- Page 1 LCD Monitor User Manual I2375PQU/ I2375SD/ I2275PWQU/ I2275SWD LED backlight www.aoc.com ©2016 AOC. All Rights Reserved.
-
Page 2: Table Of Contents
Safety .................................. 4 National Conventions ............................ 4 Power ................................5 Installation ..............................6 Cleaning ............................... 7 Other ................................8 Setup................................... 9 Contents in Box ............................9 Setup Base ..............................10 Adjusting Viewing Angle ..........................11 Connecting the Monitor ..........................12 Adjusting ................................13 Setting Optimal Resolution ...........................13 Windows 10 ............................13 Windows 8 ............................15... - Page 3 Service ................................55 Warranty Statement for Europe ........................55 Warranty Statement for Middle East and Africa (MEA) ..................57 AOC International (Europe) B.V........................59 Warranty Statement for North & South America (excluding Brazil) ............60 EASE PROGRAME .............................62 TCO DOCUMENT ............................63...
-
Page 4: Safety
Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 5: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 6: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 7: Cleaning
Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. -
Page 8: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 9: Setup
Power Cable Audio Analog HDMI MHL Cable Not all signal cables (Audio, DVI, Analog, DP, HDMI, MHL and USB cables) will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. -
Page 10: Setup Base
Setup Base Please setup or remove the base following the steps as below. Please place the monitor on a soft and flat surface to prevent the scratch. Setup: I2375PQU/I2275PWQU: Remove: I2375PQU/I2275PWQU:... -
Page 11: Adjusting Viewing Angle
Adjusting Viewing Angle For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor's angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor's angle. You are able to adjust the monitor's angle from -5°... -
Page 12: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor and Computer: I2375PQU/I2275PWQU I2375SD/I2275SWD Power Display port HDMI/MHL Analog (D-Sub 15-Pin VGA cable) AUDIO IN Earphone out USB 2.0 USB 3.0 Upstream 10 USB 3.0 11 USB 3.0+ fast charging To protect equipment, always turn off the PC and LCD monitor before connecting. -
Page 13: Adjusting
Adjusting Setting Optimal Resolution Windows 10 For Windows 10: • Right click START. • Click "CONTROL PANEL". • Click "DISPLAY". - Page 14 • Click on the "Change display settings" button. • Set the resolution SLIDE-BAR to Optimal preset resolution.
-
Page 15: Windows 8
Windows 8 For Windows 8: • Right click and click All apps at the bottom-right of the screen. • Set the "View by" to "Category". • Click "Appearance and Personalization". - Page 16 • Click "DISPLAY". • Set the resolution SLIDE-BAR to Optimal preset resolution...
-
Page 17: Windows 7
Windows 7 For Windows 7: • Click START. • Click "CONTROL PANEL". • Click "Appearance". • Click "DISPLAY". - Page 18 • Click on the "Change display settings" button. • Set the resolution SLIDE-BAR to Optimal preset resolution...
-
Page 19: Hotkeys
Press to display the OSD or confirm the selection. Power Press the Power button to turn on/off the monitor. Volume/> （I2375PQU/I2275PWQU） When there is no OSD, press Volume adjust volume. Image Ratio/> （I2375SD/I2275SWD） When there is no OSD, press Image Ratio adjust Image Ratio. - Page 20 Clear Vision When there is no OSD, Press the “<” button to activate Clear Vision. Use the “<” or “>” buttons to select between weak, medium, strong, or off settings. Default setting is always “off”. Press and hold “<” button for 5 seconds to activate the Clear Vision Demo, and a message of “Clear Vision Demo: on”...
-
Page 21: Osd Setting
OSD Setting Basic and simple instruction on the control keys. Press the MENU-button to activate the OSD window. Press to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it. If there is a sub-menu, press to navigate through the sub-menu functions. -
Page 22: Luminance
Movie Movie Mode Sports Sports Mode Gamma1 Adjust to Gamma 1 Gamma Gamma2 Adjust to Gamma 2 Gamma3 Adjust to Gamma 3 Disable dynamic contrast ratio Enable dynamic contrast ratio Weak OverDrive Medium （I2375PQU/I22 Adjust the response time. Strong 75PWQU）... -
Page 23: Image Setup
Image Setup MENU 1 Press (Menu) to display menu. MENU 2 Press to select (Image Setup), and press to enter. 3 Press to select submenu. 4 Press to adjust. AUTO 5 Press to exit Clock 0-100 Adjust picture Clock to reduce Vertical-Line noise. Phase 0-100 Adjust Picture Phase to reduce Horizontal-Line noise. -
Page 24: Color Setup
Color Setup MENU 1 Press (Menu) to display menu. MENU 2 Press to select (Color Setup), and press to enter. 3 Press to select submenu. 4 Press to adjust. AUTO 5 Press to exit Warm Recall Warm Color Temperature from EEPROM. Normal Recall Normal Color Temperature from EEPROM. -
Page 25: Picture Boost
Picture Boost MENU 1 Press (Menu) to display menu. MENU 2 Press to select (Picture Boost), and press to enter. 3 Press to select submenu. 4 Press to adjust. AUTO 5 Press to exit Bright Frame ON/OFF Enable/Disable Bright Frame Frame Size 14-100 Adjust the Size of the Frame... -
Page 26: Osd Setup
OSD Setup MENU 1 Press (Menu) to display menu. MENU 2 Press to select (OSD Setup), and press to enter. 3 Press to select submenu. 4 Press to adjust. AUTO 5 Press to exit English, France , Spanish, Portugues,German, Language Italian,Dutch,Swedish, Finnish, Select the OSD language Polish ,Czech, Russia,Korea,... -
Page 27: Extra
Extra MENU 1 Press (Menu) to display menu. MENU 2 Press to select (Extra), and press to enter. 3 Press to select submenu. 4 Press to adjust. AUTO 5 Press to exit Auto Auto Detect input signal D-SUB Select D-SUB signal source as input Input Select Select DVI signal source as input HDMI/MHL... -
Page 28: Led Indicator
LED Indicator Status LED Color Full Power Mode Green Power Saving Orange... -
Page 29: Driver
Driver Monitor Driver Windows 10 • Start Windows® 10 • Right click START. • Click "Control Panel". • Click on the "Display" icon. - Page 30 • Click on the "Change display settings" button • Click the "Advanced Settings" button.
- Page 31 • button. Click the "Monitor" tab and then click the "Properties" • Click the "Driver" tab. • Open the "Update Driver Software-Generic PnP Monitor" window by clicking on "Update Driver... “and then click the "Browse my computer for driver software" button.
- Page 32 • Select "Let me pick from a list of device drivers on my computer". • Click the "Have Disk" button. Click on the "Browse" button and navigate to the following directory: X:\Driver\module name(where X is the drive letter designator for the CD-ROM drive). •...
-
Page 33: Windows 8
Windows 8 • Start Windows® 8 • Right click and click All apps at the bottom-right of the screen. • Click on the "Control Panel" icon • Set the "View by" to "Large icons" or "Small icons". • Click on the "Display" icon. - Page 34 • Click on the "Change display settings" button. • Click the "Advanced Settings" button.
- Page 35 • button Click the "Monitor" tab and then click the "Properties" • Click the "Driver" tab. • Open the "Update Driver Software-Generic PnP Monitor" window by clicking on "Update Driver..." and then click the "Browse my computer for driver software" button.
- Page 36 • Select "Let me pick from a list of device drivers on my computer". • Click the "Have Disk" button. Click on the "Browse" button and navigate to the following directory: X:\Driver\module name (where X is the drive letter designator for the CD-ROM drive). •...
-
Page 37: Windows 7
Windows 7 • Start Windows® 7 • Click on the "Start" button and then click on "Control Panel". • Click on the "Display" icon. • Click on the "Change display settings" button. - Page 38 • Click the "Advanced Settings" button. • button. Click the "Monitor" tab and then click the "Properties" • Click the "Driver" tab.
- Page 39 • Open the "Update Driver Software-Generic PnP Monitor" window by clicking on “Update Driver... " and then click the "Browse my computer for driver software" button. • Select "Let me pick from a list of device drivers on my computer". •...
- Page 40 • Select the "xxx.inf" file and click the "Open" button. Click the "OK" button. • Select your monitor model and click the "Next" button. The files will be copied from the CD to your hard disk drive. • Close all open windows and remove the CD. •...
-
Page 41: I-Menu
Welcome to “i-Menu” software by AOC. i-Menu makes it easy to adjust your monitor display setting by using on screen menus instead of the OSD button on the monitor. To complete installation, please follow the installation guide. -
Page 42: E-Saver
Welcome to use AOC e-Saver monitor power management software! The AOC e-Saver features Smart Shutdown functions for your monitors, allows your monitor to timely shutdown when PC unit is at any status (On, Off, Sleep or Screen Saver); the actual shutdown time depends on your preferences (see example below). -
Page 43: Screen
Screen+ Welcome to "Screen+" software by AOC. Screen+ software is a desktop screen splitting tool; it splits the desktop into different panels, and each panel displays a different window. You only need to drag the window to a corresponding panel when you want to access it. It supports multiple monitor display to make your task easier. -
Page 44: Troubleshoot
Adjust the maximum resolution and frequency that the monitor can handle properly. Make sure the AOC Monitor Drivers are installed. Adjust the Contrast and Brightness Controls. Press to auto adjust. Picture Is Fuzzy & Has Make sure you are not using an extension cable or switch box. - Page 45 The Computer Power Switch should be in the ON position. The Computer Video Card should be snugly fitted in its slot. Make sure the monitor's video cable is properly connected to the computer. Monitor Is Stuck In Active Inspect the monitor's video cable and make sure no pin is bent. Off-Mode"...
-
Page 46: Specification
Driving system TFT Color LCD I2375PQU/ I2375SD: 58.42cm diagonal Viewable Image Size I2275PWQU/ I2275SWD: 54.61 cm diagonal I2375PQU/ I2375SD: 0.2652 (H)mm x 0.2652 (V)mm Panel Pixel pitch I2275PWQU/ I2275SWD: 0.24795 (H)mm x 0.24795 (V)mm Video R, G, B Analog Interface & Digital Interface Separate Sync. - Page 47 I2375PQU: 532.5mm I2375SD: 532.5mm I2275SWD: 183.53 mm I2275PWQU: 212.91 mm Depth I2375PQU: 213mm I2375SD: 198.5mm I2275SWD: 2.91KG I2275PWQU: 4.77KG Weight (monitor only) I2375PQU: 3.06KG I2375SD: 3.0KG Temperature: Operating 0° to 40° C Non-Operating -25° to 55° C Humidity: Environmental Operating...
-
Page 48: Preset Display Modes
Since the MHL provides mobile phone charging function and share the same connector with HDMI, Whether the MHL is set to On, Off or Standby mode, the MHL port provides power to charge the connected device simultaneously. In Standby and Off energy saving of ErP not applicable for the MHL charging functionality. Preset Display Modes Standard Resolution... -
Page 49: Pin Assignments
Pin Assignments 15-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Video-Red Video-Green Ground Video-Blue N.C. N.C. DDC-Serial data Detect Cable H-sync GND-R V-sync GND-G DDC-Serial clock GND-B 24-Pin Color Display Signal Cable Pin No. Signal Name Pin No. - Page 50 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Clock Shield TMDS Data 2 Shield TMDS Clock TMDS Data 2 TMDS Data 1+ Reserved (N.C. on device TMDS Data 1Shield TMDS Data 1 TMDS Data 0+ DDC/CEC Ground TMDS Data 0 Shield...
-
Page 51: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 52: Regulation
Regulation WEEE Declaration Disposal of Waste Equipment by Users in Private Household in the European Union. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. -
Page 53: Epa Energy Star
% and 0.01 weight % for cadmium, except for the exemptions set in Schedule 2 of the Rule. EPA Energy Star ENERGY STAR® is a U.S. registered mark. As an ENERGY STAR® Partner, AOC International (Europe) BV and Envision Peripherals, Inc. have determined that this product meets the ENERGY STAR® guidelines for energy... -
Page 54: Epeat Declaration
AOC believes in protecting the environment. With a key concern for the conservation of natural resources, as well as landfill protection, AOC announces the launch of AOC monitor’s packaging recycling program. This program is designed to help you discard of your monitor carton and filler materials properly. -
Page 55: Service
The freight cost for the warranty is pre-paid by AOC for the delivery and return. Please ensure you provide a dated proof of purchase along with the product and deliver to the AOC Certified or Authorized Service Center under the following condition: ... - Page 56 If your warranty has expired, you still have access to all available service options, but you will be responsible for the cost of service, including parts, labor, shipping (if any) and applicable taxes. AOC Certified or Authorized Service Center will provide you with an estimate of service costs before receiving your authorization to perform service.
-
Page 57: Warranty Statement For Middle East And Africa (Mea)
During this period, AOC International (Europe) B.V. offers a Carry-In (return to Service Center) Warranty Support at an AOC’s Authorized Service Center or Dealer and at its option, either repair the defective product with new or rebuilt parts, or replace it with a new or rebuilt product at no charge except as *stated below. As a Standard Policy,... - Page 58 Repair, modification, or installation of options or parts by anyone other than an AOC Certified or Authorized Service Center Improper environments like humidity, water damage and dusts Damaged by violence, earthquakes and terrorist attacks Excessive or inadequate heating or air conditioning or electrical powers failures, surges, or other...
-
Page 59: Aoc International (Europe) B.v
No manufacturer can guarantee that all panels will be free from pixel defects, but AOC guarantees that any monitor with an unacceptable number of defects will be repaired or replaced under warranty. This Pixel Policy explains the different types of pixel defects and defines acceptable defect levels for each type. -
Page 60: Warranty Statement For North & South America (Excluding Brazil)
In the United States and Canada contact your Dealer or EPI Customer Service, RMA Department at the toll free number (888) 662-9888. Or you can request an RMA Number online at www.aoc.com/na-warranty. * This limited warranty does not cover any losses or damages that occur as a result of:... - Page 61 ARGENTINA: http://ar.aoc.com/support/find_service_center BOLIVIA: http://bo.aoc.com/support/find_service_center CHILE: http://cl.aoc.com/support/find_service_center COLOMBIA: http://co.aoc.com/support/find_service_center COSTA RICA: http://cr.aoc.com/support/find_service_center DOMINICAN REPUBLIC: http://do.aoc.com/support/find_service_center ECUADOR: http://ec.aoc.com/support/find_service_center EL SALVADOR: http://sv.aoc.com/support/find_service_center GUATEMALA: http://gt.aoc.com/support/find_service_center HONDURAS: http://hn.aoc.com/support/find_service_center NICARAGUA: http://ni.aoc.com/support/find_service_center PANAMA: http://pa.aoc.com/support/find_service_center PARAGUAY: http://py.aoc.com/support/find_service_center PERU: http://pe.aoc.com/support/find_service_center URUGUAY: http://pe.aoc.com/support/find_service_center VENEZUELA: http://ve.aoc.com/support/find_service_center IF COUNTRY NOT LISTED: http://latin.aoc.com/support/find_service_center...
-
Page 62: Ease Programe
Tube & LCD Panel) *AOC will need to obtain a credit card number if you would like to get a new AOC monitor advanced shipped to your location, prior to the defective unit arriving at AOC’s service center. If you do not wish to supply a credit card, AOC will only ship the new monitor, once the defective unit arrives at the AOC service center. -
Page 63: Tco Document
TCO DOCUMENT (FOR TCO CERTIFIED MODELS)
