Yaesu Mark-V FT-1000MP Field Technical Supplement page 142

TUNER-CNTL Unit
Parts List
REF. DESCRIPTION
R 6557 CHIP RES.
R 6558 CHIP RES.
R 6559 CHIP RES.
R 6560 CHIP RES.
R 6561 CHIP RES.
R 6562 CHIP RES.
R 6563 CHIP RES.
R 6564 CHIP RES.
R 6565 CHIP RES.
R 6566 CHIP RES.
R 6567 CHIP RES.
R 6568 CHIP RES.
R 6569 CHIP RES.
R 6570 CHIP RES.
R 6571 CHIP RES.
R 6572 CHIP RES.
R 6573 CHIP RES.
R 6574 CHIP RES.
R 6575 CHIP RES.
R 6576 CHIP RES.
R 6577 CHIP RES.
R 6578 CHIP RES.
R 6580 CHIP RES.
R 6581 CHIP RES.
R 6587 CHIP RES.
R 6588 CHIP RES.
R 6589 CHIP RES.
R 6590 CHIP RES.
R 6591 CHIP RES.
R 6592 CHIP RES.
R 6593 CHIP RES.
R 6594 CHIP RES.
R 6595 CHIP RES.
R 6596 CHIP RES.
R 6597 CHIP RES.
R 6598 CHIP RES.
R 6599 CHIP RES.
R 6600 CHIP RES.
R 6601 CHIP RES.
R 6602 CHIP RES.
R 6603 CHIP RES.
TC6501 TRIMMER CAP.
TP6501 TERMINAL
TP6502 TERMINAL
VR6501 POT.
6P-8
VALUE V/W TOL.
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
10k 1/10W 5%
10k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
4.7k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
100k 1/10W 5%
10k 1/10W 5%
10k 1/10W 5%
1k 1/10W 5%
4.7k 1/10W 5%
1M 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
1k 1/10W 5%
180 1/10W 5%
100k 1/10W 5%
1k 1/10W 5%
100k 1/10W 5%
10k 1/10W 5%
10pF
47k
MFR'S DESIG VXSTD P/N
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 103J J24205103
RMC1/10T 103J J24205103
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 472J J24205472
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 104J J24205104
RMC1/10T 103J J24205103
RMC1/10T 103J J24205103
RMC1/10T 102J J24205102
RMC1/10T 472J J24205472
RMC1/10T 105J J24205105
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 102J J24205102
RMC1/10T 181J J24205181
RMC1/10T 104J J24205104
RMC1/10T 102J J24205102
RMC1/10T 104J J24205104
RMC1/10T 103J J24205103
ECV1ZW10X32 10PF K91000012
TP-E/MS-60124 Q5000016
TP-E/MS-60124 Q5000016
RH0411CS4J 47KB J51827473
VERS. LOT. LAY ADR
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
1-
