STeP 6: Connect other components (OPTIONAL)

AUX 2 - Side Panel
You can connect other components, such as a VCR, another recording device
(like a hard-disk drive product or DVD Recorder), or a video game system to
your Klipsch system using the AUXILIARY (AUX) INPUTS.
Connecting a component to AuX 1 INPuT
1.
From the component's output jacks, connect the best available video
option to the Klipsch system's
2.
Do the same thing for the audio connection. Choose the best available
connection from the component's AUDIO OUTPUT jacks, and connect
appropriate cables. Connect the cable(s) to the Klipsch system's
INPUT audio jacks.
Connecting a component to AuX 2 INPuT (side)
The AUX 2 INPUT jacks on the side of your Klipsch system were designed for
convenience when connecting temporary components, such as a video game
system or a digital camera/camcorder.
1.
From the component's output
option.
2.
Do the same thing for the audio connection. Choose the best available
connection from the component's
appropriate cable.
VCR Back Panel
INPUT
L R
R - AUDIO - L VIDEO S-VIDEO
AUX 1 INPUT video jacks.
jacks, connect the best available video
output jacks, and connect the
OUTPUT
L R
AUDIO VIDEO
2
Connecting headphones to heADPhONe OuTPuT
For private listening, connect compatible headphones to the HEADPHONE
jack on the side of the Klipsch system.
Connecting a device with uSB to uSB connector
Connect a device with
connector. This port is only for compatible USB flash memory drives. It is not
suitable for direct connection to a computer.
Note: this uSB port is a part of the "DISC" Source, not Aux 2.
AUX 1
Please see appendix I (page 28) for the basics on how input
and output jacks work with your Klipsch system.
RF IN
RF OUT
S-VIDEO
1
USB OUTPUT to the Klipsch system's
Input and Output Jacks
USB INPUT
