- Page 1 The Ultimate Sound Experience ™ Professional Cinema Loudspeaker Systems...
- Page 2 The best performers Once movie-goers experience the unbridled dynamics and intense realism of a Klipsch Cinema and Stage System, they will have a new favorite theater for life. Audiences have never heard dialogue so precise or soundtracks so stunningly detailed and immersive. Only Klipsch delivers...
- Page 3 American-made for over 60 years, Klipsch cinema speakers offer years of reliable and trouble-free performance. From the grandest auditoriums to the coziest cinemas, our technical experts will ensure that your customers have the richest auditory experience possible.
- Page 4 With auditorium space at a premium, the Jubilee low–frequency device, with its 24-inch depth, is the ultimate space-saving solution. Developed by audio pioneer Paul W. Klipsch in 2001, this dual 12- inch loudspeaker system couples the horn-loaded woofers with the KPT-402-MF mid-bass Tractrix Horn coupled to the Klipsch K-1133 two-inch exit titanium compression driver.
- Page 5 As the first complete three-way passive behind-the-screen system on the market, the KPT-435-N affords the ultimate in audio performance for small-and medium-sized venues. Less than 20 inches in depth, it is also one of the most space saving speakers in its performance category.
- Page 6 6.5-inch woofer and titanium dome tweeter coupled to a 90˚x 90˚ Tractrix Horn. With its dual port and bass-reflex enclosure, the CA-650-T is also capable of handling 85 watts of continuous power and sensitivity of 95dB. The included heavy gauge zinc C-bracket provides added mounting strength.
- Page 7 Subwoofers Capable of delivering an earth-shaking low frequency of 18Hz, the KPT-884 is a high-output, bass-reflex cinema subwoofer that features an advanced low-frequency four-inch voice coil driver design. Less than 23 inches in depth, this system utilizes a single 18-inch driver that gains its high efficiency through the use of large, geometrically optimized structures and lightweight cones.
-
Page 8: Specifications
S P E C I F I C A T I O N S B E H I N D – T H E – S C R E E N S Y S T E M S KPT-MCM-4-T Grand Frequency Response* 40Hz-19kHz ±... - Page 9 Vertical 60° ± 20° 2kHz-19kHz LF Device – KPT-315-LF HF Device – KPT-904-HF 50.3" (128cm) 27.25" (69.2cm) 12.25" (31.1cm) 101 lbs. (46kg) CA-650-T 69Hz-20kHz ± 4dB 60Hz-20kHz -10dB 85 watts (19V) 40Hz-10kHz 111dB 95dB Horizontal 80° ± 40° 1.4kHz-20kHz Vertical 90° ± 30° 1.4kHz-18kHz 7dB ±...
- Page 10 S U B WO O F E R S KPT-884 27Hz-240Hz ± 3dB Frequency Response 18Hz–1.2kHz -10dB Power Handling 1200 watts (92V) 20-200Hz 129dB Calc. Max. Cont. Output 98dB Sensitivity Coverage Nominal Impedance 8 ohms (7.2 min. @ 23Hz) One K-472 18" woofer Transducers Barrier strip Input Connectors...
- Page 11 KPT-KHJ-LF KPT-904-LF 45Hz-800Hz ± 4dB 45Hz-1.5kHz ± 3dB 34Hz-1kHz -10dB 32Hz-2kHz -10dB 200 watts (40.5V) per woofer 40Hz-800Hz 400 watts (58V) per woofer 40Hz-800Hz 128dB 130dB 105dB 104dB Horizontal 90° ± 20° 200Hz-1kHz Horizontal 90° ± 20° 250Hz-1.5kHz Vertical 90° ± 20° 200Hz-600Hz Vertical 60°...
- Page 12 High efficiency, low distortion, controlled directivity, flat frequency response. It’s all here. Klipsch Audio Technologies 3502 Woodview Trace Indianapolis, IN 46268 klipsch.com 193171 (Rev. 1) ©2005 Klipsch Audio Technologies. Specifications are subject to change without notice. 5M1105...
