Klipsch CA-800-T Brochure & Specs
Professional cinema loudspeaker systems
Hide thumbs
Also See for CA-800-T:
- Owner's manual (4 pages) ,
- Brochure & specs (12 pages) ,
- Owner's manual (4 pages)
Related Manuals for Klipsch CA-800-T
Summary of Contents for Klipsch CA-800-T
- Page 1 Power. Detail. Emotion. Professional Cinema Loudspeaker Systems...
- Page 2 The best performers Once movie-goers experience the unbridled dynamics and intense realism of a Klipsch Cinema and Stage System, they will have a new favorite theater for life. Audiences have never heard dialogue so precise or soundtracks so stunningly detailed and immersive. Only Klipsch delivers...
- Page 3 American-made for over 60 years, Klipsch cinema speakers offer years of reliable and trouble-free performance. From the grandest auditoriums to the coziest cinemas, our technical experts will ensure that your customers have the richest auditory experience possible.
- Page 4 KPT-745-Q Following the success of the KPT-MCM-4-T Grand fully horn-loaded, four-way cinema system, Klipsch designed the four-way KPT-745-Q to deliver similar movie chills and thrills but from a much shallower cabinet. Less than 24 inches in depth, the KPT-745- Q system is perfect for larger theater venues with limited space behind the screen.
- Page 5 As the first complete three-way passive behind-the-screen system on the market, the KPT-435-N affords the ultimate in audio performance for small-and medium-sized venues. Less than 20 inches in depth, it is also one of the most space saving speakers in its performance category. Based on the proven KPT-904-LF dual 15-inch bass unit, the KPT-435-N delivers powerful bass from a shallow cabinet that is just 17.75 inches deep.
- Page 6 CA-800-T The CA-800-T compact full-range system works well in professional cinema surround applications where flexible mounting and extended range are required. It includes a high-power eight-inch extended low-frequency driver and a titanium diaphragm compression driver mated to a 90˚...
- Page 7 Capable of delivering an earth-shaking low frequency of 18Hz, the KPT-884 is a high-output, bass-reflex cinema subwoofer that features an advanced low-frequency four-inch voice coil driver design. Less than 23 inches in depth, this system utilizes a single 18-inch driver that gains its high efficiency through the use of large, geometrically optimized structures and lightweight cones.
-
Page 8: Specifications
S P E C I F I C A T I O N S KPT-MCM-4-T Grand Frequency Response* 40Hz-19kHz ± 3dB,-10dB @ 35Hz Crossover Point 300Hz, 800Hz, 8kHz Delay LF – 0ms MB – 5.35ms MF – 5.38ms HF – 6.38ms Crossover Slope 24dB/Octave Sensitivity... - Page 9 17.25" (43.82cm) 13" (33.02cm) Top 13.25" (33.66cm) Top 7" (17.78cm) Bottom 5" (13cm) Bottom 53 lbs. (24.09kg) 42 lbs. (19kg) CA-800-T 64Hz-17.5kHz ± 4dB 47Hz-20kHz -10dB 100 watts (21V) 40Hz-10kHz 113dB 96dB Horizontal 80° ± 40° 1.2kHz-20kHz Vertical 90° ± 30° 1kHz-20kHz 7dB ±...
- Page 10 S U B WO O F E R S KPT-884 27Hz-240Hz ± 3dB Frequency Response 18Hz–1.2kHz -10dB 1200 watts (92V) 20-200Hz Power Handling 128dB Calc. Max. Cont. Output Sensitivity 98dB Coverage 8 ohms (7.2 min. @ 23Hz) Nominal Impedance One K-472 18" woofer Transducers Barrier strip Input Connectors...
- Page 11 KPT-KHJ-LF KPT-904-LF 45Hz-800Hz ± 4dB 45Hz-1.5kHz ± 3dB 34Hz-1kHz -10dB 32Hz-2kHz -10dB 200 watts (40.5V) per woofer 40Hz-800Hz 400 watts (58V) per woofer 40Hz-800Hz 128dB 130dB 105dB 104dB Horizontal 90° ± 20° 200Hz-1kHz Horizontal 90° ± 20° 250Hz-1.5kHz Vertical 90° ± 20° 200Hz-600Hz Vertical 60°...
- Page 12 High efficiency, low distortion, controlled directivity, flat frequency response. It’s all here. Klipsch Group, Inc. 3502 Woodview Trace Indianapolis, IN 46268 klipsch.com ©2009 Klipsch Group, Inc. Specifications are subject to change without notice.
