1.4 VGA 15pin Connector

Pin No.
1.
2.
3.
4.
5.
6.
7.
8.
VGA Connector layout

1.5 DVI Connector

Pin No.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
DVI Connector layout
Description
Red Input
Green Input
Blue Input
N/A
Connection detect
Red GND
Green GND
Blue GND
Description
TMDS Data 2-
TMDS Data 2+
TMDS Data 2/4 Shied
TMDS Data 4-
TMDS Data 4+
DDC Clock
DDC Data
N.C.
TMDS Data 1-
TMDS Data 1+
TMDS Data 1/3 Shield
TMDS Data 3-
Pin No.
9.
10.
11.
12.
13.
14.
15.
1
6
11
Pin No.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
6
Description
+5VDC
Logic GND
N/A
SDA- DDC-Serial Data
H Sync
V Sync
SCL- DDC-Serial Clock
5
10
15
Description
TMDS Data 3+
+5V Power
Ground (for +5V)
Hot Plug Detect
TMDS Data 0+
TMDS Data 0-
TMDS Data 0/5 Shield
TMDS Data 5-
TMDS Data 5+
TMDS Clock Shield
TMDS Clock+
TMDS Clock-
