ box - inches (mm) inches (mm) (1) Overall length 223.8 (5685) 235.8 (5990) (2) Overall width 78.9 (2005) 78.9 (2005) (3) Overall height – 73.5 (1867) / 73.5 (1867) / 4x2/4x4 76.0 (1931)
Page 323 Maintenance and Specifications...
Page 324 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure by the trailing edge of the driver’s door or...
Page 325 Maintenance and Specifications The Vehicle Identification Number (VIN) contains the following information: 1. World manufacturer identifier 2. Brake type and Gross Vehicle Weight Rating (GVWR) 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6. Model year 7.
Page 326: Accessories
In addition, each accessory is made from high quality materials and meets or exceeds Ford’s rigorous engineering and safety specifications. Ford Motor Company will repair or...
Page 327 Accessories Tonneau covers Wheels Interior style Electrochromatic compass/temperature interior mirrors Floor mats Speed control Lifestyle Bedliners and bedmats Bed tents Bike racks Cargo organization and management Rear seat entertainment systems Towing mirrors Trailer hitches, wiring harnesses and accessories Peace of mind First aid and highway safety kits Full vehicle covers Keyless entry keypads...
Page 328 Accessories • The Federal Communications Commission (FCC) and Canadian Radio Telecommunications Commission (CRTC) regulate the use of mobile communications systems — such as two-way radios, telephones and theft alarms - that are equipped with radio transmitters. Any such equipment installed in your vehicle should comply with FCC or CRTC regulations and should be installed only by a qualified service technician.
Page 329: Index
Index maintenance-free ....284 replacement, specifications ...312 Accessory delay ......71 servicing ........284 Air cleaner filter ....310, 312 Bed extender ......94 Air conditioning ....46, 49 Brakes ........205 anti-lock ........205 Airbag supplemental restraint system ....136–137 anti-lock brake system and child safety seats ....139 (ABS) warning light ....206 description ......137 fluid, checking and adding ..304...
Page 330 Emergency Flashers ....236 Cruise control Emission control system ..300 (see Speed control) ....74 Engine ........319 Customer Assistance ....234 cleaning ........265 Ford Extended Service coolant ........286 Plan ..........261 fail-safe cooling .......290 Getting assistance outside idle speed control ....284 the U.S. and Canada ....262 lubrication Getting roadside assistance ...234...
Page 331 Index checking and adding ....280 Fuel pump shut-off switch ..237 dipstick ........280 Fuses ........237–238 filter, specifications ..283, 312 recommendations ....283 refill capacities ......313 specifications ....316, 319 Garage Door Opener (see Homelink wireless Exhaust fumes ......204 control system) ......78 Gas cap (see Fuel cap) ....294 Gas mileage Fail safe cooling ......290 (see Fuel economy) ....297...
Page 332 Index Inspection/maintenance Loading instructions ....187 (I/M) testing ......302 Locks Instrument panel autolock ........104 cleaning ........268 childproof ........97 cluster ........12 Lubricant specifications ...316, 319 lighting up panel and interior ........55 Lug nuts ........250 Lumbar support, seats .....113 Jack ..........244 positioning .......244 Manual transmission ....215 storage ........244 reverse ........217...
Page 333 Index Power distribution box Safety (see Fuses) .......238 restraints ..117, 120, 122–123, 125–128, 130 Power door locks ......96 extension assembly ....130 Power mirrors ......72 for adults ..122–123, 125–128 for children ......146 Power point .........69 lap belt ........125 Power steering ......208 Occupant Classification fluid, checking and adding ..303 Sensor ........118...
Page 334 Index Specification chart, Transfer case lubricants ......316, 319 fluid checking ......309 Speed control ......74 Transmission ......209 Starting your brake-shift interlock vehicle ......201–202, 204 (BSI) ........209–210 jump starting ......251 fluid, checking and adding Steering wheel (automatic) ......305 controls ........76 fluid, checking and adding tilting .........64 (manual) .........308 fluid, refill capacities ....313...

Ford 2006 F150 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Index

Quick Links

Table of Contents

Related Manuals for Ford 2006 F150

Summary of Contents for Ford 2006 F150

Table of Contents
