EMPIRE
EMPIRE
Comfort Systems
DIRECT VENT
GAS FIREPLACE HEATER
MODEL SERIES
MILLIVOLT STANDING PILOT
DVP42DP31(N,P)-2
DIRECT IGNITION
DVP42DP51N-1
INTERMITTENT PILOT
DVP42DP71(N,P)-3
REMOTE RF
DVP42DP91(N,P)-3
UL FILE NO. MH30033
GAS-FIRED
: If not installed, operated and maintained
WARNING
in accordance with the manufacturer's instructions,
this product could expose you to substances in fuel
or from fuel combustion which can cause death or
serious illness.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by state or local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified
kit is used.
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
Direct Vent Zero Clearance Gas
Installer:
Consumer: Retain this manual for future reference.
WARNING
tions are not followed exactly, a fire or explosion
may result causing property damage, personal in-
jury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
•
•
•
— Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.
AND
Fireplace Heater
Leave this manual with the appliance.
: If the information in these instruc-
Do not try to light any appliance.
Do not touch any electrical switch; do not use
any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
Page 1
